Engine Covers replacement parts for Triumph America EFI

OEM Parts Triumph America EFI Engine Covers

Engine Covers Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	CLUTCH LIFTER ARM Part #: T1171550 Required per assembly: 1 Note: > Eng No 569398 Not Available
1	CLUTCH, LIFTER, ARM, BLACK Part #: T1171555 Required per assembly: 1 Note: Eng No 569399 > ~~$76.60~~ $75.28 - + Add to cart
2	BULLET, CLUTCH, LIFTER Part #: T1171701 Required per assembly: 1 ~~$34.34~~ $33.75 - + Add to cart
3	RETURN SPRING Part #: T1170925 Required per assembly: 1 ~~$2.68~~ $2.43 - + Add to cart
4	CLUTCH, CABLE, HOLDER, ANGLED Part #: T1171410 Required per assembly: 1 Note: > Eng No 569398 ~~$11.37~~ $10.34 - + Add to cart
4	CLUTCH CABLE HOLDER/GUIDE Part #: T1171415 Required per assembly: 1 Note: Eng No 569399 > ~~$11.37~~ $10.34 - + Add to cart
5	ASSEMBLY, COVER, CLUTCH, CHROME Part #: T1260425 Required per assembly: 1 Note: Eng No 372713 > Not Available
5	CLUTCH COVER ASSEMBLY Part #: T1261237 Required per assembly: 1 Note: > Eng No 372712 ~~$475.29~~ $467.10 - + Add to cart
6	SCREW, PAN/HD, TX, M6X1.0X12, ENC Part #: T3331042 Required per assembly: 8 ~~$1.47~~ $1.34 - + Add to cart
7	DUST, SEAL, 12X18X4.5 Part #: T3600095 Required per assembly: 1 ~~$2.36~~ $2.15 - + Add to cart
8	BEARING Part #: T3800110 Required per assembly: 2 ~~$7.00~~ $6.36 - + Add to cart
9	BEARING, NEEDLE, ROLLER, 20X14X12 Part #: T3800001 Required per assembly: 1 Note: Eng No 372713 > ~~$9.04~~ $8.22 - + Add to cart
9	BEARING, NEEDLE Part #: 3800041T0301 Required per assembly: 1 Note: > Eng No 372712 ~~$12.60~~ $12.38 - + Add to cart
10	SEAL, OIL, 14X22X4.5 Part #: T3600088 Required per assembly: 1 Note: Eng No 372713 > ~~$6.72~~ $6.11 - + Add to cart
10	OIL SEAL Part #: T3600008 Required per assembly: 1 Note: > Eng No 372712 ~~$11.14~~ $10.95 - + Add to cart
11	BOLT, HHF, LGHTD, M6X1.0X75, SLV Part #: T3205076 Required per assembly: 5 Note: Eng No 460575 > on Clutch Cover & Eng No 470730 > on Sprocket Cover ~~$4.67~~ $4.25 - + Add to cart
11	BOLT, RHHF, DOMED, S/LESS, M6X75 Part #: T3203075 Required per assembly: 5 Note: PART NO LONGER AVAILABLE > Eng No 460574 on Clutch Cover & > Eng No 470729 on Sprocket Cover Not Available
12	GASKET, CLUTCH, COVER Part #: T1260967 Required per assembly: 1 ~~$20.08~~ $18.25 - + Add to cart
13	BOLT, DOMED, M6X40 Part #: T3202030 Required per assembly: 7 Note: > Eng No 460556 Not Available
13	BOLT, HHF, LGHTD, M6X1.0X30, SLV Part #: T3205070 Required per assembly: 7 Note: Eng No 460557 > ~~$2.50~~ $2.27 - + Add to cart
14	BOLT, RHHF, DOMED, S/LESS, M6X40 Part #: T3203040 Required per assembly: 6 Note: > Eng No 460556 ~~$1.82~~ $1.65 - + Add to cart
14	BOLT, HHF, LGHTD, M6X1.0X40, SLV Part #: T3205072 Required per assembly: 6 Note: Eng No 460557 > ~~$1.82~~ $1.65 - + Add to cart
15	DOWEL 6 X 16 Part #: T3000005 Required per assembly: 8 ~~$1.19~~ $1.08 - + Add to cart
16	COVER, RH, CAST, IMP, MACH, POL, CHR Part #: T1261932 Required per assembly: 1 ~~$193.62~~ $190.29 - + Add to cart
17	GASKET, RH, COVER Part #: T1260968 Required per assembly: 1 ~~$9.58~~ $8.71 - + Add to cart
18	BOLT, RHHF, DOMED, S/LESS, M6X50 Part #: T3203050 Required per assembly: 11 Note: > Eng No 460586 ~~$7.09~~ $6.44 - + Add to cart
18	BOLT, HHF, LGHTD, M6X1.0X50, SLV Part #: T3205073 Required per assembly: 11 Note: Eng No 460587 > ~~$7.09~~ $6.44 - + Add to cart
19	BADGE, TRIUMPH, TRIANGULAR Part #: T3950103 Required per assembly: 1 Note: 468391 > ~~$12.66~~ $12.43 - + Add to cart
19	BADGE, TRIUMPH, TRIANGULAR Part #: T3950100 Required per assembly: 1 Note: > 468390 ~~$12.34~~ $12.13 - + Add to cart
20	PLATE, WIRE, RETAINER Part #: T1261178 Required per assembly: 1 ~~$6.46~~ $5.87 - + Add to cart
21	SCREW, CAP/HD, M6X1X12, ENC, RAW Part #: T3051062 Required per assembly: 1 ~~$1.54~~ $1.40 - + Add to cart
22	COVER, G/CHANGE, MECH, LINISHED Part #: T1260992 Required per assembly: 1 ~~$126.74~~ $124.56 - + Add to cart
23	GASKET, COVER, G/CHANGE, MECH Part #: T1260969 Required per assembly: 1 ~~$8.89~~ $8.08 - + Add to cart
24	BOLT, RHHF, M6X1X20, SLV Part #: T3205066 Required per assembly: 2 Note: Eng No 398116 > Eng No 460576 ~~$4.78~~ $4.34 - + Add to cart
24	BOLT, RHHF, M6X1X20, SLV Part #: T3205066 Required per assembly: 2 Note: Eng No 460577 > ~~$4.78~~ $4.34 - + Add to cart
24	BOLT, HHF, LGHTD, M6, X, 16, SLV Part #: T3205063 Required per assembly: 2 Note: > Eng No 398115 ~~$3.67~~ $3.34 - + Add to cart
25	BOLT, RHHF, DOMED, S/LESS, M6X40 Part #: T3203040 Required per assembly: 4 Note: > 459368 ~~$1.82~~ $1.65 - + Add to cart
25	BOLT, HHF, LGHTD, M6X1.0X40, SLV Part #: T3205072 Required per assembly: 4 Note: 459369 > ~~$1.82~~ $1.65 - + Add to cart
26	BRACKET, NEUT, IND, LD., RETAINER Part #: T1260965 Required per assembly: 1 ~~$8.76~~ $7.97 - + Add to cart
27	SPROCKET, COVER, CHROMED Part #: T1263006 Required per assembly: 1 ~~$123.22~~ $121.10 - + Add to cart
28	LABEL, OIL, FILTER, RED, SIZE Part #: T3900302 Required per assembly: 1 ~~$5.98~~ $5.44 - + Add to cart
29	BOLT, RHHF, DOMED, S/LESS, M6X50 Part #: T3203050 Required per assembly: 4 Note: > 474377 ~~$7.09~~ $6.44 - + Add to cart
29	BOLT, HHF, LGHTD, M6X1.0X50, SLV Part #: T3205073 Required per assembly: 4 Note: 474378 > ~~$7.09~~ $6.44 - + Add to cart
30	PLATE, FINSHER Part #: T1261595 Required per assembly: 1 ~~$58.06~~ $57.05 - + Add to cart
31	SOUND, SUPPRESSION, PLATE, CLUTCH, COVER Part #: T1261560 Required per assembly: 1 Not Available
32	SOUND, SUPPRESSION, PAD, CLUTCH, COVER Part #: T1261570 Required per assembly: 1 Not Available
