OEM Parts Triumph Tiger Explorer Sumpguard

Triumph Tiger Explorer - Sumpguard

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

GUARD, SUMP, ALUMINIUM

Part #: T2308015 Required per assembly: 1
Not Available
2

BRACKET, FRONT, GUARD

Part #: T2308377 Required per assembly: 2
$61.50
$60.43
-
+
Add to cart
3

BRACKET, REAR, GUARD

Part #: T2308378 Required per assembly: 2
$61.50
$60.43
-
+
Add to cart
4

SCREW, PAN/HD, TX, M6X1.0X12, ENC

Part #: T3331042 Required per assembly: 4
$1.42
$1.29
-
+
Add to cart
5

SCREW, PANHD, TX, M6X1X20, SLV, ENC

Part #: T3331191 Required per assembly: 8
$2.13
$1.94
-
+
Add to cart
6

GROMMET; 13*3*10

Part #: T3020153 Required per assembly: 8
$1.94
$1.77
-
+
Add to cart
7

FLANGED, SLEEVE, M6X10X8.5

Part #: T3010702 Required per assembly: 8
$5.90
$5.36
-
+
Add to cart
8

NUT, M6X1.0, SLV

Part #: T3350300 Required per assembly: 8
$0.94
$0.86
-
+
Add to cart
