OEM Parts Triumph Speed Triple 141872 > 210444 Instruments

Triumph Speed Triple 141872 > 210444 VIN between 141872 and 210444 - Instruments

Instruments Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

INSTRUMENT ASSEMBLY

Part #: T2502017 Required per assembly: 1
Not Available
2

HOUSING, UPPER

Part #: T2502055 Required per assembly: 1 Note: Upper
$74.37
$73.09
-
+
Add to cart
3

HOUSING, LOWER

Part #: T2502056 Required per assembly: 1 Note: Lower - PART NO LONGER AVAILABLE
Not Available
4

BULB ASSEMBLY

Part #: T2502057 Required per assembly: 2
Not Available
5

BULB, WARNING, LIGHTS

Part #: T2502058 Required per assembly: 4 Note: Warning light
Not Available
6

SCREW, SELF, TAPPING

Part #: T3331812 Required per assembly: 5
Not Available
7

SCREW, HHF, 50X16, SLV

Part #: T3331414 Required per assembly: 3
$1.54
$1.40
-
+
Add to cart
8

WASHER M5X15X1.6

Part #: T3551178 Required per assembly: 3
$0.98
$0.89
-
+
Add to cart
9

GROMMET, INSTRUMENTS

Part #: T3020097 Required per assembly: 3
$2.05
$1.86
-
+
Add to cart
10

COVER, INSTRUMENTS, FINISHER

Part #: T2502028 Required per assembly: 1 Note: All except DE,ES,FR,IT,JP,NL,NZ,SE,UK & US - All VINS DE,ES,FR,IT,JP,NL,NZ,SE,UK & US >186150
$37.25
$11.85
-
+
Add to cart
11

BOLT, HHF, LGHTD, M6, X, 16, SLV

Part #: T3205063 Required per assembly: 2
$3.57
$3.24
-
+
Add to cart
12

WASHER, 6.4, X, 14, X, 1.6

Part #: T3555004 Required per assembly: 2 Note: All except DE,ES,FR,IT,JP,NL,NZ,SE,UK & US - All VINS DE,ES,FR,IT,JP,NL,NZ,SE,UK & US >186150
$1.42
$1.29
-
+
Add to cart
