Engine Covers replacement parts for Triumph Street Triple RS

OEM Parts Triumph Street Triple RS Engine Covers

Engine Covers Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	CLUTCH, COVER, CRINKLE, BLACK Part #: T1265491 Required per assembly: 1 $301.12 $295.93 - + Add to cart
2	DUST, SEAL, 12X18X4.5 Part #: T3600095 Required per assembly: 1 $2.29 $2.08 - + Add to cart
3	BEARING Part #: T3800110 Required per assembly: 2 $6.79 $6.17 - + Add to cart
4	GASKET, CLUTCH, COVER Part #: T1260258 Required per assembly: 1 $18.86 $18.52 - + Add to cart
5	DOWEL 6 X 16 Part #: T3000005 Required per assembly: 6 $1.15 $1.05 - + Add to cart
6	OIL FILLER CAP Part #: T1260249 Required per assembly: 1 $19.22 $18.88 - + Add to cart
7	O-RING, ID, 19X3.0 Part #: T3600163 Required per assembly: 1 $10.62 $10.43 - + Add to cart
8	BOLT, HHF, LGHTD, M6X1.0X25, SLV Part #: T3205067 Required per assembly: 35 $2.50 $2.27 - + Add to cart
9	WASHER, 6.4, X, 11.5, X, 1.0, COPP Part #: T3550146 Required per assembly: 1 $1.42 $1.29 - + Add to cart
10	COVER, SPROCKET Part #: T1261269 Required per assembly: 1 $95.71 $94.06 - + Add to cart
11	BREATHER COVER Part #: T1260824 Required per assembly: 1 $78.63 $77.26 - + Add to cart
12	BREATHER COVER GASKET Part #: T1260825 Required per assembly: 1 $23.51 $23.10 - + Add to cart
13	BRACKET, QUICKSHIFTER, CONNECTOR Part #: T2505456 Required per assembly: 1 $13.61 $13.37 - + Add to cart
14	ALTERNATOR COVER Part #: T1265492 Required per assembly: 1 $169.28 $166.37 - + Add to cart
15	GASKET, ALTERNATOR, COVER Part #: T1260838 Required per assembly: 1 $30.77 $30.24 - + Add to cart
16	BRACKET, CABLE, GUIDE, ACG, STATOR Part #: T1260365 Required per assembly: 1 $15.61 $15.33 - + Add to cart
17	BRACKET, CABLE, GUIDE, VR, SENSOR Part #: T1260366 Required per assembly: 1 $16.41 $16.12 - + Add to cart
18	SCREW, CAP/HD, M5X0.8X10, SLV, ENC Part #: T3051055 Required per assembly: 3 $3.10 $2.82 - + Add to cart
19	CRANK, COVER, CRINKLE, BLACK Part #: T1265494 Required per assembly: 1 $174.14 $171.14 - + Add to cart
20	CRANK COVER GASKET Part #: T1260437 Required per assembly: 1 $14.79 $14.53 - + Add to cart
21	BALANCER, COVER, CRINKLE, BLACK Part #: T1260517 Required per assembly: 1 $165.76 $162.90 - + Add to cart
22	GASKET, BALANCER, COVER Part #: T1260267 Required per assembly: 1 $9.29 $8.45 - + Add to cart
23	BOLT, RHHF, M6X1X20, SLV Part #: T3205066 Required per assembly: 4 $4.64 $4.21 - + Add to cart
24	TAB, ENGINE, SUB-HARNESS Part #: T2508270 Required per assembly: 1 $9.69 $8.81 - + Add to cart
25	BADGE, FLAT, TYPE, 1 Part #: T3951060 Required per assembly: 2 $11.98 $11.76 - + Add to cart
26	BRACKET, CLUTCH, CABLE Part #: T1170263 Required per assembly: 1 $7.33 $6.66 - + Add to cart
27	BOLT, HHF, LGHTD, M6X1.0X28, SLV Part #: T3205083 Required per assembly: 2 $2.52 $2.29 - + Add to cart
28	BRACKET, SOLENOID, EVAP Part #: T1240645 Required per assembly: 1 $18.09 $17.77 - + Add to cart
29	BRACKET, O2, CONNECTOR, PRIMARY Part #: T2502684 Required per assembly: 1 $10.21 $10.02 - + Add to cart
30	BRACKET, O2, CONNECTOR Part #: T2505488 Required per assembly: 1 $10.21 $10.02 - + Add to cart
