Honda Power Equipment E1500K3 - Alternator

ALTERNATOR ASSEMBLY

Part #: 31100-876-671SF Required per assembly: 1 Note: (Honda Code 0443333)

Not Available

ROTOR

Part #: 31104-876-003 Required per assembly: 1 Note: (Honda Code 0803841)

Not Available

STATOR ASSEMBLY

Part #: 31105-876-168 Required per assembly: 1 Note: (Honda Code 0916189)

Not Available

BRUSH, CARBON

Part #: 31107-815-168 Required per assembly: 2 Note: (NOT AVAILABLE) (Honda Code 0140343)

Not Available

COVER, END, *NH31*

Part #: 31108-876-158XC Note: (Honda Code 0443366) (MCKINLEY WHITE)
(MCKINLEY WHITE)

Not Available

COVER, FR., *NH31*

Part #: 31109-815-188XC Note: (Honda Code 0379180) (MCKINLEY WHITE)
(MCKINLEY WHITE)

Not Available

COVER *R8*

Part #: 31113-876-158H Note: (Honda Code 0443374) (BRIGHT RED)
(BRIGHT RED)

Not Available

COVER, FAN, *NH31*

Part #: 31114-815-168XC Note: (Honda Code 0379230) (MCKINLEY WHITE)
(MCKINLEY WHITE)

Not Available

COVER, B, BEARING

Part #: 31117-839-168 Required per assembly: 1 Note: (Honda Code 0442822)

Not Available

TERMINAL

Part #: 31119-876-158 Required per assembly: 1 Note: (Honda Code 0442830)

Not Available

COVER, STATOR, *NH31*

Part #: 31127-876-158XC Note: (Honda Code 0443382) (MCKINLEY WHITE)
(MCKINLEY WHITE)

Not Available

STAY, BRUSH, HOLDER

Part #: 31192-876-158 Required per assembly: 2 Note: (Honda Code 0443408)

Not Available

WASHER, BEARING

Part #: 31131-815-158 Required per assembly: 1 Note: (Honda Code 0140418)

Not Available

BUSH, RUBBER

Part #: 31131-876-158 Required per assembly: 1 Note: (Honda Code 0443390)

Not Available

CIRCLIP (25MM)

Part #: 94514-25000 Required per assembly: 1 Note: (OUTER) (25MM) (Honda Code 0443168)

Not Available

BUSH, INSULATING

Part #: 31133-815-158 Required per assembly: 2 Note: (Honda Code 0140376)

Not Available

WASHER, INSULATING

Part #: 31134-815-158 Required per assembly: 2 Note: (Honda Code 0140350)

Not Available

PLATE

Part #: 32101-839-168 Required per assembly: 1 Note: (Honda Code 0442988)

Not Available

WASHER, LOCK, (8MM)

Part #: 90534-706-010 Required per assembly: 1 Note: (8MM) (Honda Code 0177998)

KEY (7X7X33)

Part #: 90741-889-810 Note: (7X7X33) (YELLOW) (Honda Code 1064039)

BOLT, HEX., (8X20)

Part #: 92101-08020-0A Required per assembly: 1

BOLT, HEX., (8X25)

Part #: 92101-08025-0A Required per assembly: 1

BOLT, HEX., (6X118)

Part #: 92020-06118-0H Required per assembly: 4 Note: (6X118) (Honda Code 2687812)

Not Available

BOLT, HEX., (10X28)

Part #: 95100-10028 Required per assembly: 4 Note: (10X28) (Honda Code 0443556)

Not Available

NUT, HEX., (10MM)

Part #: 94030-10000 Required per assembly: 4

WASHER, PLAIN, (6MM)

Part #: 94101-06800 Required per assembly: 4

Not Available

WASHER, PLAIN, (8MM)

Part #: 94102-08000 Required per assembly: 1

WASHER, FLAT, (18MM)

Part #: 94101-18000 Required per assembly: 1 Note: (18MM) (Honda Code 0140020)

Not Available

WASHER, SPRING, (8MM)

Part #: 94111-08000 Required per assembly: 1

WASHER (10MM)

Part #: 94111-10000 Required per assembly: 4

BEARING (6203UU)

Part #: 96150-62030-10 Required per assembly: 1

BEARING (6205UU)

Part #: 96150-62050-10 Required per assembly: 1

WASHER, PLAIN, (10MM)

Part #: 94101-10000 Required per assembly: 4

WASHER, SPRING, (5MM)

Part #: 94111-05800 Required per assembly: 4

SCREW, PAN, (5X10)

Part #: 93500-05010-0H Required per assembly: 4

WASHER, PLAIN, (5MM)

Part #: 94101-05800 Required per assembly: 4

CLAMP, B, WIRE

Part #: 30564-871-601 Required per assembly: 2 Note: (Honda Code 0442723)
