Carburetor replacement parts for Kymco People 250

OEM Parts Kymco Kymco People 250 Carburetor

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

0137-261-36G5	TORX SCREW Part #: 0137-261-36G5 Required per assembly: 2 Currently Not Available
0301-261-36G5	PLAIN WASHER Part #: 0301-261-36G5 Required per assembly: 2 Currently Not Available
0301-803-2000	PLAIN WASHER Part #: 0301-803-2000 Required per assembly: 1 Currently Not Available
N350-19K00	FLOAT CHAMBER COMP Part #: N350-19K00 Required per assembly: 1 Currently Not Available
N413-17E00	NEEDLE JET HOLDER Part #: N413-17E00 Required per assembly: 1 Currently Not Available
N424-51B38	SLOW JET Part #: N424-51B38 Required per assembly: 1 Currently Not Available
N425-7AF01	JET NEEDLE COMP Part #: N425-7AF01 Required per assembly: 1 Currently Not Available
N426-33B00	NEEDLE JET Part #: N426-33B00 Required per assembly: 1 Currently Not Available
N446-12C00	SCREW Part #: N446-12C00 Required per assembly: 1 Currently Not Available
1028-054-7000	SEALING CAP Part #: 1028-054-7000 Required per assembly: 1 Currently Not Available
1030-892-2101	TOP SET Part #: 1030-892-2101 Required per assembly: 1 Currently Not Available
1034-869-2001	SCREW SET (S.S) Part #: 1034-869-2001 Required per assembly: 1 Currently Not Available
1052-862-2100	FLOAT COMP Part #: 1052-862-2100 Required per assembly: 1 Currently Not Available
1090-872-2000	SET PLATE Part #: 1090-872-2000 Required per assembly: 1 Currently Not Available
1190-B30-2002	STAY PLATE Part #: 1190-B30-2002 Required per assembly: 1 Currently Not Available
1190-B63-2100	STAY PLATE SET Part #: 1190-B63-2100 Required per assembly: 1 Currently Not Available
1201-830-2300	DIAPHRAGM COMP Part #: 1201-830-2300 Required per assembly: 1 Currently Not Available
1229-805-7000	VALVE PLATE SET Part #: 1229-805-7000 Required per assembly: 1 Currently Not Available
1230-850-2000	COVER Part #: 1230-850-2000 Required per assembly: 1 Currently Not Available
1230-851-2001	COVER Part #: 1230-851-2001 Required per assembly: 1 Currently Not Available
1230-856-7001	HOLDER CAP Part #: 1230-856-7001 Required per assembly: 1 Currently Not Available
1290-996-2000	SPG. COMPR Part #: 1290-996-2000 Required per assembly: 1 Currently Not Available
1290-A07-2000	SPG COMPR Part #: 1290-A07-2000 Required per assembly: 1 Currently Not Available
1290-A28-2000	SPG COMPR Part #: 1290-A28-2000 Required per assembly: 1 Currently Not Available
1402-939-2100	VACUUM PISTON COMP Part #: 1402-939-2100 Required per assembly: 1 Currently Not Available
W1448-006-9900	ADJUST HOLDER Part #: W1448-006-9900 Required per assembly: 1 Currently Not Available
W1470-MW0-7500	ACV DIAPHRAGM COMP Part #: W1470-MW0-7500 Required per assembly: 1 Currently Not Available
1610K-LLJ3-E00	CARB ASSY Part #: 1610K-LLJ3-E00 Required per assembly: 1 Currently Not Available
1614-870-2100	THROTTLE POSITION SENSOR "TPS" Part #: 1614-870-2100 Required per assembly: 1 Currently Not Available
W1711-518-9901	SPG COMPR Part #: W1711-518-9901 Required per assembly: 1 Currently Not Available
4000-317-0000	AUTO BYSTARTER SET Part #: 4000-317-0000 Required per assembly: 1 Currently Not Available
4115-803-1100	SCREW PAN Part #: 4115-803-1100 Required per assembly: 1 Currently Not Available
4115-804-1100	SCREW PAN Part #: 4115-804-1100 Required per assembly: 1 Currently Not Available
W9201-04090	WASHER Part #: W9201-04090 Required per assembly: 1 Currently Not Available
W9353-36000	U-RING Part #: W9353-36000 Required per assembly: 2 Currently Not Available
W9525-25250	ARM PIN Part #: W9525-25250 Required per assembly: 1 Currently Not Available
W9535-45000	TUBE CLIP Part #: W9535-45000 Required per assembly: 1 Currently Not Available
16053-KT7-0031	SYNCHRONIZE COIL SPG Part #: 16053-KT7-0031 Required per assembly: 1 Currently Not Available
16075-KG8-9010-M1	O-RING Part #: 16075-KG8-9010-M1 Required per assembly: 1 Currently Not Available
16145-MZ2-7800	COLLAR Part #: 16145-MZ2-7800 Required per assembly: 1 Currently Not Available
16155-ZG8-L100	FLOAT VALVE COMP Part #: 16155-ZG8-L100 Required per assembly: 1 Currently Not Available
16199-GY6-9000	TUBE SET Part #: 16199-GY6-9000 Required per assembly: 1 Currently Not Available
16978-ZB9-0050	O-RING Part #: 16978-ZB9-0050 Required per assembly: 1 Currently Not Available
37710-KGBG-E000	HEATER Part #: 37710-KGBG-E000 Required per assembly: 1 Currently Not Available
93500-04008-1H	SCREW PAN Part #: 93500-04008-1H Required per assembly: 5 Currently Not Available
93500-04010-1H	SCREW PAN Part #: 93500-04010-1H Required per assembly: 2 Currently Not Available
93500-04012-1H	SCREW PAN Part #: 93500-04012-1H Required per assembly: 3 Currently Not Available
93892-04008-18	SCREW WASH 48 Part #: 93892-04008-18 Required per assembly: 2 Currently Not Available*
99101-116-1080	MAIN JET Part #: 99101-116-1080 Required per assembly: 1 Currently Not Available
