Honda Power Equipment EP2500CX1 - Control Panel (Ach,Ah)

TERMINAL, SET, GROUND

Part #: 31428-ZR4-T61 Required per assembly: 1 Note: (Honda Code 8749368)

BRACKET

Part #: 32103-Z15-000 Required per assembly: 1 Note: (Honda Code 8749384)

WIRE HARNESS ASSEMBLY

Part #: 32150-Z15-A30 Note: (Honda Code 8749392) (CX-AH)

CLIP, B, HARNESS

Part #: 32172-GJ1-003 Required per assembly: 1

SUB-WIRE ASSEMBLY

Part #: 32196-Z15-000 Required per assembly: 1 Note: (A) (Honda Code 8749400)

SUB-WIRE ASSEMBLY

Part #: 32197-Z15-000 Required per assembly: 1 Note: (B) (Honda Code 8749426)

RECEPTACLE ASSEMBLY

Part #: 32330-Z07-C30 Note: (125V-20A) (Honda Code 6728315) (MATSUSHITA)

RECEPTACLE

Part #: 32330-Z21-A31 Required per assembly: 1 Note: (20A/125V) Use from Frame SN 1039898.

PANEL, CONTROL

Part #: 32345-Z15-A30 Required per assembly: 1 Note: (CX-AH) (Honda Code 8749434)

PANEL, ENGINE, SWITCH

Part #: 32353-Z15-S60 Required per assembly: 1 Note: (Honda Code 8598765)

CASE *R280R*

Part #: 32356-Z15-S60ZA Note: (Honda Code 8401341) (POWER RED)
(POWER RED)

MARK, PANEL

Part #: 32366-Z15-A30 Required per assembly: 1 Note: (CX-A) (Honda Code 8749442)

TIE, CABLE

Part #: 32903-ZC8-N01 Required per assembly: 1 Note: (C) (Honda Code 6569651) (Optional)

SWITCH, ENGINE, STOP

Part #: 35120-Z11-E01 Required per assembly: 1 Note: (Honda Code 7777022)

BREAKER (20A)

Part #: 38220-ZR5-D31 Required per assembly: 1 Note: (20A) (Honda Code 8749475)

Not Available

BOLT (6X12) (CT200)

Part #: 90013-883-000 Required per assembly: 1

BOLT, HEX., (6X20)

Part #: 90101-ZR4-T60 Required per assembly: 1 Note: (6X20) (Honda Code 8749616)

SCREW, TRUSS, (6X18)

Part #: 90101-Z15-000 Required per assembly: 5 Note: (6X18) (Honda Code 7496037)

TIE, CABLE

Part #: 90672-ZB4-003 Required per assembly: 1 Note: (Honda Code 2279966)

COLLAR, CONTROL, CASE

Part #: 91551-Z15-000 Required per assembly: 5 Note: (Honda Code 7501315)

SCREW, PAN, (3X5)

Part #: 93500-03005-1A Required per assembly: 2 Note: (3X5) (Honda Code 8749657)

SCREW, PAN, (3X6)

Part #: 93500-03006-3C Required per assembly: 2 Note: (3X6) (Honda Code 8749665)

SCREW, PAN, (4X10)

Part #: 93500-04010-0A Required per assembly: 2

SCREW-WASHER (5X10)

Part #: 93892-05010-00 Required per assembly: 1

SCREW, TAP, (4X16)

Part #: 93911-24410 Required per assembly: 2

Not Available

NUT, HEX., (6MM)

Part #: 94001-06390-0S Required per assembly: 2 Note: (6MM) (Honda Code 1240720)

NUT, FLANGE, (4MM)

Part #: 94050-04000 Required per assembly: 2

WASHER, PLAIN, (6MM)

Part #: 94101-06800 Required per assembly: 1

Not Available

WASHER, SPRING, (6MM)

Part #: 94111-06800 Required per assembly: 2
