Instruments replacement parts for Triumph Tiger XRx

OEM Parts Triumph Tiger XRx Instruments

Instruments Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	INSTRUMENT KIT Part #: T2503734 Required per assembly: 1 Note: > 731170 $1,307.47 $1,284.97 - + Add to cart
1	INSTRUMENT ASSEMBLY Part #: T2503175 Required per assembly: 1 Note: 731171 > 761795 $1,290.38 $1,268.17 - + Add to cart
1	INSTRUMENT ASSEMBLY Part #: T2503175 Required per assembly: 1 Note: 761796 > BR Only $1,290.38 $1,268.17 - + Add to cart
1	INSTRUMENT ASSEMBLY Part #: T2503185 Required per assembly: 1 Note: 761796 > All Except BR $1,290.38 $1,268.17 - + Add to cart
2	SCREW, HHF, 50X16, SLV Part #: T3331414 Required per assembly: 1 Note: > 731170 $1.54 $1.40 - + Add to cart
2	SCREW, HHF, 50X16, SLV Part #: T3331414 Required per assembly: 2 Note: 731171 > $1.54 $1.40 - + Add to cart
3	WASHER, 5.3, X, 18, X, 1.6 Part #: T3555023 Required per assembly: 1 Note: > 731170 $1.29 $1.18 - + Add to cart
3	WASHER, 5.3, X, 18, X, 1.6 Part #: T3555023 Required per assembly: 2 Note: 731171 > $1.29 $1.18 - + Add to cart
4	GROMMET, INSTRUMENTS Part #: T3020097 Required per assembly: 3 $2.05 $1.86 - + Add to cart
5	INSTRUMENT FINISHER Part #: T2307997 Required per assembly: 1 $37.09 $36.44 - + Add to cart
6	GROMMET Part #: T3020065 Required per assembly: 2 $3.01 $2.74 - + Add to cart
