Bodywork - Lower Fairings replacement parts for Triumph Sprint ST

OEM Parts Triumph Sprint ST > 139276 Bodywork - Lower Fairings

Bodywork - Lower Fairings Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FAIRING, SIDEPANEL, LH, BLK Part #: T2301900PG Required per assembly: 1 Note: Jet Black Not Available
1	SIDE, PANEL, LH, SAPPHIRE, BLUE Part #: T2301900JM Required per assembly: 1 Note: Sapphire Blue Not Available
1	SIDEPANEL, LH, PNT, DEC, LAQ, DKG Part #: T2301900HA Required per assembly: 1 Note: British Racing Green Not Available
1	FAIRING, SIDEPANEL, LH, RED Part #: T2301900CM Required per assembly: 1 Note: Tornado Red Not Available
2	FAIRING, SIDEPANEL, RH, BLK Part #: T2301901PG Required per assembly: 1 Note: Jet Black Not Available
2	SIDE, PANEL, RH, SAPPHIRE, BLUE Part #: T2301901JM Required per assembly: 1 Note: Sapphire Blue Not Available
2	SIDEPANEL, RH, PNT, DEC, LAQ, DKG Part #: T2301901HA Required per assembly: 1 Note: British Racing Green Not Available
2	FAIRING, SIDEPANEL, RH, RED Part #: T2301901CM Required per assembly: 1 Note: Tornado Red Not Available
3	PAD, FOAM, FAIRING, LH Part #: T2301800 Required per assembly: 1 Note: LH ~~$21.22~~ $6.74 - + Add to cart
4	PAD, FOAM, FAIRING, RH Part #: T2301801 Required per assembly: 1 Note: RH ~~$12.71~~ $12.49 - + Add to cart
5	PAD, FOAM., FAIRING, LH Part #: T2301802 Required per assembly: 1 Note: LH Not Available
6	PAD, FOAM, FAIRING, RH Part #: T2301803 Required per assembly: 1 Note: RH ~~$21.22~~ $6.74 - + Add to cart
7	BRKT, FAIRING, FRAME, FRONT Part #: T2301771 Required per assembly: 2 ~~$4.91~~ $1.56 - + Add to cart
8	BRACKET, FAIRING, LH, FRAME Part #: T2301776 Required per assembly: 1 ~~$4.91~~ $1.56 - + Add to cart
9	BRACKET, FAIRING, RH, FRAME Part #: T2301777 Required per assembly: 1 ~~$5.84~~ $5.31 - + Add to cart
10	NUT, CAPTIVE, M, 4-5.5MM Part #: T3351052 Required per assembly: 17 ~~$4.58~~ $4.17 - + Add to cart
11	BOLT, HHF, LGHTD, M6, X, 16, SLV Part #: T3205063 Required per assembly: 4 ~~$3.67~~ $3.34 - + Add to cart
12	SCREW, BUT/HD, M6X1.0X20, SLV Part #: T3330727 Required per assembly: 2 Note: > 80391 ~~$3.57~~ $3.24 - + Add to cart
12	SCREW, BUT/HD, M5X0.8X16, SLV Part #: T3330941 Required per assembly: 2 Note: 80392 > ~~$7.09~~ $6.44 - + Add to cart
13	FLANGED, SLEEVE, M6X10X8.5 Part #: T3010702 Required per assembly: 6 ~~$6.07~~ $5.52 - + Add to cart
14	GROMMET; 13310 Part #: T3020153 Required per assembly: 6 ~~$2.01~~ $1.83 - + Add to cart
15	SCREW, BUT/HD, M6X1.0X20, SLV Part #: T3330727 Required per assembly: 6 ~~$3.57~~ $3.24 - + Add to cart
16	SCREW, BUT/HD, M5X0.8X16, SLV Part #: T3330941 Required per assembly: 9 ~~$7.09~~ $6.44 - + Add to cart
17	WASHER, NYLON Part #: T3555555 Required per assembly: 13 ~~$1.70~~ $1.54 - + Add to cart
18	NUT, CAPTIVE, M6 Part #: T3350111 Required per assembly: 4 ~~$5.18~~ $4.71 - + Add to cart
19	INFILL, RAD, TO, FAIRING, LH Part #: T2301766 Required per assembly: 1 Note: LH ~~$16.06~~ $14.60 - + Add to cart
20	INFILL, RAD, TO, FAIRING, RH Part #: T2301767 Required per assembly: 1 Note: RH ~~$26.58~~ $24.17 - + Add to cart
21	SCREW, BUT/HD, M5X0.8X16, SLV Part #: T3330941 Required per assembly: 6 ~~$7.09~~ $6.44 - + Add to cart
22	BELLYPAN, LH, BLK Part #: T2301912PG Required per assembly: 1 Note: Jet Black Not Available
22	BELLYPAN, LH, SAPPHIRE, BLUE Part #: T2301912JM Required per assembly: 1 Note: Sapphire Blue Not Available
22	BELLYPAN, LH.PNT, LAQ, DKG Part #: T2301912HA Required per assembly: 1 Note: British Racing Green Not Available
22	BELLYPAN, LH, RED Part #: T2301912CM Required per assembly: 1 Note: Tornado Red Not Available
23	BELLYPAN, RH, BLK Part #: T2301913PG Required per assembly: 1 Note: Jet Black Not Available
23	BELLYPAN, RH, SAPPHIRE, BLUE Part #: T2301913JM Required per assembly: 1 Note: Sapphire Blue Not Available
23	BELLYPAN, RH, PNT, LAQ, DKG Part #: T2301913HA Required per assembly: 1 Note: British Racing Green Not Available
23	BELLYPAN, RH, RED Part #: T2301913CM Required per assembly: 1 Note: Tornado Red Not Available
24	SCREW, BUT/HD, M8X1.25X12, SLV Part #: T3331625 Required per assembly: 2 ~~$1.82~~ $1.65 - + Add to cart
25	PAD, HEAT, BELLYPAN, RH Part #: T2301804 Required per assembly: 1 Not Available
26	PAD, HEAT, BELLYPAN, LH Part #: T2301805 Required per assembly: 1 Not Available
27	BRACKET, BELLYPAN, LH, FRONT Part #: T2301773 Required per assembly: 1 Not Available
28	BRACKET, ASSEMBLY, OIL, COOLER/BELLY Part #: T2301778 Required per assembly: 1 Not Available
29	BRACKET, BELLYPAN, LH, REAR Part #: T2301772 Required per assembly: 1 ~~$4.18~~ $3.80 - + Add to cart
30	BRACKET, BELLYPAN, RH, REAR Part #: T2301774 Required per assembly: 1 ~~$5.92~~ $1.88 - + Add to cart
