Instruments replacement parts for Triumph Speed Triple (Carbs)

OEM Parts Triumph Speed Triple (Carbs) Instruments

Instruments Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	INSTRUMENT, ASSEMBLY, T309RP, (KPH) Part #: T2501105 Required per assembly: 1 Note: KPH Not Available
1	INSTRUMENT, ASSEMBLY, T309RP, (MPH) Part #: T2501100 Required per assembly: 1 Note: MPH Not Available
2	BULB, INSTRUMENTS, 2.0, W Part #: T2500098 Required per assembly: 4 Note: 2.0 watt Speedo, Tacho gauges $5.72 $5.20 - + Add to cart
3	BULB, INSTRUMENTS, 1.7W Part #: T2500097 Required per assembly: 6 Note: 1.2 watt Warning lamps $4.95 $4.50 - + Add to cart
4	WASHER, M5, CSK Part #: T3550265 Required per assembly: 2 $4.29 $3.90 - + Add to cart
5	SCREW, M5, X, 30, CSK, SKT, ENC Part #: T3331643 Required per assembly: 2 $2.05 $1.86 - + Add to cart
6	SPEEDO T309 RP (KPH) Part #: T2502001 Required per assembly: 1 Not Available
6	SPEEDO T309RP MPH Part #: T2502000 Required per assembly: 1 Not Available
7	TACHOMETER, T309, RP Part #: T2502010 Required per assembly: 1 Not Available
8	FACE, PLATE, TELL, TALE, LAMPS Part #: T2502070 Required per assembly: 1 Note: Warning lamps Not Available
9	SCREW, TELL, TALE, LAMPS, COVER Part #: T2502063 Required per assembly: 2 Not Available
10	MOUNTING, PLATE, BLACK Part #: T2502060 Required per assembly: 1 $35.54 $11.29 - + Add to cart
11	SPEEDO, CAN, BLACK Part #: T2502015 Required per assembly: 1 $78.63 $77.26 - + Add to cart
12	TACHO, CAN, BLACK Part #: T2502020 Required per assembly: 1 Not Available
13	SPEEDO, END, PLATE, CHROME Part #: T2502025 Required per assembly: 1 Note: PART NO LONGER AVAILABLE Not Available
14	TACHO, END, PLATE, CHROME Part #: T2502030 Required per assembly: 1 Not Available
15	NUT, END, PLATE Part #: T2502033 Required per assembly: 2 Not Available
16	WASHER, END, PLATE Part #: T2502035 Required per assembly: 2 Not Available
17	SUB HARNESS COMPLETE Part #: T2502040 Required per assembly: 1 Not Available
18	SPEEDO TRIP KNOB Part #: T2502050 Required per assembly: 1 Not Available
19	SCREW, RESET, KNOB Part #: T2501205 Required per assembly: 1 $1.42 $1.29 - + Add to cart
20	COVER, TELL, TALE, LAMPS Part #: T2501184 Required per assembly: 1 $9.45 $9.28 - + Add to cart
21	SCREW, FACE, PLATE Part #: T2502073 Required per assembly: 3 Not Available
22	LABEL, ULG, INST, PACK Part #: T3930090 Required per assembly: 1 Note: Unleaded fuel US CAL Not Available
23	HOUSING, WARNING, LIGHTS Part #: T2502080 Required per assembly: 1 Not Available
25	FOAM GASKET Part #: T2502082 Required per assembly: 1 Not Available
26	COVER, WARNING, LIGHTS Part #: T2502083 Required per assembly: 1 $21.00 $6.68 - + Add to cart
27	RUBBER, GASKET, INSTS.TO, BRKT Part #: T2502061 Required per assembly: 2 Not Available
