Control replacement parts for Honda Power Equipment EM3500X

OEM Parts Honda Power Equipment Honda Power Equipment EM3500X Control

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

02	ARM, GOVERNOR Part #: 16551-ZE2-000 Required per assembly: 1 Note: (Honda Code 2026003) $17.64 $12.98 - + Add to cart
03	ROD, GOVERNOR Part #: 16555-ZE2-000 Required per assembly: 1 Note: (Honda Code 2026011) $5.06 $4.73 - + Add to cart
04	SPRING (L=145.0MM) Part #: 16561-ZE2-000 Required per assembly: 1 Note: (L=145.0MM) (Honda Code 2026029) (WIRE DIAMETER 1.0MM) $5.50 $5.05 - + Add to cart
05	SPRING Part #: 16562-ZE2-000 Required per assembly: 1 Note: (Honda Code 2026037) $4.78 $4.52 - + Add to cart
06	CONTROL ASSEMBLY Part #: 16570-ZE2-701 Required per assembly: 1 Note: (Honda Code 4024816) $17.78 $15.25 - + Add to cart
07	SPRING Part #: 16584-883-300 Required per assembly: 1 Note: (Honda Code 0636431) $4.78 $4.52 - + Add to cart
08	BOLT (6X12) (CT200) Part #: 90013-883-000 Required per assembly: 2 $2.55 $2.36 - + Add to cart
09	BOLT, GOVERNOR, ARM Part #: 90015-ZE5-010 Required per assembly: 1 Note: (Honda Code 2418671) $3.22 - + Add to cart
11	BOLT, HEX., (6X22) Part #: 92101-06022-0A Required per assembly: 1 $2.55 $2.36 - + Add to cart
12	SCREW, PAN, (5X35) Part #: 93500-05035-0A Required per assembly: 1 $2.13 $1.97 - + Add to cart
13	NUT, FLANGE, (6MM) Part #: 94050-06000 Required per assembly: 1 $1.73 $1.59 - + Add to cart
