Honda Power Equipment EG2200Z - Points

COVER, BREAKER

Part #: 30211-883-000 Required per assembly: 1 Note: (Honda Code 0636720)

CONDENSER

Part #: 30251-883-003 Required per assembly: 1 Note: (Honda Code 1002237)

POINTS ASSEMBLY

Part #: 30280-883-005 Required per assembly: 1 Note: (Honda Code 0636746)

GROMMET, WIRE

Part #: 30563-ZA5-300 Required per assembly: 1 Note: (Honda Code 1267897)

GROMMET, WIRE

Part #: 30564-ZA5-000 Required per assembly: 1 Note: (Honda Code 1267913)

TUBE, IGN, RUB

Part #: 30565-728-000 Required per assembly: 1 Note: (Honda Code 0905984)

CAP ASSEMBLY

Part #: 30700-865-013 Required per assembly: 1 Note: (Honda Code 3637048)

Not Available

COIL, ASSEMBLY, BACK-UP

Part #: 31511-ZA5-003 Required per assembly: 1 Note: (Honda Code 1267905)

Not Available

BOLT, FLANGE, (6X32)

Part #: 90017-883-000 Required per assembly: 4

BOLT, FLANGE, (5X10)

Part #: 90019-883-000 Required per assembly: 3

SCREW-WASHER (5X12)

Part #: 90051-883-000 Required per assembly: 1 Note: (5X12) (Honda Code 0649699)
