Control Panel (2) replacement parts for Honda Power Equipment EM5000SXK3

OEM Parts Honda Power Equipment Honda Power Equipment EM5000SXK3 Control Panel (2)

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

01	TERMINAL Part #: 31408-880-000 Required per assembly: 1 Note: (+) (Honda Code 0475103) $44.90 $33.05 - + Add to cart
02	TERMINAL Part #: 31409-880-000 Required per assembly: 1 Note: (-) (Honda Code 0475111) $44.90 $34.03 - + Add to cart
03	TERMINAL, SET, GROUND Part #: 31428-Z22-000 Required per assembly: 1 Note: (Honda Code 7500507) $8.38 $6.66 - + Add to cart
04	RUB, CONTROL, PANEL Part #: 31462-Z23-F10 Required per assembly: 1 $10.00 $7.87 - + Add to cart
05	SUB-WIRE ASSEMBLY Part #: 32101-Z23-F20 Required per assembly: 4 $7.98 $6.37 - + Add to cart
07	RECEPTACLE Part #: 32330-Z21-A31 Required per assembly: 2 Note: (20A/125V) Use from Frame SN 1039898. $51.82 $38.14 - + Add to cart
08	RECEPTACLE Part #: 32334-Z22-A31 Required per assembly: 1 Note: (30A-125/250V) Use up to Frame SN 1039897 $103.78 $76.37 - + Add to cart
09	RECEPTACLE Part #: 32332-Z22-E31 Required per assembly: 1 Note: (30A-125V) Use from Frame SN 1039898 $86.86 $63.92 - + Add to cart
10	PNL, CONTROL, R280 Part #: 32345-Z23-F20ZB Note: (POWER RED) $289.50 $213.03 - + Add to cart
12	MARK, PANEL Part #: 32366-Z23-F20 Required per assembly: 1 $93.70 $68.95 - + Add to cart
13	CONNECTOR (12P) Part #: 32395-Z30-S32 Required per assembly: 1 $113.48 $83.51 - + Add to cart
14	TIE, CABLE Part #: 32903-Z22-000 Required per assembly: 1 $2.83 $2.62 - + Add to cart
15	CONTROL, UNIT, ENGINE Part #: 34100-Z23-F21 Required per assembly: 1 $220.86 $162.53 - + Add to cart
16	SWITCH, COMBINATION Part #: 35100-Z1C-D22 Required per assembly: 1 $91.22 $70.85 - + Add to cart
17	KEY Part #: 35110-Z5T-W01 Required per assembly: 1 $11.18 $9.79 - + Add to cart
18	KEY ASSEMBLY Part #: 35110-Z5T-W11 $10.52 $8.81 - + Add to cart
19	SWITCH, VOLT, CHANGE Part #: 35320-Z23-F21 Required per assembly: 1 $108.98 $82.59 - + Add to cart
20	SENSOR ASSEMBLY Part #: 35694-Z23-003 Required per assembly: 1 $101.78 $77.14 - + Add to cart
21	SWITCH Part #: 36214-Z11-A01 Required per assembly: 1 $24.08 $17.72 - + Add to cart
22	BREAKER (21A) Part #: 38220-Z31-D41 Required per assembly: 1 $171.44 $126.16 - + Add to cart
24	PROTR, CIRCUIT, (30A) Part #: 38241-Z23-F20 Required per assembly: 2 $26.64 $19.60 - + Add to cart
24	PROTR, CIRCUIT, (20A) Part #: 38240-Z23-F20 Required per assembly: 1 $91.82 $67.57 - + Add to cart
25	PROTR, CIRCUIT, (15A) Part #: 38240-ZA8-710 Required per assembly: 1 Note: (15A) (Honda Code 7677578) $23.22 $17.08 - + Add to cart
26	LENS, PROTECTOR Part #: 38250-ZA8-701 Required per assembly: 1 Note: (Honda Code 1888676) $19.10 $14.05 - + Add to cart
27	COVER (LOWER) Part #: 50361-Z23-F10 Required per assembly: 1 $51.06 $37.95 - + Add to cart
28	LOCK, PLATE, COVER Part #: 50362-Z23-F10 Required per assembly: 1 $10.06 $7.91 - + Add to cart
29	BOLT, HEX., (6X28) Part #: 90111-Z22-000 Required per assembly: 1 Note: (6X28) (Honda Code 7496060) $3.33 - + Add to cart
30	NUT, HEX., (6MM) Part #: 90112-Z22-000 Required per assembly: 2 Note: (6MM) (Honda Code 7496078) $2.11 $1.96 - + Add to cart
31	BOLT, SOCKET, (8X22) Part #: 90128-MEM-630 Required per assembly: 4 $3.11 $2.90 - + Add to cart
32	BOLT Part #: 90163-Z23-F10 Required per assembly: 1 $3.29 $3.06 - + Add to cart
33	WASHER (4MM) Part #: 90401-ZR4-F30 Required per assembly: 2 Note: (4MM) (Honda Code 7678352) $2.17 $2.00 - + Add to cart
34	WASHER, WAVE, (12MM) Part #: 90444-397-000 Required per assembly: 1 Note: (12MM) (Honda Code 2037398) $5.34 $4.93 - + Add to cart
35	RETAINER (6MM) Part #: 90501-ZA7-640 Required per assembly: 1 Note: (6MM) (Honda Code 3479805) $3.70 - + Add to cart
36	BAND, WIRE, (95MM) Part #: 90650-KV6-003 Required per assembly: 1 $4.43 $4.03 - + Add to cart
37	CLIP, WIRE, HARNESS Part #: 90681-763-A01 Required per assembly: 1 $10.56 $8.27 - + Add to cart
38	CLIP (145MM) Part #: 91541-S0A-003 $4.96 $4.51 - + Add to cart
40	SCREW, PAN, (3X16) Part #: 93500-03016-0G Required per assembly: 2 Note: (3X16) (Honda Code 7678451) $1.80 $1.67 - + Add to cart
41	SCREW, PAN, (4X6) Part #: 93500-04006-0G Required per assembly: 2 $1.87 $1.73 - + Add to cart
42	SCREW-WASHER (5X14) Part #: 93892-05014-08 Required per assembly: 2 $2.13 $1.97 - + Add to cart
43	NUT, FLANGE, (4MM) Part #: 94050-04000 Required per assembly: 8 $2.26 $2.05 - + Add to cart
44	NUT, FLANGE, (6MM) Part #: 94050-06000 Required per assembly: 2 $1.73 $1.59 - + Add to cart
45	WASHER, PLAIN, (6MM) Part #: 94101-06800 Required per assembly: 1 Not Available
46	WASHER, SPRING, (6MM) Part #: 94111-06000 Required per assembly: 2 $1.98 $1.83 - + Add to cart
47	BOLT, FLANGE, (6X10) Part #: 95701-06010-07 Required per assembly: 1 $2.63 $2.44 - + Add to cart
48	BOLT, FLANGE, (6X14) Part #: 95701-06014-00 Required per assembly: 1 $2.04 $1.88 - + Add to cart
