1984 Honda 1000 INTERCEPTOR (VF1000F) - Front Fork

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
001

FORK, ASSEMBLY, R., FR.

Part #: 51400-MB6-612 Required per assembly: 1
Not Available
003

COLLAR, SPRING

Part #: 51402-MB6-611 Required per assembly: 2
Not Available
004

SPRING, OIL, LOCK

Part #: 51402-MB7-611 Required per assembly: 1
$6.05
$5.40
005

VALVE, OIL, LOCK

Part #: 51403-MB7-611 Required per assembly: 1
$11.85
$10.10
006

PLATE, SPRING, JOINT

Part #: 51404-MB4-003 Required per assembly: 2
$5.92
$5.30
007

SEAT, SPRING

Part #: 51404-MB7-611 Required per assembly: 1
$5.74
$5.15
008

RING, STOPPER

Part #: 51405-MB4-003 Required per assembly: 2
$7.31
$6.42
009

RING, STOPPER

Part #: 51405-MB7-611 Required per assembly: 2
$3.94
$3.58
012

RING, BACK-UP

Part #: 51412-MB4-003 Required per assembly: 2
$11.18
$9.55
013

BUSH, GUIDE

Part #: 51414-KCR-003 Required per assembly: 2
$16.26
$13.54
013

BUSH, GUIDE

Part #: 51414-KCR-003 Required per assembly: 2
$16.26
$13.54
014

BUSH, SLIDER

Part #: 51415-MB4-003 Required per assembly: 2
Not Available
015

BUSH, B, SLIDER

Part #: 51419-MB4-003 Required per assembly: 2
$23.35
$19.46
016

GASKET

Part #: 51417-MJ0-013 Required per assembly: 1
Not Available
017

SPRING, PISTON

Part #: 51418-MJ0-003 Required per assembly: 1
$4.76
$3.67
019

COLLAR, PISTON

Part #: 51423-MJ0-003 Required per assembly: 1
$13.64
$11.37
022

PISTON

Part #: 51436-MJ0-003 Required per assembly: 1
Not Available
023

RING, PISTON

Part #: 51437-MB4-003 Required per assembly: 2
$11.09
$9.48
026

PIPE, SEAT

Part #: 51440-MB6-611 Required per assembly: 1
Not Available
027

RUBBER, STOPPER

Part #: 51441-MJ0-003 Required per assembly: 2
$2.77
$2.14
028

BOOT, PISTON, CASE

Part #: 51442-MJ0-003 Required per assembly: 1
$11.28
$9.62
029

RING, STOPPER

Part #: 51445-MJ0-003 Required per assembly: 1
$3.62
$3.29
030

CIRCLIP (INNER)

Part #: 51447-MB4-003 Required per assembly: 1
$5.59
$5.04
031

BOLT, ASSEMBLY, FR., FORK

Part #: 51450-MB6-771 Required per assembly: 1
Not Available
033

CAP, AIR, VALVE

Part #: 51456-MB2-003 Required per assembly: 2
Not Available
034

VALVE, AIR

Part #: 51456-469-013 Required per assembly: 2
$39.05
$32.57
035

CAP, ADJUSTING, PLATE

Part #: 51458-MG5-611 Required per assembly: 1
Not Available
036

SEAL, SET, FR., FORK

Part #: 51490-MN8-305 Required per assembly: 2
$40.80
$34.03
037

MARK, FR., FORK

Part #: 51496-MC7-670 Required per assembly: 1
$6.00
$5.36
038

FORK, ASSEMBLY, L., FR.

Part #: 51500-MB6-613 Required per assembly: 1
Not Available
041

CASE, PISTON

Part #: 51530-MJ0-003 Required per assembly: 1
Not Available
042

BUSH, PIVOT

Part #: 51532-MB2-300 Required per assembly: 2
Not Available
044

PIPE, SEAT

Part #: 51540-MB6-611 Required per assembly: 1
Not Available
045

BUSH, RUBBER

Part #: 51545-MJ0-003 Required per assembly: 1
$10.87
$9.30
046

PLATE, ADJUSTER

Part #: 51558-MJ0-003 Required per assembly: 1
Not Available
047

ROD, SET, ADJUSTER

Part #: 51591-MJ0-305 Required per assembly: 1
Not Available
048

HOLDER, AXLE

Part #: 51634-MJ0-003 Required per assembly: 2
Not Available
051

BOLT, FLANGE, (8X16)

Part #: 90106-MB2-000 Required per assembly: 2
$5.43
$4.94
053

BOLT, SOCKET, (8X27)

Part #: 90116-383-721 Required per assembly: 2
$6.04
$5.49
055

SCREW, SOCKET

Part #: 90150-MJ0-003 Required per assembly: 1
Not Available
057

GASKET, FR.

Part #: 90543-273-000 Required per assembly: 1
$3.50
$3.18
058

WASHER (8MM)

Part #: 90544-283-000 Required per assembly: 2
$3.89
$3.54
059

DUST SEAL

Part #: 91254-MM8-003 Required per assembly: 2
$20.72
$17.28
060

O-RING (5.6X1.9)

Part #: 91318-ME5-003 Required per assembly: 1
$5.04
$4.58
060

O-RING (5.8X1.9)

Part #: 91305-323-000 Required per assembly: 2
$4.08
$3.71
061

O-RING (16MM)

Part #: 91303-800-000 Required per assembly: 1
$3.19
$2.97
062

O-RING

Part #: 91308-MJ0-003 Required per assembly: 2
$4.93
$4.48
063

O-RING

Part #: 91310-MJ0-003 Required per assembly: 2
$3.31
065

O-RING (40.5X2)

Part #: 91352-MB4-003 Required per assembly: 4
$5.59
$5.04
067

O-RING

Part #: 91356-MB4-003 Required per assembly: 2
$4.90
$4.45
068

BOLT, HEX., (6X8)

Part #: 92101-06008-0A Required per assembly: 1
$2.26
$2.05
069

BOLT, STUD, (8X50)

Part #: 92900-08028-3B Required per assembly: 2
$2.60
$2.41
070

NUT, HEX., (8MM)

Part #: 94030-08070 Required per assembly: 1
$1.55
$1.42
071

WASHER, PLAIN, (8MM)

Part #: 94101-08700 Required per assembly: 4
$2.02
$1.87
073

BALL (#5) (5/32)

Part #: 96211-05000 Required per assembly: 55
$2.13
$1.97
