Exhaust System replacement parts for Triumph Daytona 675 VIN 381275 to VIN 564947

OEM Parts Triumph Daytona 675 VIN 381275 to VIN 564947 Exhaust System

Exhaust System Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	SPARES, KIT, SLOTTED, HEADER Part #: T2202675 Required per assembly: 1 Note: > 443581 & > 445378 Special Edition ~~$1,082.62~~ $1,063.99 - + Add to cart
1	PRIMARY HEADER PIPE ASSEMBLY Part #: T2204250 Required per assembly: 1 Note: 443582 > & 445379 > Special Edition Not Available
2	SECONDARY HEADER PIPE ASSEMBLY Part #: T2203710 Required per assembly: 1 ~~$177.80~~ $174.74 - + Add to cart
3	BUSH, RUBBER Part #: T3020482 Required per assembly: 2 ~~$3.32~~ $3.02 - + Add to cart
4	BOLT, 3RD, MOUNT, PLTD Part #: T2218053 Required per assembly: 1 ~~$9.71~~ $8.83 - + Add to cart
5	CLAMP, EXHAUXT, 51-55MM Part #: T2206078 Required per assembly: 2 ~~$19.35~~ $19.01 - + Add to cart
6	GASKET, EXHAUST Part #: T2202115 Required per assembly: 2 ~~$12.02~~ $11.81 - + Add to cart
7	ACTUATOR, EXHAUST, VALVE Part #: T2203885 Required per assembly: 1 Note: 494489 > ~~$220.02~~ $216.23 - + Add to cart
7	KIT, EXBV, CABLES Part #: T2203379 Required per assembly: 1 Note: > 494488 - PART NO LONGER AVAILABLE Not Available
8	FLANGED, SLEEVE, M6X10X8.5 Part #: T3010702 Required per assembly: 2 ~~$6.07~~ $5.52 - + Add to cart
9	GROMMET, DIA11.8X4.0 Part #: T3020050 Required per assembly: 2 ~~$5.41~~ $4.91 - + Add to cart
10	SCREW, PANHD, TX, M6X1X20, SLV, ENC Part #: T3331191 Required per assembly: 2 ~~$2.20~~ $2.00 - + Add to cart
11	BRACKET, ACTUATOR, EXHAUST, VALVE Part #: T2203894 Required per assembly: 1 ~~$10.91~~ $10.72 - + Add to cart
12	SCREW, PAN/HD, TX, M6X1.0X12, ENC Part #: T3331042 Required per assembly: 2 ~~$1.47~~ $1.34 - + Add to cart
13	PULLEYWHEEL, ACTUATOR, EXH, VALVE Part #: T2203889 Required per assembly: 1 ~~$30.99~~ $30.45 - + Add to cart
14	SCRW, SKT, CSK, M5X0.8X10, SLV, ENC Part #: T3331865 Required per assembly: 1 ~~$5.97~~ $5.42 - + Add to cart
15	COVER, ACTUATOR, EXHAUST, VALVE Part #: T2203893 Required per assembly: 1 ~~$9.80~~ $8.91 - + Add to cart
16	SCREW, PAN/HD, TX, M6X1.0X12, SLV Part #: T3331043 Required per assembly: 2 ~~$1.01~~ $0.92 - + Add to cart
17	COVER, EXHAUST, VALVE Part #: T2203891 Required per assembly: 1 ~~$14.07~~ $13.82 - + Add to cart
18	SCREW, HHF, 50X16, SLV Part #: T3331414 Required per assembly: 2 ~~$1.59~~ $1.45 - + Add to cart
19	KIT, EXBV, CABLES Part #: T2203378 Required per assembly: 1 Note: > 494488 Not Available
19	CABLES, EX, VALVE, ACTUATOR Part #: T2203377 Required per assembly: 1 Note: 494489 > - PART NO LONGER AVAILABLE Not Available
20	ACTUATOR BOOT Part #: T2203899 Required per assembly: 1 ~~$9.48~~ $8.62 - + Add to cart
21	FLANGED, SLEEVE, 8.4X12X12.5 Part #: T3010708 Required per assembly: 2 ~~$2.59~~ $2.35 - + Add to cart
22	BOLT, HHF, LGHTD, M8, X, 45, SLV Part #: T3205109 Required per assembly: 1 ~~$5.39~~ $4.90 - + Add to cart
23	BUSH, RUBBER, 12X19X9.5 Part #: T2200387 Required per assembly: 2 ~~$5.41~~ $4.91 - + Add to cart
24	OXYGEN SENSOR SPARES KIT Part #: T2204191 Required per assembly: 1 ~~$202.84~~ $199.34 - + Add to cart
25	GASKET, HEADER Part #: T2200854 Required per assembly: 3 ~~$7.70~~ $7.00 - + Add to cart
26	LOCKNUT, FLANGED, M8 Part #: T3350004 Required per assembly: 6 ~~$2.57~~ $2.34 - + Add to cart
27	SILENCER, UNDER, SEAT, NON, CAT Part #: T2203848 Required per assembly: 1 Not Available
28	HEAT, SHIELD, INTERMEDIATE Part #: T2203858 Required per assembly: 1 ~~$58.98~~ $57.95 - + Add to cart
29	BOLT, HEX, HD, FLGD, M6X1.0X12 Part #: T3330216 Required per assembly: 2 Not Available
30	HEAT, SHIELD, SILENCER Part #: T2203852 Required per assembly: 1 ~~$84.50~~ $53.76 - + Add to cart
31	GROMMET, RUBBER Part #: T3020390 Required per assembly: 2 ~~$3.50~~ $3.18 - + Add to cart
32	GROMMET, DIA, 18.0X1.0X9.0, ID Part #: T3020085 Required per assembly: 4 ~~$2.20~~ $2.00 - + Add to cart
33	FLANGED, SLEEVE, M6, X, 9.5, X, 10.5 Part #: T3010144 Required per assembly: 4 ~~$3.95~~ $3.59 - + Add to cart
34	BOLT, HHF, LGHTD, M8, X, 45, SLV Part #: T3205109 Required per assembly: 1 ~~$5.39~~ $4.90 - + Add to cart
35	LOCKNUT, FLANGED, M8 Part #: T3350004 Required per assembly: 1 ~~$2.57~~ $2.34 - + Add to cart
36	BUSH, RUBBER, M8 Part #: T2200622 Required per assembly: 2 ~~$2.36~~ $2.15 - + Add to cart
37	TUBE, COMPRESSION, LIMITER Part #: T2203853 Required per assembly: 1 Not Available
38	FOOT, RUBBER, DIA14.0X6.0 Part #: T3020162 Required per assembly: 3 ~~$2.36~~ $2.15 - + Add to cart
39	FOOT, RUBBER, PUSH, IN. Part #: T3020175 Required per assembly: 2 ~~$10.91~~ $10.72 - + Add to cart
40	END, CAP, EXHAUST, PNTD Part #: T2203849MJ Required per assembly: 1 Note: > 498020 ~~$193.24~~ $189.91 - + Add to cart
40	MOULDING, TAIL, PIECE Part #: T2203855 Required per assembly: 1 Note: Daytona 675R & 498021 > ~~$91.53~~ $89.95 - + Add to cart
40	TAIL, PIECE, SILENCER, CARBON Part #: T2203875 Required per assembly: 1 Note: Special Edition 2 Not Available
41	FLANGED, SLEEVE, M6X10X8.5 Part #: T3010702 Required per assembly: 2 ~~$6.07~~ $5.52 - + Add to cart
42	WASHER, M10, SILICON Part #: T3550149 Required per assembly: 4 ~~$1.59~~ $1.45 - + Add to cart
43	BOLT, RHHF, M6X1X20, SLV Part #: T3205066 Required per assembly: 2 Note: > 461400 ~~$4.78~~ $4.34 - + Add to cart
43	BOLT, RHHF, M6X1X20, SLV Part #: T3205066 Required per assembly: 2 Note: 461401 > ~~$4.78~~ $4.34 - + Add to cart
44	WASHER, M6X13X1, S5041 Part #: T3550962 Required per assembly: 2 Note: 461401 > ~~$2.01~~ $1.83 - + Add to cart
44	WASHER.M6X1X13 Part #: T3550957 Required per assembly: 2 Note: > 461400 ~~$2.01~~ $1.83 - + Add to cart
45	WASHER, EXHAUST, VALVE Part #: T2203886 Required per assembly: 1 ~~$11.46~~ $11.25 - + Add to cart
46	SPRING, HEADER, EX, VALVE Part #: T2203887 Required per assembly: 1 ~~$16.73~~ $16.44 - + Add to cart
47	PULLY, WHEEL, EXHAUST, VALVE Part #: T2203888 Required per assembly: 1 ~~$21.13~~ $20.76 - + Add to cart
48	NUT, M8X1.25, THIN, SS Part #: T3350175 Required per assembly: 1 ~~$5.90~~ $5.36 - + Add to cart
49	WASHER, TAB, EXHAUST, VALVE Part #: T2203890 Required per assembly: 1 ~~$2.68~~ $2.43 - + Add to cart
