Engine Control replacement parts for Honda Power Equipment EB12D

OEM Parts Honda Power Equipment Honda Power Equipment EB12D Engine Control

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

01	RECTIFIER, REGULATOR Part #: 31620-762-003 Required per assembly: 1 Note: (Honda Code 3639291) ~~$195.26~~ $147.93 - + Add to cart
02	DIODE, D.C. Part #: 31720-ZA8-V00 Required per assembly: 1 ~~$46.98~~ $34.04 - + Add to cart
02	DIODE, D.C. Part #: 31720-ZA8-V00 Required per assembly: 1 ~~$46.98~~ $34.04 - + Add to cart
03	BRKT, ELECTRIC, PARTS Part #: 38252-ZC6-000 Required per assembly: 1 Note: (Honda Code 3639556) ~~$102.02~~ $73.93 - + Add to cart
04	RELAY, CONTROL, (20A) Part #: 38360-762-003 Required per assembly: 1 Not Available
05	RELAY (20A) Part #: 38380-MN5-003 Required per assembly: 1 ~~$49.48~~ $41.22 - + Add to cart
06	CONTROL, UNIT, ENGINE Part #: 38480-ZC6-003 Required per assembly: 1 Note: (Honda Code 3639564) Not Available
07	CUSHION Part #: 38487-ZC6-003 Required per assembly: 2 Note: (Honda Code 3639572) $10.42 - + Add to cart
08	RELAY, STARTER Part #: 38501-KG8-004 Required per assembly: 2 ~~$56.87~~ $45.33 - + Add to cart
09	SUSPENSION Part #: 38506-KG8-004 Not Available
10	SUSPENSION, STARTER, RELAY, (TATEISHI) Part #: 38506-751-701 $6.22 - + Add to cart
11	SCREW-WASHER (5X12) Part #: 93891-05012-08 Required per assembly: 1 $1.70 - + Add to cart
12	BOLT, FLANGE, (6X12) Part #: 95701-06012-08 Required per assembly: 4 ~~$2.67~~ $2.24 - + Add to cart
13	BOLT, FLANGE, (6X25) Part #: 95701-06025-08 Required per assembly: 2 $2.67 - + Add to cart
