Instruments replacement parts for Triumph Tiger 955i 124106

OEM Parts Triumph Tiger 955i 124106 > 198874 Instruments

Instruments Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	INSTRUMENT, ASSEMBLY, KPH Part #: T2501149 Required per assembly: 1 Note: KPH Not Available
1	INSTRUMENT, ASSEMBLY, MPH Part #: T2501144 Required per assembly: 1 Note: MPH Not Available
2	GAUGE, SPEEDO, KPH Part #: T2504022 Required per assembly: 1 Note: KPH Not Available
2	GAUGE, SPEEDO, MPH Part #: T2504021 Required per assembly: 1 Note: MPH Not Available
3	TACH ASSEMBLY Part #: T2504116 Required per assembly: 1 Not Available
4	GAUGE, TEMPERATURE Part #: T2504204 Required per assembly: 1 Not Available
5	GAUGE, FUEL Part #: T2504255 Required per assembly: 1 $247.81 $243.54 - + Add to cart
6	CLOCK, DIGITAL Part #: T2504351 Required per assembly: 1 Note: Digital Not Available
7	FACIA, INSTRUMENTS Part #: T2502097 Required per assembly: 1 $164.04 $161.21 - + Add to cart
8	RUBBER, SEAL, SPEEDO/TACHO Part #: T2500480 Required per assembly: 2 Not Available
9	RUBBER, SEAL, FUEL/TEMP Part #: T2500481 Required per assembly: 2 Not Available
10	WARNING, LIGHT, UNIT, ASSEMBLY Part #: T2504320 Required per assembly: 1 Not Available
11	BULB, INSTRUMENTS, T6.5, 1.7W Part #: 2500085T0301 Required per assembly: 2 Note: T6.5 - 1.7W Tachometer /Clock $5.74 $5.22 - + Add to cart
12	BULB, INSTRUMENTS, T6.5, 3.0W Part #: T2500090 Required per assembly: 6 Note: T6.5 - 3W Warning lamps $6.26 $5.69 - + Add to cart
13	BULB, INSTRUMENTS, T10, 1.7W Part #: 2500095T0301 Required per assembly: 3 Note: T10 - 1.7W Speedometer/Fuel/Temperature Gauges $6.28 $5.71 - + Add to cart
14	BADGE, OVAL, PLASTIC Part #: T3900450 Required per assembly: 1 $8.71 $7.92 - + Add to cart
15	TRIM, FACIA Part #: T2501139 Required per assembly: 2 Not Available
16	LOCKNUT M6 Part #: T3350012 Required per assembly: 4 $1.15 $1.05 - + Add to cart
17	FLANGED, SLEEVE, M6X10X8.5 Part #: T3010702 Required per assembly: 4 $5.90 $5.36 - + Add to cart
18	GROMMET, DIA, 13.0, X, 1.8, PANEL Part #: T3021100 Required per assembly: 4 $2.90 $2.64 - + Add to cart
19	COVER EXPANSION BOTTLE Part #: T2501138 Required per assembly: 1 Note: PART NO LONGER AVAILABLE Not Available
20	HARNESS, INSTRUMENTS Part #: T2501152 Required per assembly: 1 Not Available
21	GROMMET GAUGES Part #: T2500479 Required per assembly: 8 Not Available
22	WASHER, DIA, 15, X, 1, M5 Part #: T3350057 Required per assembly: 8 $1.75 $1.59 - + Add to cart
23	NUT, M5X0.8 Part #: T3350061 Required per assembly: 8 $1.75 $1.59 - + Add to cart
24	SCREW, CSK, M4X16, SS, BLK Part #: T3330265 Required per assembly: 2 Note: M4 x 16mm $3.46 $3.15 - + Add to cart
25	WASHER, M4, CSK Part #: T3330267 Required per assembly: 2 $6.26 $5.69 - + Add to cart
26	RESET BUTTON Part #: T2501150 Required per assembly: 1 Not Available
27	SCREW, CLOCK, M4X14 Part #: T2500402 Required per assembly: 2 Note: M4 Not Available
28	BLANKING, COVER, HTD, H/BAR Part #: T2300983 Required per assembly: 1 Note: All except DE,ES,IT,JP,NL,SE & UK - All VINS DE,ES,IT,JP,NL,SE & UK >186150 $10.59 $3.36 - + Add to cart
29	P-CLIP, HARNESS, INSTRUMENTS Part #: T2501147 Required per assembly: 1 Not Available
30	SCREW, P-CLIP, HARNESS Part #: T2501148 Required per assembly: 1 Not Available
31	SETTING, BOLT, INSTRUMENT, ASSEMBLY Part #: T2501157 Required per assembly: 1 Not Available
