Instruments replacement parts for Triumph Tiger 885 Carbs

OEM Parts Triumph Tiger 885 Carbs > 71698 Instruments

Instruments Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	INSTRU, ASSEMBLY, KPH Part #: T2501056 Required per assembly: 1 Note: > 16921 KPH Not Available
1	INSTRU, ASSEMBLY, KPH Part #: T2501056 Required per assembly: 1 Note: 16922 > KPH Not Available
1	INSTR, ASSEMBLY, MPH Part #: T2501001 Required per assembly: 1 Note: MPH Not Available
2	BULB, INSTRUMENTS, T6.5, 3.0W Part #: T2500090 Required per assembly: Note: T6.5 - 3W Warning lamps $6.26 $5.69 - + Add to cart
3	BULB, INSTRUMENTS, T6.5, 1.7W Part #: 2500085T0301 Required per assembly: 3 Note: T6.5 - 1.7W Instrument illumination $5.74 $5.22 - + Add to cart
4	BULB, INSTRUMENTS, T10, 1.7W Part #: 2500095T0301 Required per assembly: Note: T10 - 1.7W Instrument illumination $6.28 $5.71 - + Add to cart
5	SCREW, TX, PAN/HD, M6X1.0X16, SLV Part #: T3330334 Required per assembly: 2 $2.68 $2.43 - + Add to cart
6	SPEEDO, KPH Part #: 2501055T0301 Required per assembly: 1 Not Available
6	SPEEDO, MPH Part #: 2501053T0301 Required per assembly: 1 Not Available
7	TACHOMETER Part #: 2501051T0301 Required per assembly: 1 $316.20 $310.76 - + Add to cart
8	TEMPERATURE GAUGE Part #: 2500565T0301 Required per assembly: 1 Not Available
9	CLOCK, DIGITAL Part #: 2500022T0301 Required per assembly: 1 Note: Digital $201.69 $198.22 - + Add to cart
10	BULB, INSTRUMENTS, 1.7W Part #: T2500097 Required per assembly: 1 Note: 1.2 watt $4.95 $4.50 - + Add to cart
11	LABEL, ULG, INST, PACK Part #: T3930090 Required per assembly: 1 Note: Unleaded fuel US CAL Not Available
12	WARNING LIGHT PANEL Part #: T2500388 Required per assembly: 1 Note: Part No Longer Available Not Available
13	MOUNTING PLATE Part #: T2500387 Required per assembly: 1 Not Available
14	RUBBER, SEAL, SPEEDO, &TEMP, GAUGE Part #: T2500386 Required per assembly: 1 Note: Speedometer Not Available
15	SUB-HARNESS, WARNING, LIGHTS Part #: T2500384 Required per assembly: 1 Not Available
16	TRIP KNOB Part #: T2500380 Required per assembly: 1 $3.85 $3.50 - + Add to cart
17	SCREW, RESET, KNOB Part #: T2501205 Required per assembly: 1 $1.42 $1.29 - + Add to cart
18	SUB-HARNESS, TEMP, GAUGE Part #: T2500382 Required per assembly: 1 Note: Temperature gauge Not Available
19	SUB-HARNESS, PANEL, ILLUMINATION Part #: T2500383 Required per assembly: 1 Note: Panel illumination Not Available
20	MOUNTING PLATE Part #: T2500387 Required per assembly: 1 Not Available
21	GASKET, WARNING, LIGHT, CLUSTER Part #: T2500389 Required per assembly: 1 Not Available
22	SCREW, ASSEMBLY, INSTRUMENTS Part #: T2500390 Required per assembly: 1 Note: Not illustrated Not Available
23	RUBBER, SEAL, TACHOMETER Part #: T2500385 Required per assembly: 1 Note: Tachometer Not Available
