Engine Covers replacement parts for Triumph Rocket III, Classic & Roadster

OEM Parts Triumph Rocket III, Classic & Roadster Engine Covers

Engine Covers Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	COVER, CLUTCH, ASSEMBLY, BLACK Part #: T1260193 Required per assembly: 1 Note: Eng No 242555 > $350.35 $344.31 - + Add to cart
1	CLUTCH, COVR, ASSEMBLY Part #: T1260108 Required per assembly: 1 Note: > Eng No 242554 Not Available
2	COVER, OUTER, CLUTCH, COVER Part #: T1260066 Required per assembly: 1 Note: > Eng No 554422 $62.36 $61.28 - + Add to cart
2	COVER, OUTER, CLUTCH, COVER Part #: T1264455 Required per assembly: 1 Note: Eng No 554423 > $62.36 $61.28 - + Add to cart
3	GASKET, CLUTCH, COVER, OUTER Part #: T1260203 Required per assembly: 1 $11.98 $11.76 - + Add to cart
4	GROMMET; 13310 Part #: T3020153 Required per assembly: 3 $1.94 $1.77 - + Add to cart
5	FLANGED, SLEEVE, M6X10X8.5 Part #: T3010702 Required per assembly: 3 $5.90 $5.36 - + Add to cart
6	SCREW, BUT/HD, M6X1.0X20, SLV Part #: T3330727 Required per assembly: 3 $3.46 $3.15 - + Add to cart
7	DOWEL 6 X 16 Part #: T3000005 Required per assembly: 7 $1.15 $1.05 - + Add to cart
8	BOLT, HHF, LGHTD, M6X1.0X30, SLV Part #: T3205070 Required per assembly: 24 Note: 449911 > $2.43 $2.21 - + Add to cart
8	BOLT, RHHF, DOMED, S/LESS, M6X30 Part #: T3203030 Required per assembly: 24 Note: > 449910 $3.57 $3.24 - + Add to cart
9	GASKET, CLUTCH, COVER Part #: T1260107 Required per assembly: 1 $12.65 $12.43 - + Add to cart
10	PLUG, M45, X, 1.5, BLACK Part #: T1261223 Required per assembly: 1 $30.09 $29.56 - + Add to cart
11	'O'RING, 48IDX3.5 Part #: T3600222 Required per assembly: 1 $9.72 $9.54 - + Add to cart
12	SCREW, CAP/HD, M6X1X12, ENC, RAW Part #: T3051062 Required per assembly: 3 $1.40 $1.27 - + Add to cart
13	COVER, ALTERNATOR, ASSEMBLY Part #: T1260113 Required per assembly: 1 Note: > Eng No 242554 Not Available
13	COVER, ALTERNATOR, ASSEMBLY, BLACK Part #: T1260232 Required per assembly: 1 Note: Eng No 242555 > $189.69 $186.41 - + Add to cart
14	SPIGOT, OD, 14.0MM Part #: T1160268 Required per assembly: 1 $5.90 $5.36 - + Add to cart
15	GASKET, ALTERNATOR, COVER Part #: T1260119 Required per assembly: 1 $13.90 $13.65 - + Add to cart
16	BOLT, RHHF, DOMED, S/LESS, M6X65 Part #: T3203065 Required per assembly: 6 Note: > 516713 $3.85 $3.50 - + Add to cart
16	BOLT, RHHF, DOMED, S/LESS, M6X75 Part #: T3203075 Required per assembly: 6 Note: 516714 > PART NO LONGER AVAILABLE Not Available
17	CVR, O/P, SHAFT, PAINTE Part #: T1260441 Required per assembly: 1 Note: > Eng No 242554 $123.05 $120.93 - + Add to cart
17	COVER, O/P, SHAFT, PAINTED, BLACK Part #: T1260442 Required per assembly: 1 Note: Eng No 242555 > 574812 $123.05 $120.93 - + Add to cart
17	COVER, O/P, SHAFT, PAINTED, BLACK Part #: T1260442 Required per assembly: 1 Note: Roadster Only $123.05 $120.93 - + Add to cart
18	SEAL, OIL, 40, 62, 6, CLOCKWISE Part #: T3600068 Required per assembly: 1 $10.59 $10.40 - + Add to cart
19	GASKET, OUTPUT, SHAFT, COVER Part #: T1260184 Required per assembly: 1 $15.90 $15.62 - + Add to cart
20	BOLT, HHF, M8X1.25X35, SLV Part #: T3202319 Required per assembly: 9 $2.68 $2.43 - + Add to cart
21	PLATE, RETAINER, BEARING Part #: T1260222 Required per assembly: 1 $7.87 $7.16 - + Add to cart
22	LIFTER, ARM, CLUTCH Part #: T1172039 Required per assembly: 1 Note: > 574812 $72.65 $71.40 - + Add to cart
22	LIFTER, ARM, CLUTCH Part #: T1172039 Required per assembly: 1 Note: 574813 > $72.65 $71.40 - + Add to cart
23	BOLT, HHF, LGHTD, M6X1.0X25, SLV Part #: T3205067 Required per assembly: 1 Note: Eng No 472436 > $2.50 $2.27 - + Add to cart
23	BOLT, RHHF, DOMED, M6X1.0X25, S/S Part #: T3203025 Required per assembly: 1 Note: > Eng No 472435 $2.13 $1.94 - + Add to cart
24	BRACKET/HOLDER, CLUTCH, CABLE Part #: T1172034 Required per assembly: 1 Note: 574813 > $7.07 $6.43 - + Add to cart
24	BRACKET/HOLDER, CLUTCH, CABLE Part #: T1170034 Required per assembly: 1 Note: > 574812 $7.07 $6.43 - + Add to cart
25	LIFTER, SHAFT, CLUTCH Part #: T1170041 Required per assembly: 1 $67.52 $66.35 - + Add to cart
26	RETURN SPRING Part #: T1170032 Required per assembly: 1 $2.90 $2.64 - + Add to cart
27	BOLT, HHF, LGHTD, M6X1.0X28, SLV Part #: T3205083 Required per assembly: 8 Note: > Eng No 572659 $2.52 $2.29 - + Add to cart
27	BOLT, HHF, LGHTD, M6X1.0X28, SLV Part #: T3205083 Required per assembly: 8 Note: Eng No 572660 > $2.52 $2.29 - + Add to cart
28	BEARING Part #: T3800110 Required per assembly: 2 $6.79 $6.17 - + Add to cart
29	DUST, SEAL, 12X18X4.5 Part #: T3600095 Required per assembly: 1 $2.29 $2.08 - + Add to cart
