Control Panel (1) replacement parts for Honda Power Equipment EU3000IK1

OEM Parts Honda Power Equipment Honda Power Equipment EU3000IK1 Control Panel (1)

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

02	CLAMP, F, CABLE Part #: 30569-895-000 Required per assembly: 2 Note: (Honda Code 2655165) $4.26 $4.13 - + Add to cart
03	RECEPTACLE, D.C. Part #: 31460-ZT3-C01 Required per assembly: 1 Note: (Honda Code 6022412) $74.80 $55.04 - + Add to cart
04	SUB-WIRE ASSEMBLY Part #: 32101-Z28-C30 Required per assembly: 2 Note: (Honda Code 9223975) $6.68 $5.42 - + Add to cart
05	SOCKET, COMPOSITE Part #: 32139-Z07-C00 Required per assembly: 2 Note: (Honda Code 6728265) $28.48 $20.95 - + Add to cart
06	WIRE HARNESS ASSEMBLY Part #: 32150-Z28-C30 Required per assembly: 1 Note: (Honda Code 9223983) $195.22 $143.65 - + Add to cart
07	SUB-WIRE ASSEMBLY Part #: 32196-Z28-C30 Required per assembly: 1 Note: (Honda Code 9224007) $33.66 $24.77 - + Add to cart
08	RECEPTACLE ASSEMBLY Part #: 32330-Z07-C30 Required per assembly: 1 Note: (125V-20A) (Honda Code 6728315) (MATSUSHITA) $56.90 $43.14 - + Add to cart
09	RECPTL (30A/125V) Part #: 32332-ZB4-630 Required per assembly: 1 $45.20 $34.26 - + Add to cart
10	PANEL, CONTROL Part #: 32345-Z28-C30 Required per assembly: 1 Note: (Honda Code 9224023) $156.78 $115.38 - + Add to cart
12	MARK, CONTROL, PANEL Part #: 32366-Z28-C30 Required per assembly: 1 Note: (Honda Code 9224072) $82.02 $60.36 - + Add to cart
13	TIE, CABLE Part #: 32903-ZC8-N01 Required per assembly: 1 Note: (C) (Honda Code 6569651) (Optional) $2.44 $2.26 - + Add to cart
14	SWITCH, IDLE, CONTROL Part #: 35340-Z28-003 Required per assembly: 1 Note: (Honda Code 9224221) $15.38 $11.32 - + Add to cart
15	CVR, THROTTLE, MOTOR Part #: 36168-ZT3-C01 Required per assembly: 1 Note: (Honda Code 6022552) $8.06 $6.50 - + Add to cart
16	INDICATOR ASSEMBLY Part #: 37150-Z28-004 Required per assembly: 1 Note: (Honda Code 9224247) $125.14 $92.09 - + Add to cart
17	HARNESS, INDICATOR Part #: 37155-Z28-000 Required per assembly: 1 Note: (Honda Code 9224254) $38.88 $28.61 - + Add to cart
18	PROTR, CIRCUIT, (20A) Part #: 38240-Z28-C30 Required per assembly: 1 Note: (20A) (Honda Code 9224270) $35.92 $26.43 - + Add to cart
19	PROTR, CIRCUIT, (30A) Part #: 38241-Z28-C30 Required per assembly: 1 Note: (30A) (Honda Code 9224288) $35.92 $26.43 - + Add to cart
21	BOLT (6X14) (CT200) Part #: 90014-952-000 Required per assembly: 1 $3.38 $3.07 - + Add to cart
22	SCREW, PAN, (5X12) Part #: 90102-899-003 Required per assembly: 1 Note: (5X12) (Honda Code 1809219) (GROUND CABLE) $3.62 $3.29 - + Add to cart
23	SCREW, PAN, (5X13) Part #: 90108-MN0-000 Required per assembly: 2 $2.78 $2.58 - + Add to cart
24	BOLT, FLANGE, (6X57) Part #: 90108-Z28-000 Required per assembly: 2 Note: (6X57) (Honda Code 9225608) $3.19 - + Add to cart
25	TIE, CABLE Part #: 90672-ZB4-000 Required per assembly: 1 Note: (Honda Code 9225749) $3.61 - + Add to cart
27	CLIP (145MM) Part #: 91541-S0A-003 Required per assembly: 2 $4.96 $4.51 - + Add to cart
28	CLIP, CONNECTOR Part #: 91555-SM4-003 Required per assembly: 1 Note: (RED) (Honda Code 3302288) $5.04 $4.95 - + Add to cart
29	SCREW, PAN, (5X8) Part #: 93500-05008-3J Required per assembly: 1 Note: (5X8) (Honda Code 0443150) $1.98 $1.83 - + Add to cart
30	SCREW, TAP, (5X12) Part #: 93901-25220 Required per assembly: 4 $1.95 $1.80 - + Add to cart
31	SCREW, TAP, (5X16) Part #: 93911-25420 Required per assembly: 2 $2.01 $1.86 - + Add to cart
32	NUT, FLANGE, (4MM) Part #: 94050-04000 Required per assembly: 4 $2.26 $2.05 - + Add to cart
33	BOLT, FLANGE, (6X10) Part #: 95701-06010-00 Required per assembly: 2 $2.29 $2.12 - + Add to cart
