OEM Parts Triumph Street Triple RS 966534 > Instruments

Triumph Street Triple RS 966534 > VIN 966534 and up - Instruments

Instruments Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

INSTRUMENT, PACK, TFT, MPH, UK

Part #: T2503601 Required per assembly: 1 Note: UK
$1,499.64
$1,473.84
-
+
Add to cart
1

INSTRUMENT, PACK, TFT, MPH, US

Part #: T2503602 Required per assembly: 1 Note: US
$1,499.64
$1,473.84
-
+
Add to cart
1

INSTRUMENT, PACK, TFT, KMH, EU

Part #: T2503603 Required per assembly: 1 Note: All Except UK, US, CA & JP
$1,499.64
$1,473.84
-
+
Add to cart
1

INSTRUMENT, PACK, TFT, KMH, JP

Part #: T2503604 Required per assembly: 1 Note: JP
$1,499.64
$1,473.84
-
+
Add to cart
1

INSTRUMENT, PACK, TFT, KMH, CA

Part #: T2503605 Required per assembly: 1 Note: CA
$1,499.64
$1,473.84
-
+
Add to cart
2

TFT, INSTRUMENT, CRADLE, MLGD

Part #: T2502243 Required per assembly: 1
$44.89
$44.11
-
+
Add to cart
3

HINGE, ASSEMBLY, FRICTION

Part #: T2306464 Required per assembly: 1
$63.24
$62.14
-
+
Add to cart
4

GROMMET, INSTRUMENTS

Part #: T3020056 Required per assembly: 3
$3.57
$3.24
-
+
Add to cart
5

WASHER, 6.5, X, 20, X, 2

Part #: T3555011 Required per assembly: 3
$0.98
$0.89
-
+
Add to cart
6

BOLT, RHHF, M5, X, 10

Part #: T3330894 Required per assembly: 3
$6.79
$6.17
-
+
Add to cart
7

HINGE, MOUNT, PLATE

Part #: T2702889 Required per assembly: 1
$3.01
$2.74
-
+
Add to cart
8

STUD, M5, X, 18, SLV

Part #: T3100105 Required per assembly: 2
$2.20
$2.00
-
+
Add to cart
9

SCREW, BUT/HD, M5, X, 16, BLK

Part #: T3330945 Required per assembly: 2
$8.64
$7.86
-
+
Add to cart
10

LOCKNUT M5

Part #: T3350010 Required per assembly: 4
$2.29
$2.08
-
+
Add to cart
