Honda Power Equipment E1500 - Alternator

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
01

ALTERNATOR ASSEMBLY

Part #: 31100-839-672 Required per assembly: 1 Note: (Honda Code 0217836)
Not Available
02

ROTOR ASSEMBLY

Part #: 31104-839-158 Required per assembly: 1 Note: (Honda Code 0178996)
Not Available
03

STATOR ASSEMBLY

Part #: 31105-839-671 Required per assembly: 1 Note: (Honda Code 0177626)
Not Available
05

BRUSH, CARBON

Part #: 31107-815-168 Required per assembly: 2 Note: (NOT AVAILABLE) (Honda Code 0140343)
Not Available
06

COVER, END, *Y3L*

Part #: 31108-839-158N Note: (Honda Code 0177634) (IVORY WHITE)
(IVORY WHITE)
$442.40
$320.74
-
+
Add to cart
07

COVER, FR., *Y3L*

Part #: 31109-815-178N Note: (Honda Code 0140277) (IVORY WHITE)
(IVORY WHITE)
$482.52
$349.83
-
+
Add to cart
08

PULLEY, FAN

Part #: 31111-815-168 Required per assembly: 1 Note: (Honda Code 0140269)
$271.20
$196.62
-
+
Add to cart
09

COVER *R2L*

Part #: 31113-839-158C Note: (Honda Code 0177642) (SCARLET)
(SCARLET)
$175.22
$127.03
-
+
Add to cart
10

COVER, FAN, *Y3L*

Part #: 31114-815-168N Note: (Honda Code 0140251) (IVORY WHITE)
(IVORY WHITE)
$94.84
$68.76
-
+
Add to cart
14

TERMINAL ASSEMBLY

Part #: 31118-815-169 Required per assembly: 1 Note: (Honda Code 0246793)
Not Available
15

COVER, STATOR, *Y3L*

Part #: 31127-815-158N Note: (Honda Code 0140426) (IVORY WHITE)
(IVORY WHITE)
$68.10
$49.37
-
+
Add to cart
16

STAY, BRUSH, HOLDER

Part #: 31129-815-168 Required per assembly: 2 Note: (Honda Code 0379255)
Not Available
17

WASHER, BEARING

Part #: 31131-815-158 Required per assembly: 1 Note: (Honda Code 0140418)
Not Available
18

BUSH, RUBBER

Part #: 31131-839-158 Required per assembly: 1 Note: (Honda Code 0177675)
Not Available
19

CIRCLIP (INNER)

Part #: 31132-815-158 Required per assembly: 1 Note: (INNER) (Honda Code 0140293)
Not Available
20

BUSH, INSULATING

Part #: 31133-815-158 Required per assembly: 2 Note: (Honda Code 0140376)
Not Available
21

WASHER, INSULATING

Part #: 31134-815-158 Required per assembly: 2 Note: (Honda Code 0140350)
Not Available
24

CONNECTOR ASSEMBLY

Part #: 32100-839-158 Required per assembly: 1 Note: (Honda Code 0177873)
$132.50
$97.50
-
+
Add to cart
27

PLATE, CAUTION

Part #: 87525-839-670 Required per assembly: 1 Note: (Honda Code 0177972)
Not Available
29

WASHER, LOCK, (8MM)

Part #: 90534-706-010 Required per assembly: 1 Note: (8MM) (Honda Code 0177998)
$6.39
$5.21
-
+
Add to cart
30

KEY (7X7X33)

Part #: 90741-889-810 Note: (7X7X33) (YELLOW) (Honda Code 1064039)
$9.18
$7.26
-
+
Add to cart
31

BOLT, HEX., (8X20)

Part #: 92101-08020-0A Required per assembly: 1
$2.63
$2.44
-
+
Add to cart
34

BOLT, HEX., (10X28)

Part #: 92101-10028-0A Required per assembly: 4
Not Available
36

NUT, HEX., (10MM)

Part #: 94030-10000 Required per assembly: 4
$2.42
$2.25
-
+
Add to cart
37

WASHER, PLAIN, (6MM)

Part #: 94101-06800 Required per assembly: 4
Not Available
38

WASHER, PLAIN, (8MM)

Part #: 94101-08000 Required per assembly: 1
$1.87
$1.73
-
+
Add to cart
39

WASHER, FLAT, (18MM)

Part #: 94101-18000 Required per assembly: 1 Note: (18MM) (Honda Code 0140020)
Not Available
40

WASHER, SPRING, (6MM)

Part #: 94111-06000 Required per assembly: 4
$1.98
$1.83
-
+
Add to cart
41

WASHER, SPRING, (8MM)

Part #: 94111-08000 Required per assembly: 1
$2.02
$1.87
-
+
Add to cart
42

WASHER (10MM)

Part #: 94111-10000 Required per assembly: 4
$2.37
$2.19
-
+
Add to cart
44

BEARING (6203UU)

Part #: 96150-62030-10 Required per assembly: 1
$17.47
$15.89
-
+
Add to cart
45

BEARING (6205UU)

Part #: 96150-62050-10 Required per assembly: 1
$34.59
$31.48
-
+
Add to cart
46

WASHER, PLAIN, (10MM)

Part #: 94101-10000 Required per assembly: 4
$2.18
$2.02
-
+
Add to cart
