Honda - Tube, B, Fuel - 16952-MAH-010

Had a fuel tube spring a leak above the LH carb at the fuel inlet. Figured it was time to replace to replace all the fuel line.

First I removed all components keeping me from accessing all fuel line including the tank, battery, battery box, top pipe, and all of the covers bellow the seat. I then proceeded to remove all the old fuel line (take pictures to remember how all the tubes are routed!!!). Then do the reverse. A little bit of oil really helps to slide the line over the nipples.

The only thing I wasn't able to swap out for an OEM line was the tank vent line on the RH side since its no longer available anywhere. I got around this but just using the extra bulk hose I had left (you need only a 2 inch section for the RH carb and the rest is extra.) And ran a similar route to the OEM tube.

Honestly ordering some extra clips will save you a lot of headache so don't be stingy and gets some!

Parts used in this repair

+

+

+

+

+

+

+

+

Total price:  $132.82

Honda TUBE, L. (17515-MG8-000) $14.78

Honda TUBE, A, FUEL (16955-MAH-000) $25.77

Honda CLAMP, TUBE, (D12) (95002-41200-08) $3.45

Honda CLAMP, CANISTER, HOSE (90682-SA0-671) $11.47

Honda CLIP, TUBE, (B12) (95002-02120) $2.67

Honda CLIP, OIL, DRAIN, TUBE (15771-KV6-000) $5.48

Honda BULK HOSE (5.5X3000) (95001-55003-60M) $64.86

Honda CLIP, TUBE, (C9) (95002-50000) $1.74

Honda CLIP, TUBE, (B10) (95002-02100) $2.60
