Engine Covers replacement parts for Triumph Tiger 1200 XRx / Tiger SE Alpine

OEM Parts Triumph Tiger 1200 XRx / Tiger SE Alpine Engine Covers

Engine Covers Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	CLUTCH, COVER, WET, PAINT Part #: T1260509 Required per assembly: 1 ~~$330.97~~ $325.28 - + Add to cart
2	COVER, SLAVE, CYLINDER Part #: T1261408 Required per assembly: 1 ~~$75.69~~ $74.38 - + Add to cart
3	GASKET, CLUTCH, COVER Part #: T1261430 Required per assembly: 1 $17.16 - + Add to cart
4	DOWEL 6 X 16 Part #: T3000005 Required per assembly: 10 $1.50 - + Add to cart
5	OIL FILLER CAP Part #: T1261053 Required per assembly: 1 $13.52 - + Add to cart
6	O-RING, ID, 19X3.0 Part #: T3600163 Required per assembly: 1 $14.65 - + Add to cart
7	BOLT, HHF, LGHTD, M6X1.0X25, SLV Part #: T3205067 Required per assembly: 17 $3.20 - + Add to cart
8	BOLT, HHF, LGHTD, M6X1.0X28, ENC Part #: T3205081 Required per assembly: 6 $2.00 - + Add to cart
9	BOLT, HHF, LGHTD, M6X1.0X20, ENC Part #: T3205085 Required per assembly: 5 $7.18 - + Add to cart
10	RH, CRANK, COVER, WET, PAINT Part #: T1260573 Required per assembly: 1 ~~$142.58~~ $140.12 - + Add to cart
11	GASKET, RH, CRANK, COVER Part #: T1261431 Required per assembly: 1 $19.22 - + Add to cart
12	BALANCER, COVER, WET, PAINT Part #: T1260556 Required per assembly: 1 ~~$186.59~~ $183.38 - + Add to cart
13	GASKET, BALANCER, COVER Part #: T1260267 Required per assembly: 1 $11.03 - + Add to cart
14	BOLT, RHHF, M6X1X20, SLV Part #: T3205066 Required per assembly: 4 $5.81 - + Add to cart
15	LH, CRANK, COVER, ASSEMBLY, WET, PAINT Part #: T1260528 Required per assembly: 1 ~~$161.95~~ $159.15 - + Add to cart
16	BUSH, 10X12X8 Part #: T1222207 Required per assembly: 1 $7.18 - + Add to cart
17	GASKET, LH, CRANK Part #: T1261433 Required per assembly: 1 $16.39 - + Add to cart
18	BRACKET, EXPANSION, TANK Part #: T2100462 Required per assembly: 1 $14.20 - + Add to cart
19	BOLT, HHF, LGHTD, M6X1.0X28, SLV Part #: T3205083 Required per assembly: 10 $3.23 - + Add to cart
20	BREATHER COVER ASSEMBLY Part #: T1262201 Required per assembly: 1 ~~$112.68~~ $110.74 - + Add to cart
21	GASKET, BREATHER, COVER Part #: T1260296 Required per assembly: 1 $24.75 - + Add to cart
22	BOLT RHHF DOMED S/S M6 X 16 Part #: T3205064 Required per assembly: 3 $5.16 - + Add to cart
23	BOLT, HHF, LGHTD, M6X1.0X35, ENC Part #: T3205082 Required per assembly: 4 $3.12 - + Add to cart
24	GEARCHANGE, COVER, WET, PAINT Part #: T1260534 Required per assembly: 1 ~~$140.84~~ $138.41 - + Add to cart
25	GASKET, GEARCHANGE, COVER Part #: T1261426 Required per assembly: 1 $11.53 - + Add to cart
26	SEAL, OIL, 14X22X4.5 Part #: T3600088 Required per assembly: 1 $8.00 - + Add to cart
27	BEARING, NEEDLE, ROLLER, 20X14X12 Part #: T3800001 Required per assembly: 1 $10.49 - + Add to cart
28	BOLT, RHHF, M6X1.0X90.0, SLV Part #: T3202330 Required per assembly: 1 $13.08 - + Add to cart
29	WASHER, CU, OD12.5, ID6.4, 0.8 Part #: T3550542 Required per assembly: 1 $1.40 - + Add to cart
30	SUPRESSION, PAD, CLUTCH Part #: T1262202 Required per assembly: 1 ~~$28.59~~ $28.09 - + Add to cart
