Instruments replacement parts for Triumph Legend TT

OEM Parts Triumph Legend TT Instruments

Instruments Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	INSTRUMENT, ASSEMBLY, KPH Part #: T2501168 Required per assembly: 1 Note: Kilometers Per Hour Not Available
1	INSTRUMENT, ASSEMBLY, MPH Part #: T2501163 Required per assembly: 1 Note: Miles Per Hour Not Available
2	BULB, INSTRUMENTS, 1.7W Part #: T2502089 Required per assembly: 4 Note: 2.0 watt Speedo, Tacho gauges $2.78 $2.53 - + Add to cart
3	BULB, INSTRUMENTS, 1.7W Part #: T2500097 Required per assembly: 6 Note: 1.2 watt Warning lamps $4.95 $4.50 - + Add to cart
4	WASHER, M5, CSK Part #: T3550265 Required per assembly: 2 $4.29 $3.90 - + Add to cart
5	SCREW, CSK, M5X0.8X30, SLV, ENC Part #: T3330643 Required per assembly: 2 $2.05 $1.86 - + Add to cart
6	SPEEDO, KPH Part #: T2502107 Required per assembly: 1 Note: PART NO LONGER AVAILABLE - > 89489 Not Available
6	SPEEDO MPH Part #: T2502106 Required per assembly: 1 Note: > 86435 - VIN required on order Not Available
6	SPEEDO, GAUGE, KPH Part #: T2501175 Required per assembly: 1 Note: 89490 > Not Available
6	SPEEDO, GAUGE, MPH Part #: T2501174 Required per assembly: 1 Note: 86436 > Not Available
7	TACHOMETER ASSEMBLY Part #: T2501173 Required per assembly: 1 Note: 86436 >, MPH 89490 >, KPH Not Available
8	FACE, PLATE, WARNING, LIGHTS-BLK Part #: T2501170 Required per assembly: 1 Note: Warning lamps > 86435, MPH > 89489, KPH $62.36 $19.83 - + Add to cart
8	FACE, PLATE, WARNING, LIGHTS-BLK Part #: T2501170 Required per assembly: 1 Note: Warning lamps 86436 >, MPH 89490 >, KPH $62.36 $19.83 - + Add to cart
9	SCREW, WARNING, LIGHT, HOUSING Part #: T2501187 Required per assembly: 2 Not Available
10	MOUNTING PLATE Part #: T2502108 Required per assembly: 1 Note: > 86435, MPH > 89489, KPH Not Available
10	MOUNTING, PLATE, BLACK Part #: T2501178 Required per assembly: 1 Note: 86436 >, MPH 89490 >, KPH - PART NO LONGER AVAILABLE Not Available
11	SPEEDOMETER, CAN, BLACK Part #: T2501185 Required per assembly: 1 Note: 86436 >, MPH 89490 >, KPH $146.97 $144.44 - + Add to cart
11	SPEEDO, CAN, BLACK, METAL Part #: T2502092 Required per assembly: 1 Note: > 86435, MPH > 89489, KPH Not Available
12	TACHO, CAN, BLACK, METAL Part #: T2502093 Required per assembly: 1 Note: > 86435, MPH > 89489, KPH Not Available
12	TACHO, CAN, BLACK Part #: T2501186 Required per assembly: 1 Note: 86436 >, MPH 89490 >, KPH $146.97 $144.44 - + Add to cart
13	NUT, INSTRUMENT, CAN Part #: T2501189 Required per assembly: 2 $2.29 $2.08 - + Add to cart
14	WASHER, INSTRUMENT, CAN Part #: T2501188 Required per assembly: 2 $1.29 $1.18 - + Add to cart
15	SUB-HARNESS, INSTRUMENTS Part #: T2501179 Required per assembly: 1 Note: 86436 >, MPH 89490 >, KPH Not Available
15	SUB-HARNESS, INSTRUMENTS, RT/C Part #: T2502046 Required per assembly: 1 Note: > 86435, MPH > 89489, KPH Not Available
16	SPEEDO, TRIP, KNOB Part #: T2502051 Required per assembly: 1 Note: > 89489 $7.68 $6.98 - + Add to cart
16	TRIP, KNOB, SPEEDO Part #: T2501172 Required per assembly: 1 Note: 89490 > $9.69 $8.81 - + Add to cart
17	SCREW, RESET, KNOB Part #: T2501205 Required per assembly: 1 $1.42 $1.29 - + Add to cart
18	COVER, TELL, TALE, LAMPS Part #: T2501184 Required per assembly: 1 Note: Warning lamps > 86435, MPH > 89489, KPH Not Available
18	COVER, TELL, TALE, LAMPS Part #: T2501184 Required per assembly: 1 Note: Warning lamps 86436 >, MPH 89490 >, KPH Not Available
19	SCREW, FACE, PLATE, INSTRUMENTS Part #: T2501171 Required per assembly: 3 $1.54 $1.40 - + Add to cart
20	LABEL, ULG, INST, PACK Part #: T3930090 Required per assembly: 1 Note: Unleaded fuel US Cal ONLY Not Available
21	HOUSING, WARNING, LIGHTS Part #: T2501183 Required per assembly: 1 Note: Warning lamps 86436 >, MPH 89490 >, KPH Not Available
21	HOUSING, WARNING, LIGHTS Part #: T2502084 Required per assembly: 1 Note: Warning lamps > 86435, MPH > 89489, KPH Not Available
22	LENS, WARNING, LIGHTS Part #: T2502081 Required per assembly: 1 Note: > 86435, MPH > 89489, KPH - PART NO LONGER AVAILABLE $10.00 $9.83 - + Add to cart
22	BLOCK, CHAIN, AD Part #: T2501182 Required per assembly: 1 Note: 86436 >, MPH 89490 >, KPH $11.53 $11.32 - + Add to cart
23	GASKET, COVER, WARNING, LIGHTS Part #: T2501181 Required per assembly: 1 Note: 86436 >, MPH 89490 >, KPH Not Available
23	FOAM GASKET Part #: T2502082 Required per assembly: 1 Note: > 86435, MPH > 89489, KPH Not Available
24	COVER, WARNING, LIGHTS Part #: T2502102 Required per assembly: 1 Note: > 86435, MPH > 89489, KPH Not Available
24	COVER, WARNING, LIGHTS Part #: T2501180 Required per assembly: 1 Note: 86436 >, MPH 89490 >, KPH Not Available
25	GASKET, RUBBER, INST, TO, BRKT Part #: T2501176 Required per assembly: 2 Note: > 86435, MPH > 89489, KPH $10.00 $9.83 - + Add to cart
25	GASKET, RUBBER, INST, TO, BRKT Part #: T2501176 Required per assembly: 2 Note: 86436 >, MPH 89490 >, KPH $10.00 $9.83 - + Add to cart
