After a lowside crash, my 2015 Triumph Street Triple found itself virtually unscathed, thanks to aftermarket sliders, with the only irreparable damage being a broken rear brake pedal/lever. (Safety equipment for the win)

The muffler was already removed for dent repair and refinishing, leaving easy access to the pivots for the rear brake lever. Starting with the clevis for the master cylinder, the spring clip was lifted up and unwrapped from the clevis pin, allowing the pin to slide out. [outboard, away from centerline of the bike]
After this, the lever could be swung forward far enough to unhook the return spring and the brake lamp switch spring from thier perch on the inboard side of the lever.
Lastly, a metric hex key (don't recall size) was used to unfastened the brake lever pivot bolt from the frame. This was achieved best using a ratchet and hex drive socket, though an Allen key would work. Best access is to reach in from below the perch allowing the tool to arc parallel to the swing arm.

Installation was as follows:
It was easier to insert the master cylinder clevis pin through the new lever first, and clip it into place. Next the pivot bolt was inserted through the lever and screwed into the back side of the perch. (Grease it first, knuckleheads!)
Lastly the springs. First stretch the return sping and hook it onto the lever. Then the brake lamp switch spring.

After checking proper torque, all is clear to re-hang the muffler. I think this task can be completed without removal of it, but being able to see certainly helped.
