OEM Parts Triumph Daytona 1200, 900 & Super III Instruments

Triumph Daytona 1200, 900 & Super III - Instruments

Instruments Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

INSTRU, ASSEMBLY, KPH, -, LS

Part #: T2500701 Required per assembly: 1 Note: > 16921 KPH
Not Available
1

INSTRU, ASSEMBLY, KPH, -, LS

Part #: T2500701 Required per assembly: 1 Note: 16922 > KPH
Not Available
1

INSTRU, ASSEMBLY, MPH, -, LS

Part #: T2500601 Required per assembly: 1 Note: 16922 > MPH
Not Available
2

BULB, INSTRUMENTS, T6.5, 3.0W

Part #: T2500090 Required per assembly: Note: T6.5 - 3W Warning lamps
$6.26
$5.69
-
+
Add to cart
3

BULB, INSTRUMENTS, T6.5, 1.7W

Part #: 2500085T0301 Required per assembly: 3 Note: T6.5 - 1.7W Warning lamps
$5.74
$5.22
-
+
Add to cart
4

BULB, INSTRUMENTS, T10, 1.7W

Part #: 2500095T0301 Required per assembly: Note: T10 - 1.7W Instrument illumination
$6.28
$5.71
-
+
Add to cart
5

SCREW, PAN, /, HD, TX, M6, X, 16, SLV

Part #: T3331044 Required per assembly: 2 Note: M6 x 16mm
$0.98
$0.89
-
+
Add to cart
6

SPEEDOMETER KPH

Part #: 2500760T0301 Required per assembly: 1
Not Available
6

SPEEDO, MPH

Part #: 2500660T0301 Required per assembly: 1
Not Available
7

TACHOMETER

Part #: 2500675T0301 Required per assembly: 1
Not Available
8

TEMPERATURE, GAUGE, S

Part #: 2500680T0301 Required per assembly: 1
Not Available
9

LABEL, ULG, INST, PACK

Part #: T3930090 Required per assembly: 1 Note: Unleaded fuel US CAL
Not Available
10

WARNING LIGHT PANEL

Part #: T2500388 Required per assembly: 1 Note: Part No Longer Available
Not Available
11

SUB-HARNESS, WARNING, LIGHTS

Part #: T2500384 Required per assembly: 1
Not Available
12

TRIP KNOB

Part #: T2500380 Required per assembly: 1
$3.85
$3.50
-
+
Add to cart
13

SCREW, RESET, KNOB

Part #: T2501205 Required per assembly: 1
$1.42
$1.29
-
+
Add to cart
14

SUB-HARNESS, TEMP, GAUGE

Part #: T2500382 Required per assembly: 1 Note: Temperature gauge
Not Available
15

SUB-HARNESS, PANEL, ILLUMINATION

Part #: T2500383 Required per assembly: 1 Note: Panel illumination
Not Available
16

MOUNTING PLATE

Part #: T2500387 Required per assembly: 1
Not Available
17

GASKET, WARNING, LIGHT, CLUSTER

Part #: T2500389 Required per assembly: 1
Not Available
18

RUBBER, SEAL, SPEEDO, &TEMP, GAUGE

Part #: T2500386 Required per assembly: 1 Note: Speedometer
Not Available
19

RUBBER, SEAL, TACHOMETER

Part #: T2500385 Required per assembly: 1 Note: Tachometer
Not Available
