Exhaust System - Low Ride Height Version Only replacement parts for Triumph Explorer XRx

OEM Parts Triumph Explorer XRx Exhaust System - Low Ride Height Version Only

Exhaust System - Low Ride Height Version Only Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	EXHAUST HEADER ASSEMBLY Part #: T2203400 Required per assembly: 1 Note: AU & NZ Only $1,127.98 $1,108.57 - + Add to cart
1	PRIMARY HEADER PIPE ASSEMBLY Part #: T2203399 Required per assembly: 1 Note: BR Only $1,127.98 $1,108.57 - + Add to cart
1	HEADER ASSEMBLY Part #: T2203390 Required per assembly: 1 Note: All Markets Except AU, NZ & BR $1,127.98 $1,108.57 - + Add to cart
2	GASKET, EXHAUST, HEADER Part #: T2201997 Required per assembly: 3 $9.60 $8.73 - + Add to cart
3	LOCKNUT, FLANGED, M8 Part #: T3350004 Required per assembly: 6 $2.33 $2.12 - + Add to cart
4	RUBBER GROMMET 7.86MM Part #: T2200912 Required per assembly: 1 $3.22 $2.93 - + Add to cart
5	FLANGED, SLEEVE, M8X26.6 Part #: T3010212 Required per assembly: 1 $2.52 $2.29 - + Add to cart
6	BOLT, HHF, LGHTD, M8, X, 45, SLV Part #: T3205109 Required per assembly: 1 $5.23 $4.76 - + Add to cart
7	WASHER, 8.4, X, 24, X, 2 Part #: T3555033 Required per assembly: 1 $2.78 $2.53 - + Add to cart
8	OXYGEN SENSOR SPARES KIT Part #: T2204191 Required per assembly: 1 $196.93 $193.54 - + Add to cart
9	GASKET, EXHAUST Part #: T2202115 Required per assembly: 1 $10.93 $10.74 - + Add to cart
10	CLAMP, EXHAUXT, 51-55MM Part #: T2206078 Required per assembly: 1 $18.79 $18.46 - + Add to cart
11	SILENCER, ASSEMBLY, NO, UPSTOP Part #: T2205330 Required per assembly: 1 $598.19 $587.90 - + Add to cart
12	END, CAP, SILENCER, SINGLE, EXIT Part #: T2205404 Required per assembly: 1 $36.67 $36.03 - + Add to cart
13	SCREW, CAP/HD, M5, X, 10, SLV, ENC Part #: T3050186 Required per assembly: 6 $3.22 $2.93 - + Add to cart
14	COVER, SECONDARY, BRUSHED Part #: T2200869 Required per assembly: 1 $75.21 $73.91 - + Add to cart
15	SCREW, PAN/HD, TX, M5X0.8X12, SLV Part #: T3330649 Required per assembly: 2 $5.42 $4.93 - + Add to cart
16	CAPTIVE, NUT, M6 Part #: T3350117 Required per assembly: 2 $0.62 $0.61 - + Add to cart
17	SCREW, PAN/HD, M8X1.25X50, SLV Part #: T2205403 Required per assembly: 1 $8.26 $7.51 - + Add to cart
18	FLANGED, SLEEVE, M8, SILENCER Part #: T2205410 Required per assembly: 2 $15.38 $15.10 - + Add to cart
19	LOCKNUT, FLANGED, M8 Part #: T3350004 Required per assembly: 1 $2.33 $2.12 - + Add to cart
20	WASHER, 8.25X28X2 Part #: T3554322 Required per assembly: 1 $2.05 $1.86 - + Add to cart
23	SILENCER STRAP Part #: T2205325 Required per assembly: 1 $27.53 $27.05 - + Add to cart
