Engine Management System replacement parts for Triumph Tiger XRT

OEM Parts Triumph Tiger XRT Engine Management System

Engine Management System Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	ECM BASE Part #: T1299335 Required per assembly: 1 Note: > 761795 - All Except BR $2,256.04 $2,217.23 - + Add to cart
1	ECM BASE Part #: T1299335 Required per assembly: 1 Note: BR Only $2,256.04 $2,217.23 - + Add to cart
1	ECM BASE Part #: T1291234 Required per assembly: 1 Note: 761796 > - All Except BR $1,034.01 $1,016.22 - + Add to cart
2	COIL, IGNITION, 1.4OHM Part #: T1291503 Required per assembly: 3 $176.03 $172.99 - + Add to cart
3	SPARK, PLUG, CR9EK Part #: T1290023 Required per assembly: 3 $18.38 $16.71 - + Add to cart
4	SENSOR, AIR, TEMPERATURE Part #: T1290088 Required per assembly: 1 $58.20 $57.20 - + Add to cart
5	SENSOR, AIR, PRESSURE Part #: T1290975 Required per assembly: 1 $129.89 $127.64 - + Add to cart
6	BOLT, HHF, LGHTD, M6X1.0X25, SLV Part #: T3205067 Required per assembly: 1 $2.50 $2.27 - + Add to cart
7	SENSOR, AIR, PRESSURE Part #: T1290975 Required per assembly: 1 $129.89 $127.64 - + Add to cart
8	SCREW, S/TAP, HHF, 5X25.0 Part #: T3332464 Required per assembly: 2 $2.20 $2.00 - + Add to cart
9	GEAR POSITION SENSOR Part #: T1290660 Required per assembly: 1 $107.66 $105.79 - + Add to cart
10	BOLT, RHHF, M6X1X20, SLV Part #: T3205066 Required per assembly: 2 $4.64 $4.21 - + Add to cart
11	O-RING, 26.65IDX2.62DIA Part #: T3600267 Required per assembly: 2 $1.54 $1.40 - + Add to cart
14	BOLT RHHF DOMED S/S M6 X 16 Part #: T3205064 Required per assembly: 1 $4.09 $3.72 - + Add to cart
15	SENSOR, ENGINE, COOLANT Part #: T2100808 Required per assembly: 1 $48.56 $47.72 - + Add to cart
16	WASHER, COPPER Part #: T3550571 Required per assembly: 1 $5.18 $4.71 - + Add to cart
17	HOSE, THROTTLE, BODY, CYL1 Part #: T1292075 Required per assembly: 1 $3.31 $3.01 - + Add to cart
18	HOSE, THROTTLE, BODY, CYL2 Part #: T1292076 Required per assembly: 1 $3.31 $3.01 - + Add to cart
19	HOSE, THROTTLE, BODY, CYL3 Part #: T1292077 Required per assembly: 1 $3.31 $3.01 - + Add to cart
20	HOSE, MAP, SENSOR Part #: T1290136 Required per assembly: 1 $10.76 $10.57 - + Add to cart
21	CONNECTOR, 4-WAY Part #: T1242929 Required per assembly: 1 $9.81 $9.63 - + Add to cart
22	HOSE GUIDE Part #: T3700254 Required per assembly: 1 $6.68 $6.08 - + Add to cart
23	CLIP, 10.5, GER, OETIKER Part #: T3700077 Required per assembly: 1 $4.09 $3.72 - + Add to cart
24	VR, SENSOR, IGNITION, V-GROMMET Part #: T1290139 Required per assembly: 1 $100.81 $99.07 - + Add to cart
25	BRACKET, CABLE, GUIDE, VR, SENSOR Part #: T1290148 Required per assembly: 1 $15.38 $15.10 - + Add to cart
26	BRACKET, CABLE, GUIDE, VR, SENSOR Part #: T1290147 Required per assembly: 1 $15.38 $15.10 - + Add to cart
27	BOLT, HHF, M5, X, 12, ENCAP Part #: T3330178 Required per assembly: 3 $5.42 $4.93 - + Add to cart
28	PLUG, BLANKING, RD, SPD, SENSOR Part #: T1164500 Required per assembly: 1 $2.59 $2.35 - + Add to cart
29	O-RING, ID, 14.6, SD, 2.4 Part #: T3600085 Required per assembly: 1 $4.09 $3.72 - + Add to cart
30	TWIN, CLIP, BRAKE, HOSE Part #: T2040811 Required per assembly: 2 $2.68 $2.43 - + Add to cart
31	FLYLEAD, GEAR, POSITION, SENSOR Part #: T2509323 Required per assembly: 1 $19.55 $19.20 - + Add to cart
