Engine Covers replacement parts for Triumph Bonneville Bobber Black

OEM Parts Triumph Bonneville Bobber Black Engine Covers

Engine Covers Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	CLUTCH, COVER, ASSEMBLY, BLACK Part #: T1267765 Required per assembly: 1 Note: See Tech News 180 $367.47 $361.14 - + Add to cart
2	DUST, SEAL, 12X18X4.5 Part #: T3600095 Required per assembly: 1 $2.29 $2.08 - + Add to cart
3	BEARING Part #: T3800110 Required per assembly: 1 $6.79 $6.17 - + Add to cart
4	BEARING, NEEDLE, ROLLER, 7X11X9 Part #: T3800156 Required per assembly: 1 $29.87 $29.35 - + Add to cart
5	BEARING, NEEDLE, ROLLER, 20X14X12 Part #: T3800001 Required per assembly: 1 $8.78 $7.98 - + Add to cart
6	SEAL, OIL, 14X22X4.5 Part #: T3600088 Required per assembly: 1 $6.53 $5.93 - + Add to cart
7	GASKET, CLUTCH, COVER Part #: T1269876 Required per assembly: 1 $13.83 $13.58 - + Add to cart
8	CLUTCH, COVER, BADGE, GRAPHITE Part #: T1269027 Required per assembly: 1 $33.09 $32.51 - + Add to cart
9	SCREW, CAP/HD, M5X0.8X10, SLV, ENC Part #: T3051055 Required per assembly: 4 $3.10 $2.82 - + Add to cart
10	PLUG, M12, X, 1.75, BLACK Part #: T1267676 Required per assembly: 1 $10.00 $9.83 - + Add to cart
11	BOLT, HHF, LGHTD, M6X1.0X40, SLV Part #: T3205072 Required per assembly: 19 $1.75 $1.59 - + Add to cart
12	BOLT, HHF, LGHTD, M6, X, 50, SLV Part #: T3205093 Required per assembly: 4 $6.88 $6.25 - + Add to cart
13	BOLT, HHF, LGHTD, M6X1.0X35, ENC Part #: T3205082 Required per assembly: 2 $2.43 $2.21 - + Add to cart
14	DOWEL 6 X 16 Part #: T3000005 Required per assembly: 6 $1.15 $1.05 - + Add to cart
17	SCREW, PAN/HD, TX, M6X1.0X12, ENC Part #: T3331042 Required per assembly: 6 $1.42 $1.29 - + Add to cart
18	ALTERNATOR, COVER, BLACK Part #: T1267210 Required per assembly: 1 $194.82 $191.46 - + Add to cart
19	GASKET, ALTERNATOR, COVER Part #: T1268765 Required per assembly: 1 $11.55 $11.34 - + Add to cart
20	COVER, GRAPHITE Part #: T1269017 Required per assembly: 1 $9.22 $8.38 - + Add to cart
21	BADGE, FLAT, TYPE, 1 Part #: T3951060 Required per assembly: 1 $11.98 $11.76 - + Add to cart
22	BRACKET, CABLE Part #: T1308765 Required per assembly: 1 $10.00 $9.83 - + Add to cart
23	SCREW, PAN/HD, TX, M5X0.8X12, SLV Part #: T3330649 Required per assembly: 1 $5.42 $4.93 - + Add to cart
24	COVER, SPROCKET, BLACK Part #: T1263543 Required per assembly: 1 $157.23 $154.51 - + Add to cart
25	BOLT, M6X30, SILVER Part #: T3200148 Required per assembly: 4 $4.55 $4.14 - + Add to cart
26	WASHER, CAP, NYLON Part #: T1260568 Required per assembly: 1 $6.19 $5.63 - + Add to cart
27	GROMMET, SPROCKET, COVER Part #: T1261662 Required per assembly: 4 $3.57 $3.24 - + Add to cart
28	FLANGED, SLEEVE, 6.4, X, 9, X, 14.6 Part #: T3010901 Required per assembly: 4 $6.56 $5.96 - + Add to cart
29	MESH INSERT Part #: T1260563 Required per assembly: 1 $39.39 $38.71 - + Add to cart
30	SCREW, CAP, /, HD, M5, X, 10, SILVER Part #: T3050341 Required per assembly: 2 Note: 459486 > $3.62 $3.29 - + Add to cart
31	'O'RING, 48IDX3.5 Part #: T3600222 Required per assembly: 2 $9.72 $9.54 - + Add to cart
32	CAP, SPROCKET, COVER, BLACK Part #: T1260576 Required per assembly: 1 $41.26 $40.54 - + Add to cart
