Electrical / Indicator Relocation Kit, Multifunction replacement parts for Triumph Scrambler 1200 XE AC8499 >

OEM Parts Triumph Scrambler 1200 XE AC8499 > Electrical / Indicator Relocation Kit, Multifunction

Electrical / Indicator Relocation Kit, Multifunction Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	INDICATOR, RELOCATION, KIT, MULTIFUNCTION Part #: A9701331 Required per assembly: 1 Note: Market restrictions apply N/A for CA. Not compatible with A9700145. Also requires A9838023 and A9830140 or A9838048 and A9838056 $130.00 $127.76 - + Add to cart
