OEM Parts Polaris Shaft-Output(285810)

Polaris

Polaris - Shaft-Output(285810) - 2204329

Check if this part fits your Polaris model

Manufacturer

Brand New, Genuine Polaris Part

Manufacturer Part#

2204329

Item Number

OEM598330

Adept Powersports currently does not sell Polaris parts.

Information is available for reference only at this time.

Provided by Adept Powersports customers like you

Installation Instructions and Repair Stories

Friday, March 6, 2020

I purchased a well used 2013 Bobcat 3400XL Diesel that had a gearbox problem. It was slipping and popping under load. Found the primary drive chain was stretched, but luckily the sprockets were fine. While I had it apart I went ahead and changed out both the front and rear output shafts since the splines were badly worn. The front output shaft assembly comes with the bearings already pressed on! To remove the bearings from the rear output shaft, the bearing separator and puller kit from HF worked great. When installing new seals in the case, be careful and take your time as there are no stops. You have to go slow and keep them even until you get to the proper depth or you can easily drive the seals too far.

Difficulty level: Average

Were these instructions helpful?

Parts used in this repair

+

Total price: $2.88

Polaris WASHER-.906 X 1.38 X .060" (7556120) $1.73

Polaris LOCK WASHER (7552901) $1.15

This part is utilized in 12 assemblies

2011 Polaris MILITARY DIESEL RANGER CREW - M11WH90MA/MG/MK/ML

DRIVE TRAIN, MAIN GEARCASE INTERNALS - M11WH90MA/MG/MK/ML

This part is number 52 on this diagram
Quantity required per assembly: 1

2011 Polaris RANGER 4X4 900 D (R11TH90DG)

DRIVE TRAIN, MAIN GEARCASE INTERNALS

This part is number 52 on this diagram
Quantity required per assembly: 1

2011 Polaris RANGER 4X4 CREW DIESEL 900 D - R11WH90DG

DRIVE TRAIN, MAIN GEARCASE INTERNALS - R11WH90DG

This part is number 52 on this diagram
Quantity required per assembly: 1

2012 Polaris MILITARY DIESEL RANGER CREW - M12WH90MG/MK/ML

DRIVE TRAIN, MAIN GEARCASE INTERNALS - M12WH90MG/MK/ML

This part is number 52 on this diagram
Quantity required per assembly: 1

2012 Polaris RANGER 900 DIESEL (R12TH90DG)

DRIVE TRAIN, MAIN GEARCASE INTERNALS

This part is number 52 on this diagram
Quantity required per assembly: 1

2012 Polaris RANGER CREW 4X4 900 DIESEL (R12WH90DG)

DRIVE TRAIN, MAIN GEARCASE INTERNALS

This part is number 52 on this diagram
Quantity required per assembly: 1

2013 Polaris MV DIESEL CREW - M13WH90MB

DRIVE TRAIN, MAIN GEARCASE INTERNALS - M13WH90MB

This part is number 52 on this diagram
Quantity required per assembly: 1

2013 Polaris RANGER 900 DIESEL - R13TH90DG

DRIVE TRAIN, MAIN GEARCASE INTERNALS - R13TH90DG

This part is number 52 on this diagram
Quantity required per assembly: 1

2013 Polaris RANGER CREW 900 DIESEL - R13WH90DG

DRIVE TRAIN, MAIN GEARCASE INTERNALS - R13WH90DG

This part is number 52 on this diagram
Quantity required per assembly: 1

2014 Polaris Ranger 900 Diesel

R14TH90DG

Main Gearcase Internals - R14TH90DG

This part is number 52 on this diagram
Quantity required per assembly: 1

2014 Polaris Ranger Crew 900 Diesel

R14WH90DG

Main Gearcase Internals - R14WH90DG

This part is number 52 on this diagram
Quantity required per assembly: 1

2014 Polaris Ranger Diesel INTL

R14TH90FX

Main Gearcase Internals - R14TH90FX

This part is number 52 on this diagram
Quantity required per assembly: 1
