Instruments replacement parts for Triumph Daytona 750/1000

OEM Parts Triumph Daytona 750/1000 Instruments

Instruments Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	INSTRUMENT, ASSEMBLY, MPH Part #: 2500650T0301 Required per assembly: 1 Note: MPH UK Not Available
1	INSTRUMENT, ASSEMBLY, KPH Part #: 2500750T0301 Required per assembly: 1 Note: KPH Not Available
2	BULB, INSTRUMENTS, T6.5, 3.0W Part #: T2500090 Required per assembly: Note: T6.5 - 3W Warning lamps $6.26 $5.69 - + Add to cart
3	BULB, INSTRUMENTS, T6.5, 1.7W Part #: 2500085T0301 Required per assembly: 3 Note: T6.5 - 1.7W Warning lamps $5.74 $5.22 - + Add to cart
4	BULB, INSTRUMENTS, T10, 1.7W Part #: 2500095T0301 Required per assembly: Note: T10 - 1.7W Instrument illumination $6.28 $5.71 - + Add to cart
5	SCREW, PAN, /, HD, TX, M6, X, 16, SLV Part #: T3331044 Required per assembly: 2 Note: M6 x 16mm $0.98 $0.89 - + Add to cart
6	SPEEDOMETER KPH Part #: 2500760T0301 Required per assembly: 1 Not Available
6	SPEEDO, MPH Part #: 2500660T0301 Required per assembly: 1 Note: UK Not Available
7	TACHO GAUGE SP Part #: 2500670T0301 Required per assembly: 1 Not Available
8	TEMPERATURE, GAUGE, S Part #: 2500680T0301 Required per assembly: 1 Not Available
9	TRIP KNOB Part #: T2500380 Required per assembly: 1 $3.85 $3.50 - + Add to cart
10	SCREW, RESET, KNOB Part #: T2501205 Required per assembly: 1 $1.42 $1.29 - + Add to cart
11	SUB-HARNESS, TEMP, GAUGE Part #: T2500382 Required per assembly: 1 Note: Temperature gauge Not Available
12	SUB-HARNESS, PANEL, ILLUMINATION Part #: T2500383 Required per assembly: 1 Note: Panel illumination Not Available
13	SUB-HARNESS, WARNING, LIGHTS Part #: T2500384 Required per assembly: 1 Not Available
14	MOUNTING PLATE Part #: T2500387 Required per assembly: 1 Not Available
15	WARNING LIGHT PANEL Part #: T2500388 Required per assembly: 1 Note: Part No Longer Available Not Available
16	GASKET, WARNING, LIGHT, CLUSTER Part #: T2500389 Required per assembly: 1 Not Available
17	RUBBER, SEAL, SPEEDO, &TEMP, GAUGE Part #: T2500386 Required per assembly: 1 Note: Speedometer Not Available
18	RUBBER, SEAL, TACHOMETER Part #: T2500385 Required per assembly: 1 Note: Tachometer Not Available
