Instruments replacement parts for Triumph Tiger 1200 XCx / Tiger SE Desert

OEM Parts Triumph Tiger 1200 XCx / Tiger SE Desert Instruments

Instruments Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	INSTRUMENT, PACK, TFT, KMH, EU Part #: T2503473 Required per assembly: 1 Note: All Except UK, US & JP ~~$1,890.64~~ $1,816.82 - + Add to cart
1	INSTRUMENT, PACK, TFT, KMH, JP Part #: T2502364 Required per assembly: 1 Note: JP Only ~~$1,901.23~~ $1,826.99 - + Add to cart
1	INSTRUMENT, PACK, TFT, MPH, UK Part #: T2503471 Required per assembly: 1 Note: UK Only ~~$1,890.64~~ $1,816.82 - + Add to cart
1	INSTRUMENT, PACK, TFT, MPH, US Part #: T2503472 Required per assembly: 1 Note: US Only ~~$1,890.64~~ $1,816.82 - + Add to cart
2	INSTRUMENT, MOUNT, MOULDING Part #: T2307141 Required per assembly: 1 ~~$33.53~~ $32.95 - + Add to cart
3	GROMMET, INSTRUMENTS Part #: T3020056 Required per assembly: 3 $4.52 - + Add to cart
4	WASHER, 6.5, X, 20, X, 2 Part #: T3555011 Required per assembly: 3 $1.29 - + Add to cart
5	BOLT, RHHF, M5, X, 10 Part #: T3330894 Required per assembly: 3 $8.31 - + Add to cart
6	HINGE, ASSEMBLY, FRICTION Part #: T2306464 Required per assembly: 1 ~~$65.14~~ $64.02 - + Add to cart
7	LOCKNUT M5 Part #: T3350010 Required per assembly: 4 $2.95 - + Add to cart
8	SCREW, BUT/HD, M5X0.8X16, SLV Part #: T3330941 Required per assembly: 2 $8.40 - + Add to cart
9	BOLT, RHHF, M5, X, 20, ENC Part #: T3330311 Required per assembly: 2 $0.76 - + Add to cart
