Stands replacement parts for Triumph Explorer XR

OEM Parts Triumph Explorer XR Stands

Stands Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	SIDESTAND BRACKET Part #: T2087791 Required per assembly: 1 $165.76 $162.90 - + Add to cart
2	BOLT, HHF, LGHTD, M10X1.25X60, SLV Part #: T3205760 Required per assembly: 2 $6.26 $5.69 - + Add to cart
3	SIDESTAND, LEG, BLACK Part #: T2082133 Required per assembly: 1 $170.90 $167.95 - + Add to cart
4	SPRING, SIDE, STAND Part #: T2080808 Required per assembly: 1 $9.56 $9.39 - + Add to cart
5	PIN, PIVOT, SIDESTAND Part #: T2084020 Required per assembly: 1 $7.17 $6.52 - + Add to cart
6	CIRCLIP, EXT, 8X1 Part #: T3500210 Required per assembly: 1 $2.05 $1.86 - + Add to cart
7	SWITCH, SIDESTAND Part #: T2080746 Required per assembly: 1 $54.72 $53.77 - + Add to cart
8	SCREW, PAN/HD, TX, M5X0.8X16, ENC Part #: T3330728 Required per assembly: 2 $0.98 $0.89 - + Add to cart
9	CENTRESTAND ASSEMBLY Part #: T2081358 Required per assembly: 1 $289.85 $263.50 - + Add to cart
10	PIN, CENTRESTAND, SPRING Part #: T2081970 Required per assembly: 1 $15.05 $14.79 - + Add to cart
11	SPRING, CENTRE, STAND Part #: T2080793 Required per assembly: 2 $8.34 $7.59 - + Add to cart
12	BRACKET, CENTRE, STAND, SPRING Part #: T2080811 Required per assembly: 1 $20.43 $20.06 - + Add to cart
13	BOSS, PIVOT, CENTRESTAND Part #: T2083340 Required per assembly: 2 $32.32 $31.75 - + Add to cart
14	SCREW, M10X1.25X30, ENC Part #: T3332162 Required per assembly: 2 $6.68 $6.08 - + Add to cart
15	O-RING 14 X 17.6 X 1.8 Part #: T3606360 Required per assembly: 4 $2.13 $1.94 - + Add to cart
16	BRACKET, CENTRESTAND, SPRING Part #: T2081147 Required per assembly: 1 $19.65 $19.31 - + Add to cart
17	SCREW, CAP/HD, M8X1.25X45 Part #: T3051043 Required per assembly: 1 $6.79 $6.17 - + Add to cart
18	STOP, CENTRESTAND Part #: T2081928 Required per assembly: 1 $5.83 $5.30 - + Add to cart
19	BOLT, HHF, LGHTD, M8, X, 18, SLV Part #: T3205156 Required per assembly: 1 $1.64 $1.49 - + Add to cart
20	COVER, TUBULAR, PLASTIC Part #: T2081346 Required per assembly: 1 $20.00 $19.66 - + Add to cart
21	RIVET, BARBED, 2.1-4.3MM Part #: T3300008 Required per assembly: 1 $9.16 $9.00 - + Add to cart
