Honda Power Equipment EN2500 - Control

CONTROL ASSEMBLY

Part #: 16500-ZL8-D00 Required per assembly: 1 Note: (Honda Code 7784390)

Not Available

ARM, GOVERNOR

Part #: 16551-ZL8-010 Required per assembly: 1 Note: (Honda Code 8867475)

ARM, GOVERNOR

Part #: 16551-ZL8-010 Required per assembly: 1 Note: (Honda Code 8867475)

ROD, GOVERNOR

Part #: 16555-ZL8-000 Required per assembly: 1 Note: (Honda Code 5611140)

SPRING, GOVERNOR

Part #: 16561-ZL8-810 Required per assembly: 1 Note: (Honda Code 5611165)

SPRING

Part #: 16562-ZL8-000 Required per assembly: 1 Note: (Honda Code 5611173)

LEVER, CONTROL

Part #: 16571-ZL8-850 Required per assembly: 1 Note: (Honda Code 5611207)

SPRING, LEVER

Part #: 16574-ZE1-000 Required per assembly: 1 Note: (Honda Code 1427384)

WASHER

Part #: 16575-ZL8-000 Required per assembly: 1 Note: (Honda Code 5611215)

SPACER

Part #: 16578-ZE1-000 Required per assembly: 1 Note: (Honda Code 1427400)

BASE, CONTROL

Part #: 16580-ZL8-000 Required per assembly: 1 Note: (Honda Code 5611256)

SPRING

Part #: 16584-883-300 Required per assembly: 1 Note: (Honda Code 0636431)

ROD, CHOKE, CONTROL

Part #: 16611-ZL8-000 Required per assembly: 1 Note: (Honda Code 5611272)

GROMMET, CHOKE, ROD

Part #: 16613-893-000 Required per assembly: 1

LEVER, STOP

Part #: 16631-ZL8-850 Required per assembly: 1 Note: (Honda Code 5611280)

PLATE, SIDE

Part #: 19612-ZL8-000 Required per assembly: 1 Note: (Honda Code 5656020)

Not Available

PLATE, SIDE

Part #: 19612-Z0L-000 Required per assembly: 1 Note: (Honda Code 8311326)

SWITCH, ENGINE, STOP

Part #: 35120-ZL8-003 Required per assembly: 1 Note: (N.O) (Honda Code 5611520)

BOLT (6X12) (CT200)

Part #: 90013-883-000 Required per assembly: 1

BOLT (6X14) (CT200)

Part #: 90014-952-000 Required per assembly: 2

BOLT, GOVERNOR, ARM

Part #: 90015-ZE5-010 Required per assembly: 1 Note: (Honda Code 2418671)

SCREW, ADJUSTING

Part #: 90031-ZL8-D00 Required per assembly: 1 Note: (Honda Code 5727037)

NUT, SELF-LOCK, (6MM)

Part #: 90114-SA0-000 Required per assembly: 1

WASHER, WHEEL, (6MM)

Part #: 90563-355-000 Required per assembly: 1

SCREW-WASHER (4X12)

Part #: 93892-04012-00 Required per assembly: 1

NUT, FLANGE, (6MM)

Part #: 94050-06000 Required per assembly: 1

WASHER, PLAIN, (4MM)

Part #: 94103-04000 Required per assembly: 1
