Ignition Switch & Lock Set replacement parts for Triumph Tiger XRT

OEM Parts Triumph Tiger XRT Ignition Switch & Lock Set

Ignition Switch & Lock Set Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	LOCK SET Part #: T2508200 Required per assembly: 1 Note: Includes 2 keys ~~$748.17~~ $735.30 - + Add to cart
2	IGNITION, LOCK, COMBINED Part #: T2508201 Required per assembly: 1 Note: Includes 2 keys ~~$286.96~~ $282.02 - + Add to cart
3	KEY, BLANK, IMMOBILISER Part #: T2504578 Required per assembly: 2 Note: Supplied as single ~~$66.90~~ $65.74 - + Add to cart
3	KEY, CUT, IMMOBILISER Part #: T2504577 Required per assembly: 1 Note: Supplied as pair ~~$73.17~~ $71.91 - + Add to cart
4	LOCK BARREL KIT Part #: T2509880 Required per assembly: 1 Note: Triumph OEM replacement lock barrel kit for luggage panniers. This kit consists of 3 barrels and two keys. Please note the keys will not be fitted for your ignition only the replacement barrels. Includes Keys ~~$72.10~~ $70.85 - + Add to cart
5	FILLER, CAP, ASSEMBLY, FUEL, TANK Part #: T2401242 Required per assembly: 1 Note: Includes 2 keys ~~$197.17~~ $193.78 - + Add to cart
6	SEAL, FILLER, CAP, BREATHER Part #: T2500622 Required per assembly: 1 ~~$6.46~~ $5.87 - + Add to cart
7	LOCK, ASS, SEAT Part #: T2505440 Required per assembly: 1 Note: Includes 2 keys ~~$130.27~~ $128.02 - + Add to cart
8	CABLE, SEAT, LOCK Part #: T2505490 Required per assembly: 1 ~~$24.22~~ $23.80 - + Add to cart
9	SEAT LATCH HOUSING Part #: T2500506 Required per assembly: 1 ~~$30.57~~ $30.04 - + Add to cart
10	SCREW, C/SUNK, TX, M6X1.0X25, SLV Part #: T3330184 Required per assembly: 2 ~~$1.33~~ $1.21 - + Add to cart
11	RIVET 4.8 * 16.3 GRIP Part #: T3300062 Required per assembly: 2 ~~$2.36~~ $2.15 - + Add to cart
12	WASHER, 11, X, 5.1, X, 1.6 Part #: T3550289 Required per assembly: 2 ~~$2.36~~ $2.15 - + Add to cart
13	BOLT, SHEAR, M6, X, 22, ENC Part #: T3330327 Required per assembly: 2 ~~$5.51~~ $5.01 - + Add to cart
14	SCREW, CAP/HD, M5X0.8X30, SLV Part #: T3050343 Required per assembly: 3 ~~$4.67~~ $4.25 - + Add to cart
15	SCREW, CAP/HD, M5X0.8X16, SLV Part #: T3050342 Required per assembly: 1 ~~$2.99~~ $2.72 - + Add to cart
16	SCREW, CAP, /, HD, M5, X, 10, SILVER Part #: T3050341 Required per assembly: 3 Note: 459486 > ~~$3.99~~ $3.63 - + Add to cart
17	IMMOBILISER, ECU, WITH, RF, 434 Part #: T2504061 Required per assembly: 1 Note: All Except JP, BR & IN - 939361 >; BR & IN Only - 939540 > ~~$1,452.32~~ $1,427.33 - + Add to cart
17	IMMOBILISER, ECU, WITH, RF, 315 Part #: T2504071 Required per assembly: 1 Note: JP Only - 940098 > ~~$1,452.32~~ $1,427.33 - + Add to cart
17	IMMOBILISER, KIT, RE, 434, FLGD, SLEEVE Part #: T2506024 Required per assembly: 1 Note: All Except JP, BR & IN > 939360; BR & IN Only > 939539 ~~$1,416.22~~ $1,391.86 - + Add to cart
17	IMMOBILISER, KIT, RF, 315, FLGD, SLEEVE Part #: T2506027 Required per assembly: 1 Note: JP Only > 940097 ~~$1,416.22~~ $1,391.86 - + Add to cart
18	SCREW, SKT, HD, M5, X, 25, SS Part #: T3330429 Required per assembly: 2 Note: 906559 > 939360 All Except JP, BR & IN; 906743 > 940097 JP Only; 906559 > 939539 BR & IN Only ~~$2.31~~ $2.10 - + Add to cart
18	SCREW, BUT/HD, M5, X, 20, SILVER Part #: T3338989 Required per assembly: 2 Note: > 906558; All Except JP & > 906742 JP Only ~~$7.10~~ $6.46 - + Add to cart
18	SCREW, BUT/HD, M5, X, 20, SILVER Part #: T3338989 Required per assembly: 2 Note: 939361 > All Except JP, BR & IN; 940098 > JP Only; 939540 > BR & IN Only ~~$7.10~~ $6.46 - + Add to cart
19	FLANGED, SLEEVE, M5, X, 7.9, X, 13.5 Part #: T3010157 Required per assembly: 2 Note: 906559 > All Except JP & 906743 > JP Only ~~$6.07~~ $5.52 - + Add to cart
20	WASHER, M6X13X1, S5041 Part #: T3550962 Required per assembly: 2 ~~$2.01~~ $1.83 - + Add to cart
