Control Box replacement parts for Honda Power Equipment EB11000

OEM Parts Honda Power Equipment Honda Power Equipment EB11000 Control Box

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

01	A.V.R. ASSEMBLY Part #: 31700-Z08-E31 Required per assembly: 1 Note: (Honda Code 6569255) $1,150.34 $846.51 - + Add to cart
02	CABLE, CHOKE Part #: 17950-765-A10 Required per assembly: 1 Note: (Honda Code 5033931) Not Available
03	COVER, CONTROL, BOX Part #: 31410-YZA-000ZA Required per assembly: 1 Note: (Honda Code 5042551) Not Available
05	MARK, PANEL, PLATE Part #: 31406-YZA-000 Required per assembly: 1 Note: (Honda Code 5042577) Not Available
06	PANEL, CONTROL Part #: 31420-YZA-000 Required per assembly: 1 Note: (Honda Code 5042585) Not Available
07	GROMMET, CHOKE, CABLE Part #: 91651-Z08-E31 Required per assembly: 1 Note: (Honda Code 6580112) $4.20 $4.09 - + Add to cart
08	DIODE ASSEMBLY Part #: 31720-YZA-000 Required per assembly: 1 Note: (Honda Code 5042601) Not Available
09	HARNESS, GENERATOR Part #: 32100-YZA-000 Required per assembly: 1 Note: (Honda Code 5042619) Not Available
10	RECEPTACLE Part #: 32331-ZC6-630 Required per assembly: 1 Note: (50A/125-250V) (Honda Code 3639374) (Optional) $127.56 $92.48 - + Add to cart
11	RECEPTACLE Part #: 32330-Z08-E42 Required per assembly: 2 Note: (20A/125V) (Honda Code 8941130) $335.10 $246.59 - + Add to cart
12	RECPTL (30A/125V) Part #: 32332-ZB4-630 Required per assembly: 1 $45.20 $34.26 - + Add to cart
13	SWITCH, COMBINATION Part #: 35100-ZA0-023 Required per assembly: 1 $111.24 $81.85 - + Add to cart
14	THROTTLE, UNIT, AUTO Part #: 36210-ZB4-014 Required per assembly: 1 $249.08 $183.29 - + Add to cart
15	SWITCH Part #: 36214-ZB4-023 Required per assembly: 1 $39.48 $29.06 - + Add to cart
16	BREAKER (41A) Part #: 38220-YZA-000 Required per assembly: 1 Note: (41A) (Honda Code 5042627) Not Available
17	PROTR, CIRCUIT, (20A) Part #: 38240-ZC6-E31 Required per assembly: 2 Note: (20A) (Honda Code 8269789) $77.66 $57.14 - + Add to cart
18	PROTR, CIRCUIT, (30A) Part #: 38241-ZC6-E31 Required per assembly: 3 Note: (30A) (Honda Code 8269797) $77.68 $57.16 - + Add to cart
19	METER, ASSEMBLY, HOUR Part #: 39700-ZC6-003 Required per assembly: 1 Note: (Honda Code 3639580) $320.68 $235.99 - + Add to cart
20	BOLT, HEX., (6X28) Part #: 90011-899-840 Required per assembly: 1 Note: (6X28) (Honda Code 3479797) $3.18 - + Add to cart
22	RETAINER (6MM) Part #: 90501-ZA7-640 Required per assembly: 1 Note: (6MM) (Honda Code 3479805) $3.70 - + Add to cart
23	TIE, CABLE Part #: 32903-ZC8-N01 Required per assembly: 3 Note: (C) (Honda Code 6569651) (Optional) $2.44 $2.26 - + Add to cart
24	SCREW, PAN, (3X6) Part #: 93500-03006-0G Required per assembly: 6 Not Available
25	SCREW, PAN, (4X12) Part #: 93500-04012-0G Required per assembly: 10 $1.95 $1.80 - + Add to cart
26	SCREW-WASHER (4X20) Part #: 93893-04020-08 Required per assembly: 1 $1.91 $1.77 - + Add to cart
27	SCREW-WASHER (5X16) Part #: 93893-05016-08 Required per assembly: 2 $2.26 $2.09 - + Add to cart
28	NUT, HEX., (6MM) Part #: 94001-06390-0S Required per assembly: 1 Note: (6MM) (Honda Code 1240720) $2.61 $2.42 - + Add to cart
29	NUT, FLANGE, (4MM) Part #: 94050-04080 Required per assembly: 11 $2.27 $2.10 - + Add to cart
30	WASHER, PLAIN, (6MM) Part #: 94101-06800 Required per assembly: 1 Not Available
31	WASHER, SPRING, (6MM) Part #: 94111-06800 Required per assembly: 1 $2.17 $2.00 - + Add to cart
32	BOLT, FLANGE, (8X16) Part #: 95701-08016-00 Required per assembly: 2 $2.79 $2.60 - + Add to cart
33	BOLT, FLANGE, (6X12) Part #: 96001-06012-07 Required per assembly: 2 $2.79 $2.60 - + Add to cart
34	FUSE B (5A) Part #: 98200-20500 Required per assembly: 1 $2.13 $1.97 - + Add to cart
35	FUSE B (10A) Part #: 98200-21000 Required per assembly: 1 $1.98 $1.83 - + Add to cart
36	RECEPTACLE Part #: 32334-ZA0-631 Required per assembly: 1 Note: (30A/125-250V) Use up to Frame SN 1039897. Not Available
