Instruments replacement parts for Triumph Rocket 3 GT Black

OEM Parts Triumph Rocket 3 GT Black Instruments

Instruments Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	INSTRUMENT, PACK, TFT, MPH, UK Part #: T2502731 Required per assembly: 1 Note: UK $1,809.64 $1,778.51 - + Add to cart
1	INSTRUMENT, PACK, TFT, MPH, US Part #: T2502732 Required per assembly: 1 Note: US $1,809.64 $1,778.51 - + Add to cart
1	INSTRUMENT, PACK, TFT, KMH, EU Part #: T2502733 Required per assembly: 1 Note: All Except UK, US & JP $1,809.64 $1,778.51 - + Add to cart
1	INSTRUMENT, PACK, TFT, KMH, JP Part #: T2502734 Required per assembly: 1 Note: JP $1,809.64 $1,778.51 - + Add to cart
1	INSTRUMENT, PACK, TFT, KMH, CN Part #: T2504416 Required per assembly: 1 $1,529.63 $1,503.31 - + Add to cart
2	INSTRUMENT MOUNT Part #: T2501797 Required per assembly: 1 $105.56 $103.74 - + Add to cart
3	RISER, INSTRUMENTS Part #: T2502472 Required per assembly: 1 $72.73 $71.47 - + Add to cart
4	BOOT, INSTRUMENTS Part #: T2502683 Required per assembly: 1 $3.34 $3.04 - + Add to cart
5	BOLT, RHHF, M5, X, 10 Part #: T3330894 Required per assembly: 1 $6.79 $6.17 - + Add to cart
6	GROMMET, INSTRUMENTS Part #: T3020056 Required per assembly: 3 $3.57 $3.24 - + Add to cart
7	WASHER, 6.5, X, 20, X, 2 Part #: T3555011 Required per assembly: 2 $0.98 $0.89 - + Add to cart
8	SCREW, BUT/HD, TX, M5, X, 16, SLV Part #: T3330289 Required per assembly: 2 $2.05 $1.86 - + Add to cart
9	SCREW, PAN/HD, TX, M5, X, 16, SLV Part #: T3330842 Required per assembly: 2 $2.24 $2.04 - + Add to cart
10	CLAMP, INSTRUMENTS Part #: T2501801 Required per assembly: 1 $51.93 $51.03 - + Add to cart
11	SCREW, CAP/HD, M6X1.0X25, SLV Part #: T3050333 Required per assembly: 2 $7.77 $7.06 - + Add to cart
12	FRICTION, RING, POM, INSTRUMENTS Part #: T2503665 Required per assembly: 2 $32.58 $32.01 - + Add to cart
13	WIRE GUIDE Part #: T2502697 Required per assembly: 1 $20.06 $19.70 - + Add to cart
14	SCREW, TX, PAN/HD, M6X1.0X16, SLV Part #: T3330334 Required per assembly: 2 $2.68 $2.43 - + Add to cart
15	PIN, FLANGED, 12MM Part #: T2501873 Required per assembly: 2 $4.29 $3.90 - + Add to cart
16	BEARING, POLYMER, FLGD, 12MM, ID Part #: T2501874 Required per assembly: 2 $1.66 $1.51 - + Add to cart
17	SCREW, SKT, CSK, M6X25, SLV Part #: T3331196 Required per assembly: 2 $4.20 $3.82 - + Add to cart
18	BOLT, RHHF, M5, X, 10 Part #: T3330894 Required per assembly: 1 $6.79 $6.17 - + Add to cart
