OEM Parts Piaggio Piaggio BV 250 Piaggio Hex Shield

Piaggio BV 250 - Piaggio Hex Shield

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

PIAGGIO HEX SHIELD

Part #: 624554
Currently Not Available
2

250 SIDE STICKER

Part #: 623372
Currently Not Available
3

NAMEPLATE BV (BV-500)

Part #: 623316
Currently Not Available
4

624713

Part #: 624713
Not Available
5

NAMEPLATE

Part #: 620103
Currently Not Available
6
Currently Not Available
7

WARNING NAME PLATE

Part #: 576708
Currently Not Available
8

NAME PLATE

Part #: 620334
Currently Not Available
9

NAME PLATE

Part #: 620333
Currently Not Available
10

SAFETY WARNING STICKER

Part #: 576704
Currently Not Available
11

NAME PLATE

Part #: 620335
Currently Not Available
12

WARNING NAME PLATE

Part #: 576702
Currently Not Available
