OEM Parts Triumph Trophy > 29155 Lubrication System

Triumph Trophy > 29155 VIN prior to 29155 - Lubrication System

Lubrication System Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

BOLT, ASSEMBLY, OIL, FILTER

Part #: 1210131T0301 Required per assembly: 1
Not Available
2

'O' RING

Part #: 3600003T0301 Required per assembly: 1
$1.84
$1.67
-
+
Add to cart
3

FILTER COVER PLATE

Part #: 1230011T0301 Required per assembly: 1 Note: 3 Cyl
$4.17
$1.32
-
+
Add to cart
3

FILTER COVER PLATE

Part #: 1230013T0301 Required per assembly: 1 Note: 4 Cyl
Not Available
4

'O' RING

Part #: 3600025T0301 Required per assembly: 1
$1.84
$1.67
-
+
Add to cart
5

SPRING, OIL, FILTER

Part #: 1210140T0301 Required per assembly: 1
Not Available
6

WASHER, OIL, FILTER

Part #: 3550004T0301 Required per assembly: 2
$2.22
$2.12
-
+
Add to cart
7

OIL, FILTER, STD, 60, PACK

Part #: T1210033 Required per assembly: 1 Note: Multipack (60)
Not Available
7

OIL, FILTER, STD, 36, PACK

Part #: T1210032 Required per assembly: 1 Note: Multipack (36)
Not Available
7

OIL FILTER

Part #: T1219000 Required per assembly: 1
$15.67
$14.95
-
+
Add to cart
8

OIL PUMP ASSEMBLY

Part #: 1210001T0301 Required per assembly: 1 Note: 4 Cyl
Not Available
8

OIL PUMP ASSEMBLY

Part #: 1210005T0301 Required per assembly: 1 Note: 3 Cyl
Not Available
9

(SUP) SCREW TORX M6 X 25

Part #: T3330186 Required per assembly: 4 Note: M6 x 25mm
$3.22
$2.93
-
+
Add to cart
10

DOWEL, HOLLOW, 8X14

Part #: T3000101 Required per assembly: 2
$3.97
$3.61
-
+
Add to cart
11

O RING

Part #: T3600013 Required per assembly: 1
$1.42
$1.29
-
+
Add to cart
12

OIL PUMP GEAR AND SHAFT

Part #: 1210290T0301 Required per assembly: 1 Note: > 23706
Not Available
12

OIL PUMP GEAR & SHAFT

Part #: T1210790 Required per assembly: 1 Note: 23707 >
Not Available
13

WASHER, 12, X, 18, X, 1.2

Part #: T3555003 Required per assembly: 1
$1.42
$1.29
-
+
Add to cart
14

CIRCLIP

Part #: 3500008T0301 Required per assembly: 1
Not Available
15

GEAR & SHAFT INTMDTE OIL PUMP

Part #: 1210305T0301 Required per assembly: 1 Note: > 23706
Not Available
15

GEAR & SHAFT ASSEMBLY< OIL PUMP

Part #: T1210805 Required per assembly: 1 Note: 23707 >
Not Available
16

AUXILIARY, GEAR, OIL, PUMP

Part #: T1210535 Required per assembly: 1 Note: 23707 >
Not Available
16

GEAR, AUXILIARY, OIL, PUMP

Part #: 1210035T0301 Required per assembly: 1 Note: > 23706
Not Available
17

WASHER, HARD

Part #: 3550033T0301 Required per assembly: 1
Not Available
18

SCREW C'SUNK TORX M5 X 10

Part #: 3330280T0301 Required per assembly: 1 Note: M5 x 10mm
Not Available
19

OIL FILTER / O RING KIT

Part #: 3990070T0301 Required per assembly: 1 Note: Comprises 1 off each of items 2, 4, & 7 above
$14.45
$13.79
-
+
Add to cart
