Control Box (2) replacement parts for Honda Power Equipment EL5000

OEM Parts Honda Power Equipment Honda Power Equipment EL5000 Control Box (2)

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

01	BOX, CONTROL, NH105 Part #: 31400-ZA0-733ZA Note: (Honda Code 2080943) (MAT BLACK) (MAT BLACK) Not Available
02	PANEL, FR. Part #: 31402-ZA0-731 Required per assembly: 1 Note: (Honda Code 1317536) Not Available
03	COVER Part #: 31403-ZA0-014 Required per assembly: 1 Note: (Honda Code 4743340) Not Available
05	MARK Part #: 31405-ZA0-731 Required per assembly: 1 Note: (Honda Code 1355155) Not Available
06	MARK, SWITCH, PANEL Part #: 31406-ZA0-731 Required per assembly: 1 Note: (Honda Code 1355163) Not Available
07	TERMINAL, BREAKER Part #: 31414-880-000 Required per assembly: 2 Note: (Honda Code 0475152) $18.10 $13.33 - + Add to cart
08	SUPPORT, BREAKER Part #: 31415-ZA0-800 Required per assembly: 1 Note: (Honda Code 1280627) $11.48 $8.82 - + Add to cart
09	PLATE, GROUND Part #: 31429-ZA0-003 Required per assembly: 1 Note: (Honda Code 1317577) Not Available
11	STACK, DIODE, (2.7A) Part #: 06317-ZA0-000 Required per assembly: 1 $111.08 $80.53 - + Add to cart
12	RECEPTACLE ASSEMBLY Part #: 32330-Z07-C30 Note: (125V-20A) (Honda Code 6728315) (MATSUSHITA) $56.90 $43.14 - + Add to cart
12	RECEPTACLE ASSEMBLY Part #: 32330-Z07-C30 Required per assembly: 1 Note: (125V-20A) (Honda Code 6728315) (MATSUSHITA) $56.90 $43.14 - + Add to cart
15	BULB, DASH, (24V-2W) Part #: 34909-880-000 Required per assembly: 1 Note: (24V2W) (Honda Code 0356600) (Optional) Not Available
16	RELAY, ALERT Part #: 35520-ZA0-003 Required per assembly: 1 Note: (Honda Code 1280841) $310.86 $228.75 - + Add to cart
18	CONTROL, UNIT, IDLE Part #: 36210-ZA0-003 Required per assembly: 1 Note: (Honda Code 1280908) $294.28 $216.56 - + Add to cart
19	SWITCH, IDLE, CONTROL Part #: 36214-ZA0-800 Required per assembly: 1 Note: (Honda Code 1298827) Not Available
20	STAY, SWITCH Part #: 36216-ZA0-003 Required per assembly: 1 Note: (Honda Code 1317585) Not Available
21	SOCKET, PILOT, LAMP Part #: 37560-ZA0-003 Required per assembly: 1 Note: (Honda Code 8018590) $34.80 $25.61 - + Add to cart
22	GROMMET, TOP, COVER Part #: 64315-GB4-000 Required per assembly: 1 $3.11 $2.90 - + Add to cart
23	MARK, GROUND Part #: 87534-892-640 Required per assembly: 1 Note: (Honda Code 1106681) $2.95 $2.74 - + Add to cart
24	BOLT, HEX., (8MM) Part #: 90103-ZA0-003 Required per assembly: 1 Note: (8MM) (Honda Code 1317593) Not Available
26	SCREW, PAN, (3X8) Part #: 93500-03008-0H Required per assembly: 2 $1.79 $1.65 - + Add to cart
27	SCREW, PAN, (5X10) Part #: 93500-05010-3J Required per assembly: 2 Note: (5X10) (NOT AVAILABLE) (Honda Code 0703033) $1.99 $1.84 - + Add to cart
28	SCREW, PAN, (6X12) Part #: 93500-06012-3J Required per assembly: 2 Note: (6X12) (Honda Code 1355346) $2.73 $2.54 - + Add to cart
29	SCREW-WASHER (4X8) Part #: 93891-04008-08 Required per assembly: 7 $2.01 $1.86 - + Add to cart
30	SCREW-WASHER (5X10) Part #: 93892-05010-08 Required per assembly: 2 $2.18 $2.02 - + Add to cart
31	NUT, HEX., (4MM) Part #: 94001-04080-0S Required per assembly: 14 $2.07 $1.91 - + Add to cart
32	WASHER, PLAIN, (3MM) Part #: 94101-03800 Required per assembly: 2 $2.02 $1.87 - + Add to cart
33	WASHER, SPRING, (3MM) Part #: 94111-03800 Required per assembly: 2 $1.72 $1.58 - + Add to cart
34	WASHER, SPRING, (4MM) Part #: 94111-04800 Required per assembly: 14 $2.02 $1.87 - + Add to cart
35	WASHER, SPRING, (5MM) Part #: 94111-05800 Required per assembly: 2 $2.17 $2.00 - + Add to cart
36	WASHER, SPRING, (6MM) Part #: 94111-06800 Required per assembly: 2 $2.17 $2.00 - + Add to cart
37	WASHER, SPRING, (8MM) Part #: 94111-08000 Required per assembly: 1 $2.02 $1.87 - + Add to cart
