OEM Parts Honda Power Equipment Honda Power Equipment E2500K2 Control Box K2

Honda Power Equipment E2500K2 - Control Box K2

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
01

BOX, CONTROL, *R8*

Part #: 31400-840-674H Note: (Honda Code 0401851) (BRIGHT RED)
(BRIGHT RED)
Not Available
02

COVER (UPPER) *R2*

Part #: 31401-840-158C Note: (UPPER) (Honda Code 0401869) (SCARLET)
(SCARLET)
Not Available
03

COVER, CONTROL, BOX

Part #: 31402-840-673 Required per assembly: 1 Note: (LOWER) (Honda Code 0438325)
Not Available
04

TRANSFORMER, CURRENT

Part #: 31403-840-672 Required per assembly: 1 Note: (Honda Code 0401901)
Not Available
05

PNL, RR., CONTROL, BOX

Part #: 31405-839-158 Required per assembly: 1 Note: (Honda Code 0401919)
Not Available
07

KNOB, ADJUSTING

Part #: 31407-815-158 Required per assembly: 1 Note: (Honda Code 0140822)
Not Available
08

TERMINAL

Part #: 31408-880-000 Required per assembly: 2 Note: (+) (Honda Code 0475103)
$44.90
$33.05
-
+
Add to cart
09

TERMINAL

Part #: 31409-880-000 Required per assembly: 1 Note: (-) (Honda Code 0475111)
$44.90
$34.03
-
+
Add to cart
10

VOLTMETER ASSY.

Part #: 37450-898-000 Required per assembly: 1
$226.92
$166.98
-
+
Add to cart
12

PLATE, RESISTOR

Part #: 31413-839-158 Required per assembly: 2 Note: (Honda Code 0433821)
Not Available
13

TERMINAL, BREAKER

Part #: 31414-815-168 Required per assembly: 1 Note: (Honda Code 0292748)
Not Available
15

STACK, ASSEMBLY, DIODE

Part #: 31417-840-159 Required per assembly: 1 Note: (Honda Code 0401935)
Not Available
16

STACK ASSEMBLY

Part #: 31425-840-159 Required per assembly: 1 Note: (Honda Code 0401943)
Not Available
17

CONDENSER ASSEMBLY

Part #: 31426-840-158 Required per assembly: 1 Note: (Honda Code 0401950)
Not Available
20

RESISTOR, ADJUSTABLE

Part #: 31452-840-158 Required per assembly: 1 Note: (Honda Code 0401976)
Not Available
21

BOLT, RESISTOR, SET

Part #: 31453-840-168 Required per assembly: 1 Note: (Honda Code 0379313)
Not Available
22

RESISTOR SET

Part #: 31455-840-158 Required per assembly: 1 Note: (Honda Code 0401984)
Not Available
24

WIRE HARNESS (6P)

Part #: 32110-840-168 Required per assembly: 1 Note: (6P) (Honda Code 0402008)
Not Available
25

CONNECTOR ASSEMBLY (4P)

Part #: 32121-840-168 Required per assembly: 1 Note: (OUTER) (4P) (Honda Code 0402024)
Not Available
26

PLUG, RECEPTACLE

Part #: 32310-812-640 Required per assembly: 2 Note: (Honda Code 0323212)
$7.78
-
+
Add to cart
27

RECEPTACLE

Part #: 32333-880-680 Required per assembly: 1 Note: (15A-125V) (Honda Code 0475533)
$78.86
$58.03
-
+
Add to cart
28

BULB, DASH, (24V-2W)

Part #: 34909-880-000 Required per assembly: 1 Note: (24V2W) (Honda Code 0356600) (Optional)
Not Available
31

FUSE (8A)

Part #: 38201-815-605 Required per assembly: 2 Note: (8A) (Honda Code 0140921)
Not Available
33

SUPPORTER

Part #: 38221-815-168 Required per assembly: 1 Note: (Honda Code 0130666)
Not Available
36

PLATE, DESCRIPTION

Part #: 87521-839-680 Required per assembly: 1 Note: (Honda Code 0402164)
Not Available
37

MARK, C, CAUTION

Part #: 87524-839-680 Required per assembly: 1 Note: (Honda Code 0402172)
Not Available
