Instruments replacement parts for Triumph Tiger 900 Rally Pro & Aragon Edition

OEM Parts Triumph Tiger 900 Rally Pro & Aragon Edition Instruments

Instruments Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	INSTRUMENT, PACK, TFT, KMH, CA Part #: T2504955 Required per assembly: 1 Note: CA ~~$1,901.23~~ $1,826.99 - + Add to cart
1	INSTRUMENT, PACK, TFT, KMH, EU Part #: T2504953 Required per assembly: 1 Note: All Markets Except UK, US, JP & CA ~~$1,901.23~~ $1,826.99 - + Add to cart
1	INSTRUMENT, PACK, TFT, KMH, JP Part #: T2504954 Required per assembly: 1 Note: JP ~~$1,901.23~~ $1,826.99 - + Add to cart
1	INSTRUMENT, PACK, TFT, MPH, UK Part #: T2504951 Required per assembly: 1 Note: UK ~~$1,901.23~~ $1,826.99 - + Add to cart
1	INSTRUMENT, PACK, TFT, MPH, US Part #: T2504952 Required per assembly: 1 Note: US ~~$1,901.23~~ $1,826.99 - + Add to cart
2	INSTRUMENT, MOUNT, 7, INCH, MOULDING Part #: T2319110 Required per assembly: 1 ~~$32.89~~ $32.31 - + Add to cart
3	GROMMET, INSTRUMENTS Part #: T3020056 Required per assembly: 4 $4.52 - + Add to cart
4	BOLT, RHHF, M5, X, 10 Part #: T3330894 Required per assembly: 4 $8.31 - + Add to cart
5	WASHER, 6.5, X, 20, X, 2 Part #: T3555011 Required per assembly: 4 $1.29 - + Add to cart
6	BOLT, RHHF, M5X0.8X15, S5041 Part #: T3330892 Required per assembly: 2 $1.50 - + Add to cart
7	SCREW, BUT/HD, M5X0.8X14, SLV Part #: T3330943 Required per assembly: 1 $6.27 - + Add to cart
8	NUT, CAPTIVE, M5 Part #: T3350129 Required per assembly: 1 $4.40 - + Add to cart
