Control Box replacement parts for Honda Power Equipment EB6500SX

OEM Parts Honda Power Equipment Honda Power Equipment EB6500SX Control Box

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

01	ALERT, UNIT, OIL Part #: 15520-ZB2-003 Required per assembly: 1 Note: (Honda Code 1496520) Not Available
02	CLIP, WIRE Part #: 30561-ZB4-000 Required per assembly: 1 Note: (Honda Code 2278844) $6.71 - + Add to cart
03	MARK, SWITCH, PANEL Part #: 31406-ZB4-E31 Required per assembly: 1 Note: (Honda Code 4025219) Not Available
03	MARK, SWITCH, PANEL Part #: 31406-ZB4-E32 Required per assembly: 1 Note: (Honda Code 5379771) Not Available
03	MARK, SWITCH, PANEL Part #: 31406-ZC2-831 Required per assembly: 1 Note: (EB-A) (Honda Code 3755238) Not Available
04	CASE, CONTROL, R280 Part #: 31425-ZB4-010ZD Note: (POWER RED) (Honda Code 7394190) (POWER RED) Not Available
05	TERMINAL, SET, GROUND Part #: 31428-899-840 Required per assembly: 1 Note: (Honda Code 3639192) ~~$23.08~~ $20.16 - + Add to cart
06	RUBBER, CONTROL Part #: 31462-ZB4-000 Required per assembly: 1 Note: (Honda Code 2279180) ~~$20.42~~ $18.45 - + Add to cart
07	GROMMET, A.C., WIRE Part #: 31481-ZB4-003 Required per assembly: 1 Note: (Honda Code 2304061) ~~$14.24~~ $13.88 - + Add to cart
08	GROMMET, MAIN, WIRE Part #: 31482-ZB4-003 Required per assembly: 1 Note: (Honda Code 2304079) ~~$16.68~~ $15.80 - + Add to cart
09	GROMMET, SWITCH, WIRE Part #: 31483-ZB4-003 Required per assembly: 1 Note: (Honda Code 2279206) ~~$12.16~~ $11.98 - + Add to cart
10	DIODE ASSEMBLY Part #: 31720-ZD1-E31 Required per assembly: 1 Note: (Honda Code 3751070) Not Available
11	CASE, FUSE, CONNECTOR Part #: 32114-230-003 Note: (Honda Code 2608537) $5.81 - + Add to cart
12	WIRE HARNESS ASSEMBLY Part #: 32150-ZD1-E33 Required per assembly: 1 Note: (EB-A) (Honda Code 5823984) Not Available
13	RECEPTACLE Part #: 32330-Z08-E42 Required per assembly: 1 Note: (20A/125V) (Honda Code 8941130) ~~$335.10~~ $246.46 - + Add to cart
15	RECPTL (30A/125V) Part #: 32332-ZB4-630 Required per assembly: 1 ~~$45.20~~ $34.25 - + Add to cart
16	RECEPTACLE Part #: 32334-ZA0-631 Required per assembly: 1 Note: (30A/125-250V) Use up to Frame SN 1039897. Not Available
18	BOX, CONTROL, R8 Part #: 32340-ZD1-E31ZA Note: (Honda Code 3753530) (BRIGHT RED) (BRIGHT RED) Not Available
18	BOX, CONTROL, R8 Part #: 32340-ZD1-E32ZA Note: (Honda Code 4751301) (BRIGHT RED) (BRIGHT RED) ~~$2,140.90~~ $2,098.08 - + Add to cart
18	BOX, CONTROL, R8 Part #: 32340-ZD1-E35ZA Note: (EB-A) (Honda Code 5823778) (BRIGHT RED) (BRIGHT RED) Not Available
18	BOX, CONTROL, R8 Part #: 32340-ZD1-E36ZA Required per assembly: 1 Note: (Honda Code 6672398) (BRIGHT RED) (BRIGHT RED) Not Available
19	PNL, CONTROL, R280 Part #: 32341-ZD1-E31ZB Note: (Honda Code 7394000) (POWER RED) (POWER RED) Not Available
20	MARK, A.C., OUT Part #: 31408-ZC2-E31 Required per assembly: 1 Note: (Honda Code 4025276) Not Available
20	MARK, A.C., OUT Part #: 31408-ZC2-E32 Required per assembly: 1 Note: (Honda Code 5367164) ~~$70.34~~ $53.29 - + Add to cart
20	MARK, A.C., OUT Part #: 32348-ZD1-E30 Required per assembly: 1 Note: (EB-A) (Honda Code 3751112) Not Available
21	SWITCH, COMBINATION Part #: 35100-ZB4-023 Required per assembly: 1 Note: (Honda Code 8756553) ~~$135.84~~ $102.91 - + Add to cart
22	KEY Part #: 35111-880-013 Required per assembly: 2 ~~$11.50~~ $11.42 - + Add to cart
23	THROTTLE, UNIT, AUTO Part #: 36210-ZB4-014 Required per assembly: 1 ~~$249.08~~ $183.20 - + Add to cart
24	SWITCH Part #: 36214-ZB4-023 Required per assembly: 1 ~~$41.28~~ $29.91 - + Add to cart
25	SWITCH, VOLT, CHANGE Part #: 36221-ZD1-E30 Required per assembly: 1 Note: (Honda Code 4751319) ~~$220.26~~ $166.88 - + Add to cart
25	SWITCH, VOLT, CHANGE Part #: 36221-899-630 Required per assembly: 1 Note: (Honda Code 1240050) ~~$212.66~~ $161.10 - + Add to cart
26	BREAKER (23A) Part #: 38220-ZD1-E30 Required per assembly: 1 Note: (23A) (Honda Code 3751179) Not Available
26	BREAKER (23A) Part #: 38220-ZD1-630 Required per assembly: 1 Note: (23A) (Honda Code 5367107) Not Available
27	PROTR, CIRCUIT, (20A) Part #: 38240-ZC6-E31 Required per assembly: 2 Note: (20A) (Honda Code 8269789) ~~$77.66~~ $57.12 - + Add to cart
27	PROTR, CIRCUIT, (20A) Part #: 38240-ZC2-E32 Required per assembly: 2 ~~$93.46~~ $68.74 - + Add to cart
28	PROTR, CIRCUIT, (30A) Part #: 38241-ZC2-E31 Required per assembly: 2 Note: (30A) (Honda Code 6387575) Not Available
28	PROTR, CIRCUIT, (30A) Part #: 38241-ZC6-E31 Required per assembly: 2 Note: (30A) (Honda Code 8269797) ~~$77.68~~ $57.13 - + Add to cart
29	MARK, ENGINE, SWITCH Part #: 87501-ZB4-A32 Required per assembly: 1 Note: (Honda Code 4532479) Not Available
29	MARK, ENGINE, SWITCH Part #: 87501-ZB4-630 Required per assembly: 1 Note: (EMS-A) (Honda Code 2279768) Not Available
30	MARK, AUTO-THROTTLE Part #: 87524-ZB4-E31 Required per assembly: 1 Note: (Honda Code 4025466) $8.42 - + Add to cart
30	MARK, AUTO-THROTTLE Part #: 87524-ZB4-830 Required per assembly: 1 Note: (EB-A) (Honda Code 2279792) Not Available
31	MARK, GROUND Part #: 87534-892-640 Required per assembly: 1 Note: (Honda Code 1106681) ~~$2.95~~ $2.62 - + Add to cart
32	BOLT, HEX., (6X28) Part #: 90011-899-840 Required per assembly: 1 Note: (6X28) (Honda Code 3479797) $3.26 - + Add to cart
33	SCREW, GLOVE, BOX Part #: 90101-692-000 Required per assembly: 1 Note: (Honda Code 0782086) ~~$2.33~~ $1.96 - + Add to cart
34	RETAINER (6MM) Part #: 90501-ZA7-640 Required per assembly: 1 Note: (6MM) (Honda Code 3479805) $4.01 - + Add to cart
35	TIE, CABLE Part #: 90672-ZB4-003 Required per assembly: 3 Note: (Honda Code 2279966) $6.08 - + Add to cart
36	TUBE, CORD Part #: 91406-ZB4-000 Required per assembly: 1 Note: (Honda Code 2280022) $11.49 - + Add to cart
37	GROMMET, TUBE Part #: 91601-ZB4-003 Required per assembly: 1 Note: (Honda Code 2280030) $4.22 - + Add to cart
38	SCREW, PAN, (3X6) Part #: 93500-03006-0H Required per assembly: 2 ~~$1.87~~ $1.24 - + Add to cart
39	SCREW, PAN, (4X6) Part #: 93500-04006-0H Required per assembly: 2 ~~$1.95~~ $1.35 - + Add to cart
40	SCREW-WASHER (5X12) Part #: 93892-05012-08 Required per assembly: 1 ~~$2.18~~ $1.70 - + Add to cart
41	SCREW-WASHER (4X10) Part #: 93893-04010-08 Required per assembly: 1 ~~$2.37~~ $1.85 - + Add to cart
42	SCREW-WASHER (4X12) Part #: 93893-04012-08 Required per assembly: 1 ~~$2.37~~ $1.98 - + Add to cart
43	NUT, HEX., (6MM) Part #: 94001-06390-0S Required per assembly: 2 Note: (6MM) (Honda Code 1240720) ~~$2.61~~ $2.15 - + Add to cart
44	NUT, FLANGE, (4MM) Part #: 94050-04000 Required per assembly: 8 ~~$2.26~~ $2.05 - + Add to cart
45	WASHER, PLAIN, (6MM) Part #: 94101-06800 Required per assembly: 1 Not Available
46	WASHER, SPRING, (6MM) Part #: 94111-06800 Required per assembly: 2 ~~$2.17~~ $1.57 - + Add to cart
47	BOLT, FLANGE, (6X40) Part #: 95701-06040-08 Required per assembly: 3 ~~$2.87~~ $2.52 - + Add to cart
48	FUSE B (10A) Part #: 98200-21000 Required per assembly: 1 ~~$1.98~~ $1.31 - + Add to cart
49	RELAY ASSEMBLY Part #: 38540-ZC2-E31 Required per assembly: 1 Note: (GFCI) (Honda Code 6308373) ~~$381.89~~ $358.65 - + Add to cart
49	RELAY ASSEMBLY Part #: 38540-ZC2-E31 Required per assembly: 1 Note: (GFCI) (Honda Code 6308373) ~~$381.89~~ $358.65 - + Add to cart
50	RECEPTACLE Part #: 32330-Z03-C31 Required per assembly: 1 Note: (20A/125V) (Honda Code 6389076) ~~$49.28~~ $36.25 - + Add to cart
51	BOLT (6X12) (CT200) Part #: 90013-883-000 Required per assembly: 1 ~~$2.55~~ $2.13 - + Add to cart
52	CLIP, WIRE, HARNESS Part #: 91406-671-000 Required per assembly: 1 $17.78 - + Add to cart
53	TUBE, CORD Part #: 91406-ZB3-740 Required per assembly: 1 Note: (Honda Code 4618690) $5.16 - + Add to cart
