Control Panel (1) replacement parts for Honda Power Equipment EM5000SXK2

OEM Parts Honda Power Equipment Honda Power Equipment EM5000SXK2 Control Panel (1)

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

01	TERMINAL Part #: 31408-880-000 Required per assembly: 1 Note: (+) (Honda Code 0475103) ~~$44.90~~ $34.01 - + Add to cart
02	TERMINAL Part #: 31409-880-000 Required per assembly: 1 Note: (-) (Honda Code 0475111) ~~$44.90~~ $34.01 - + Add to cart
03	TERMINAL, SET, GROUND Part #: 31428-Z22-000 Required per assembly: 1 Note: (Honda Code 7500507) $8.72 - + Add to cart
04	RUBBER, CONTROL Part #: 31462-Z22-000 Required per assembly: 1 Note: (Honda Code 7500515) ~~$279.86~~ $205.84 - + Add to cart
08	BRACKET Part #: 32103-Z18-000 Required per assembly: 1 Note: (A) (Honda Code 7500549) $6.85 - + Add to cart
09	WIRE HARNESS ASSEMBLY Part #: 32150-Z22-A30 Required per assembly: 1 Note: (Honda Code 7677263) ~~$401.16~~ $295.06 - + Add to cart
10	WIRE, TERMINAL Part #: 32151-Z22-E30 Required per assembly: 1 Note: (A) (Honda Code 7500580) $9.24 - + Add to cart
11	WIRE, TERMINAL Part #: 32152-Z22-E30 Required per assembly: 1 Note: (B) (Honda Code 7500598) $10.15 - + Add to cart
12	WIRE, TERMINAL Part #: 32153-Z22-E30 Required per assembly: 1 Note: (C) (Honda Code 7500606) $10.11 - + Add to cart
13	WIRE, TERMINAL Part #: 32154-Z22-E30 Required per assembly: 1 Note: (D) (Honda Code 7500614) $11.45 - + Add to cart
14	RECEPTACLE Part #: 32330-Z21-A31 Required per assembly: 2 Note: (20A/125V) Use from Frame SN 1039898. ~~$51.82~~ $38.12 - + Add to cart
14	RECEPTACLE ASSEMBLY Part #: 32330-Z07-C30 Required per assembly: 2 Note: (125V-20A) (Honda Code 6728315) (MATSUSHITA) ~~$56.90~~ $43.12 - + Add to cart
15	RECEPTACLE Part #: 32332-Z22-E31 Required per assembly: 1 Note: (30A-125V) Use from Frame SN 1039898 ~~$86.86~~ $63.88 - + Add to cart
15	RECPTL (30A/125V) Part #: 32332-ZB4-630 Required per assembly: 1 ~~$45.20~~ $34.25 - + Add to cart
16	RECEPTACLE Part #: 32334-Z22-A31 Required per assembly: 1 Note: (30A-125/250V) Use up to Frame SN 1039897 ~~$103.78~~ $78.64 - + Add to cart
16	RECEPTACLE Part #: 32334-ZA0-631 Required per assembly: 1 Note: (30A/125-250V) Use up to Frame SN 1039897. Not Available
17	PNL, CONTROL, NH105 Part #: 32345-Z22-A30ZA Required per assembly: 1 Note: (MAT BLACK) (Honda Code 7677289) (MAT BLACK) ~~$233.04~~ $171.41 - + Add to cart
18	CASE R280 Part #: 32356-Z22-010ZA Required per assembly: 1 Note: (POWER RED) Use from Frame SN 1000178 (POWER RED) ~~$138.58~~ $100.42 - + Add to cart
19	MARK, PANEL Part #: 32366-Z22-A30 Required per assembly: 1 Note: (Honda Code 7677339) ~~$101.12~~ $74.38 - + Add to cart
20	TIE, CABLE Part #: 32903-ZC8-N01 Required per assembly: 2 Note: (C) (Honda Code 6569651) (Optional) ~~$2.44~~ $1.98 - + Add to cart
21	CONTROL, UNIT, ENGINE Part #: 34100-Z22-A31 Required per assembly: 1 Note: (Honda Code 7677479) ~~$244.86~~ $185.48 - + Add to cart
22	CONTROL, UNIT, IDLE Part #: 34140-Z22-E31 Required per assembly: 1 Note: (Honda Code 7500705) ~~$241.10~~ $177.33 - + Add to cart
23	SWITCH, COMBINATION Part #: 35100-Z22-013 Required per assembly: 1 Not Available
24	KEY Part #: 35111-880-013 Required per assembly: 2 $11.42 - + Add to cart
25	SWITCH, VOLT, CHANGE Part #: 35320-Z22-E31 Required per assembly: 1 Note: (Honda Code 7500721) ~~$105.38~~ $77.51 - + Add to cart
26	SWITCH, IDLE, CONTROL Part #: 35340-Z22-E31 Required per assembly: 1 Note: (Honda Code 8167959) ~~$38.26~~ $28.15 - + Add to cart
27	SENSOR, TEMPERATURE Part #: 35673-ZF6-F42 Required per assembly: 1 Note: (Honda Code 8634008) ~~$52.34~~ $38.49 - + Add to cart
28	BRACKET, FUSE Part #: 38217-Z22-A30 Required per assembly: 1 Note: (Honda Code 7677537) $9.31 - + Add to cart
29	BREAKER (19A) Part #: 38220-ZR7-F21 Required per assembly: 1 Note: (19A) (Honda Code 7677545) ~~$106.10~~ $78.04 - + Add to cart
30	PROTR, CIRCUIT, (15A) Part #: 38240-ZA8-710 Required per assembly: 1 Note: (15A) (Honda Code 7677578) ~~$23.22~~ $20.24 - + Add to cart
32	PROTR, CIRCUIT, (20A) Part #: 38240-Z22-E31 Required per assembly: 1 Note: (20A) (Honda Code 9130709) ~~$85.90~~ $63.17 - + Add to cart
32	PROTR, CIRCUIT, (30A) Part #: 38241-Z22-E31 Required per assembly: 1 Note: (30A) (Honda Code 9130717) ~~$85.90~~ $63.17 - + Add to cart
33	PROTR, CIRCUIT, (30A) Part #: 38241-Z22-E31 Required per assembly: 1 Note: (30A) (Honda Code 9130717) ~~$85.90~~ $63.17 - + Add to cart
34	LENS, PROTECTOR Part #: 38250-ZA8-701 Required per assembly: 1 Note: (Honda Code 1888676) ~~$19.10~~ $17.55 - + Add to cart
35	MARK, ENGINE, SWITCH Part #: 87501-Z22-A30 Required per assembly: 1 Note: (Honda Code 7678246) $10.47 - + Add to cart
36	BOLT (6X12) (CT200) Part #: 90013-883-000 Required per assembly: 2 ~~$2.55~~ $2.13 - + Add to cart
37	SCREW, TRUSS, (6X18) Part #: 90101-Z15-000 Required per assembly: 4 Note: (6X18) (Honda Code 7496037) ~~$1.73~~ $0.91 - + Add to cart
38	BOLT, HEX., (6X28) Part #: 90111-Z22-000 Required per assembly: 1 Note: (6X28) (Honda Code 7496060) $3.49 - + Add to cart
39	NUT, HEX., (6MM) Part #: 90112-Z22-000 Required per assembly: 2 Note: (6MM) (Honda Code 7496078) ~~$2.11~~ $1.50 - + Add to cart
40	WASHER (4MM) Part #: 90401-ZR4-F30 Required per assembly: 2 Note: (4MM) (Honda Code 7678352) ~~$2.17~~ $1.52 - + Add to cart
41	RETAINER (6MM) Part #: 90501-ZA7-640 Required per assembly: 1 Note: (6MM) (Honda Code 3479805) $4.01 - + Add to cart
42	BAND, WIRE, (95MM) Part #: 90650-KV6-003 Required per assembly: 1 $4.61 - + Add to cart
43	CLIP, HARN, (6MM) Part #: 90654-SA4-003 Required per assembly: 1 ~~$1.32~~ $0.31 - + Add to cart
44	CLIP, WIRE, HARNESS Part #: 90658-SA0-003 Required per assembly: 1 $11.69 - + Add to cart
45	STRAP, CABLE, (105MM) Part #: 90672-SB2-003 Required per assembly: 2 $7.51 - + Add to cart
46	TIE, CABLE Part #: 90672-ZB4-003 Required per assembly: 5 Note: (Honda Code 2279966) $6.08 - + Add to cart
47	TUBE, CORD Part #: 91406-ZB3-740 Required per assembly: 1 Note: (Honda Code 4618690) $5.16 - + Add to cart
48	TUBE (22X60) Part #: 91408-Z22-000 Required per assembly: 1 Note: (22X60) (Honda Code 7501299) $7.20 - + Add to cart
49	COLLAR, CONTROL, CASE Part #: 91551-Z15-000 Required per assembly: 4 Note: (Honda Code 7501315) $3.41 - + Add to cart
50	COLLAR, CONTROL, CASE Part #: 91551-Z22-000 Required per assembly: 1 Note: (Honda Code 7501323) $3.53 - + Add to cart
51	CLIP Part #: 91565-SH3-003 Required per assembly: 1 Note: (BROWN) (Honda Code 2787489) $7.61 - + Add to cart
53	SCREW, PAN, (3X16) Part #: 93500-03016-0G Required per assembly: 2 Note: (3X16) (Honda Code 7678451) ~~$1.80~~ $1.02 - + Add to cart
54	SCREW, PAN, (5X18) Part #: 93500-05018-0G Required per assembly: 1 ~~$1.53~~ $0.65 - + Add to cart
55	SCREW-WASHER (5X14) Part #: 93892-05014-08 Required per assembly: 4 ~~$2.13~~ $1.63 - + Add to cart
57	SCREW, TAP, (4X16) Part #: 93911-24410 Required per assembly: 1 Not Available
58	NUT, FLANGE, (4MM) Part #: 94050-04000 Required per assembly: 10 ~~$2.26~~ $2.05 - + Add to cart
59	WASHER, PLAIN, (6MM) Part #: 94101-06800 Required per assembly: 1 Not Available
60	WASHER, PLAIN, (8MM) Part #: 94102-08800 Required per assembly: 1 ~~$1.98~~ $1.31 - + Add to cart
61	WASHER, SPRING, (6MM) Part #: 94111-06000 Required per assembly: 2 ~~$1.98~~ $1.31 - + Add to cart
62	FUSE, BLADE, (10A) Part #: 98200-31000 Required per assembly: 1 ~~$2.33~~ $1.81 - + Add to cart
63	TIE, CABLE Part #: 32903-ZC8-N01 Required per assembly: 1 Note: (C) (Honda Code 6569651) (Optional) ~~$2.44~~ $1.98 - + Add to cart
