Control Panel (1) replacement parts for Honda Power Equipment EB5000XK2

OEM Parts Honda Power Equipment Honda Power Equipment EB5000XK2 Control Panel (1)

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

01	TERMINAL, SET, GROUND Part #: 31428-Z22-000 Required per assembly: 1 Note: (Honda Code 7500507) $8.72 - + Add to cart
02	RUBBER, CONTROL Part #: 31462-Z22-000 Required per assembly: 1 Note: (Honda Code 7500515) ~~$279.86~~ $205.84 - + Add to cart
05	DIODE Part #: 31720-Z18-003 Required per assembly: 1 Note: (Honda Code 7500531) Not Available
06	BRACKET Part #: 32103-Z18-000 Required per assembly: 1 Note: (A) (Honda Code 7500549) $6.85 - + Add to cart
07	WIRE HARNESS ASSEMBLY Part #: 32150-Z22-E30 Required per assembly: 1 Note: (Honda Code 7500564) ~~$356.08~~ $261.90 - + Add to cart
08	WIRE, TERMINAL Part #: 32151-Z22-E30 Required per assembly: 1 Note: (A) (Honda Code 7500580) $9.24 - + Add to cart
09	WIRE, TERMINAL Part #: 32152-Z22-E30 Required per assembly: 1 Note: (B) (Honda Code 7500598) $10.15 - + Add to cart
10	WIRE, TERMINAL Part #: 32153-Z22-E30 Required per assembly: 1 Note: (C) (Honda Code 7500606) $10.11 - + Add to cart
11	WIRE, TERMINAL Part #: 32154-Z22-E30 Required per assembly: 1 Note: (D) (Honda Code 7500614) $11.45 - + Add to cart
12	RECEPTACLE Part #: 32330-Z03-C31 Required per assembly: 2 Note: (20A/125V) (Honda Code 6389076) ~~$49.28~~ $36.25 - + Add to cart
12	RECEPTACLE Part #: 32330-Z21-A31 Required per assembly: 2 Note: (20A/125V) Use from Frame SN 1039898. ~~$51.82~~ $38.12 - + Add to cart
12	RECEPTACLE ASSEMBLY Part #: 32330-Z07-C30 Required per assembly: 2 Note: (125V-20A) (Honda Code 6728315) (MATSUSHITA) ~~$56.90~~ $43.12 - + Add to cart
13	RECEPTACLE Part #: 32332-Z22-E31 Required per assembly: 1 Note: (30A-125V) Use from Frame SN 1039898 ~~$86.86~~ $63.88 - + Add to cart
13	RECPTL (30A/125V) Part #: 32332-ZB4-630 Required per assembly: 1 ~~$45.20~~ $34.25 - + Add to cart
14	RECEPTACLE Part #: 32334-Z22-A31 Required per assembly: 1 Note: (30A-125/250V) Use up to Frame SN 1039897 ~~$103.78~~ $78.64 - + Add to cart
14	RECEPTACLE Part #: 32334-ZA0-631 Required per assembly: 1 Note: (30A/125-250V) Use up to Frame SN 1039897. Not Available
15	PNL, CONTROL, NH105 Part #: 32345-Z22-E30ZA Required per assembly: 1 Note: (MAT BLACK) Use from Frame SN 1000178 (MAT BLACK) ~~$232.88~~ $168.75 - + Add to cart
15	PNL, CONTROL, NH105 Part #: 32345-Z22-E31ZA Required per assembly: 1 Note: (MAT BLACK) Use from Frame SN 1000178 (MAT BLACK) ~~$226.10~~ $166.30 - + Add to cart
16	CASE R280 Part #: 32356-Z22-010ZA Required per assembly: 1 Note: (POWER RED) Use from Frame SN 1000178 (POWER RED) ~~$138.58~~ $100.42 - + Add to cart
17	MARK, PANEL Part #: 32366-Z22-E30 Required per assembly: 1 Note: (Honda Code 7500655) ~~$93.52~~ $68.78 - + Add to cart
17	MARK, PANEL Part #: 32366-Z22-E31 Required per assembly: 1 Note: (Honda Code 8012429) ~~$99.88~~ $73.46 - + Add to cart
18	TIE, CABLE Part #: 32903-ZC8-N01 Required per assembly: 9 Note: (C) (Honda Code 6569651) (Optional) ~~$2.44~~ $1.98 - + Add to cart
19	CONTROL, UNIT, IDLE Part #: 34140-Z22-E31 Required per assembly: 1 Note: (Honda Code 7500705) ~~$241.10~~ $177.33 - + Add to cart
20	KNOB, ENGINE, SWITCH Part #: 35123-Z22-E31 Required per assembly: 1 Note: (Honda Code 7500713) $8.89 - + Add to cart
21	SWITCH, VOLT, CHANGE Part #: 35320-Z22-E31 Required per assembly: 1 Note: (Honda Code 7500721) ~~$105.38~~ $77.51 - + Add to cart
22	SWITCH, IDLE, CONTROL Part #: 35340-Z22-E31 Required per assembly: 1 Note: (Honda Code 8167959) ~~$38.26~~ $28.15 - + Add to cart
23	BUSH, CONTROL, KNOB Part #: 36106-892-003 Required per assembly: 1 Note: (Honda Code 0947473) $6.66 - + Add to cart
24	SWITCH, ENGINE, STOP Part #: 36110-ZB4-702 Required per assembly: 1 Note: (Honda Code 8823460) ~~$32.72~~ $24.99 - + Add to cart
25	BREAKER (19A) Part #: 38220-ZC2-E30 Required per assembly: 1 Note: (19A) (Honda Code 5367099) ~~$243.50~~ $184.46 - + Add to cart
27	PROTR, CIRCUIT, (20A) Part #: 38240-Z22-E31 Required per assembly: 1 Note: (20A) (Honda Code 9130709) ~~$85.90~~ $63.17 - + Add to cart
27	PROTR, CIRCUIT, (30A) Part #: 38241-Z22-E31 Required per assembly: 1 Note: (30A) (Honda Code 9130717) ~~$85.90~~ $63.17 - + Add to cart
28	PROTR, CIRCUIT, (30A) Part #: 38241-Z22-E31 Required per assembly: 1 Note: (30A) (Honda Code 9130717) ~~$85.90~~ $63.17 - + Add to cart
29	RELAY ASSEMBLY Part #: 38540-ZC2-E31 Required per assembly: 1 Note: (GFCI) (Honda Code 6308373) ~~$381.89~~ $358.65 - + Add to cart
30	MARK, ENGINE, SWITCH Part #: 87501-Z22-E30 Required per assembly: 1 Note: (Honda Code 7501109) ~~$20.50~~ $18.51 - + Add to cart
31	BOLT (6X12) (CT200) Part #: 90013-883-000 Required per assembly: 1 ~~$2.55~~ $2.13 - + Add to cart
32	SCREW, TRUSS, (6X18) Part #: 90101-Z15-000 Required per assembly: 4 Note: (6X18) (Honda Code 7496037) ~~$1.73~~ $0.91 - + Add to cart
33	BOLT, HEX., (6X28) Part #: 90111-Z22-000 Required per assembly: 1 Note: (6X28) (Honda Code 7496060) $3.49 - + Add to cart
34	NUT, HEX., (6MM) Part #: 90112-Z22-000 Required per assembly: 2 Note: (6MM) (Honda Code 7496078) ~~$2.11~~ $1.50 - + Add to cart
35	RETAINER (6MM) Part #: 90501-ZA7-640 Required per assembly: 1 Note: (6MM) (Honda Code 3479805) $4.01 - + Add to cart
36	STRAP, CABLE, (105MM) Part #: 90672-SB2-003 Required per assembly: 2 $7.51 - + Add to cart
37	TIE, CABLE Part #: 90672-ZB4-003 Required per assembly: 5 Note: (Honda Code 2279966) $6.08 - + Add to cart
38	TUBE, CORD Part #: 91406-ZB3-740 Required per assembly: 1 Note: (Honda Code 4618690) $5.16 - + Add to cart
39	TUBE (22X60) Part #: 91408-Z22-000 Required per assembly: 1 Note: (22X60) (Honda Code 7501299) $7.20 - + Add to cart
40	COLLAR, CONTROL, CASE Part #: 91551-Z15-000 Required per assembly: 4 Note: (Honda Code 7501315) $3.41 - + Add to cart
41	COLLAR, CONTROL, CASE Part #: 91551-Z22-000 Required per assembly: 1 Note: (Honda Code 7501323) $3.53 - + Add to cart
42	GROMMET, TUBE Part #: 91601-Z22-000 Required per assembly: 1 Note: (Honda Code 8844011) ~~$3.01~~ $2.71 - + Add to cart
42	GROMMET, TUBE Part #: 91601-ZB4-003 Required per assembly: 1 Note: (Honda Code 2280030) $4.22 - + Add to cart
43	SCREW, PAN, (4X6) Part #: 93500-04006-0G Required per assembly: 4 ~~$1.87~~ $1.24 - + Add to cart
44	SCREW, PAN, (5X18) Part #: 93500-05018-0G Required per assembly: 1 ~~$1.53~~ $0.65 - + Add to cart
45	SCREW-WASHER (5X12) Part #: 93892-05012-08 Required per assembly: 2 ~~$2.18~~ $1.70 - + Add to cart
45	SCREW-WASHER (5X14) Part #: 93892-05014-08 Required per assembly: 2 ~~$2.13~~ $1.63 - + Add to cart
46	SCREW, TAP, (4X16) Part #: 93911-24410 Required per assembly: 1 Not Available
47	NUT, FLANGE, (4MM) Part #: 94050-04000 Required per assembly: 10 ~~$2.26~~ $2.05 - + Add to cart
48	WASHER, PLAIN, (6MM) Part #: 94101-06800 Required per assembly: 1 Not Available
49	WASHER, SPRING, (6MM) Part #: 94111-06000 Required per assembly: 2 ~~$1.98~~ $1.31 - + Add to cart
50	BOLT, FLANGE, (6X12) Part #: 96001-06012-00 Required per assembly: 1 ~~$2.79~~ $2.67 - + Add to cart
52	BAND, HARNESS, (98MM) Part #: 90615-PN3-003 Required per assembly: 1 Note: (98MM) (NATURAL) (Honda Code 4708400) (Optional) $8.08 - + Add to cart
53	SCREW, PAN, (4X8) Part #: 93500-04008-0A Required per assembly: 1 ~~$1.91~~ $1.31 - + Add to cart
