OEM Parts Honda 1984 Honda CR125R Shock Absorber 84

1984 Honda CR125R - Shock Absorber 84

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
002

BAND, SUB-TANK

Part #: 50252-KA3-830 Required per assembly: 2
Not Available
004

SHOCK, ABSORBER, RR.

Part #: 52400-KA3-742 Required per assembly: 1
Not Available
005

SPRING (4.6 KG/MM)

Part #: 52403-KA3-732
Not Available
005

SPRING (3.8 KG/MM)

Part #: 52402-KA3-732
Not Available
005

SPRING (4.2 KG/MM)

Part #: 52401-KA3-732 Required per assembly: 1
Not Available
008

SEAT, SPRING, (UPPER)

Part #: 52422-KA3-731 Required per assembly: 1
Not Available
009

NUT, ADJUSTER

Part #: 52423-KA3-731 Required per assembly: 1
Not Available
011

CASE, RR.

Part #: 52425-KA3-732 Required per assembly: 1
Not Available
012

ROD

Part #: 52426-KA3-731 Required per assembly: 1
Not Available
014

CAP, CASE

Part #: 52428-KA3-731 Required per assembly: 1
Not Available
018

CAP, AIR, VALVE

Part #: 52436-KA3-731 Required per assembly: 1
Not Available
019

CORE, VALVE

Part #: 52437-KA3-731 Required per assembly: 1
$11.95
$10.03
-
+
Add to cart
020

NUT, HEX., (12MM)

Part #: 52438-KA3-731 Required per assembly: 1
$4.02
-
+
Add to cart
021

O-RING SET

Part #: 52437-KA3-832 Required per assembly: 1
Not Available
022

HOSE, JOINT

Part #: 52440-KA3-731 Required per assembly: 1
Not Available
023

BOLT, OIL

Part #: 52441-KA3-731 Required per assembly: 2
Not Available
024

WASHER, OIL, BOLT

Part #: 52442-KA3-731 Required per assembly: 2
$3.38
$3.07
-
+
Add to cart
025

O-RING (2.4X10.8)

Part #: 52447-KA3-731 Required per assembly: 1
Not Available
027

DIAL, SUB-TANK

Part #: 52433-KK0-004 Required per assembly: 1
Not Available
028

BUSH, DAMPER, (LOWER)

Part #: 52451-MA0-000 Required per assembly: 1
$17.53
$14.60
-
+
Add to cart
029

ARM, SHOCK, ABSORBER

Part #: 52460-KA3-730 Required per assembly: 1
Not Available
030

BUSH, DAMPER, ARM

Part #: 52462-MA0-013 Required per assembly: 1
Not Available
031

COLLAR

Part #: 52463-MA0-010 Required per assembly: 1
Not Available
033

ROD ASSEMBLY

Part #: 52470-KA3-730 Required per assembly: 1
Not Available
035

BUSH

Part #: 52472-MA0-013 Required per assembly: 2
$34.16
$28.48
-
+
Add to cart
037

COLLAR

Part #: 52473-MA0-020 Required per assembly: 2
$19.32
$16.12
-
+
Add to cart
038

COLR, SHOCK, (UPPER)

Part #: 52486-KA3-731 Required per assembly: 2
Not Available
039

RING, STOPPER

Part #: 52487-KA3-731 Required per assembly: 1
Not Available
040

LABEL, RR.

Part #: 87516-KT1-901 Required per assembly: 1
Not Available
041

BOLT, FLG, (12X105)

Part #: 90128-KA3-730 Required per assembly: 4
Not Available
042

BOLT, FLANGE, (10X77)

Part #: 90129-KF0-000 Required per assembly: 1
$17.22
$14.36
-
+
Add to cart
043

BOLT, FLANGE, (10X98)

Part #: 90130-KA3-730 Required per assembly: 1
$21.32
$17.26
-
+
Add to cart
044

BOLT, FLANGE, (10X48)

Part #: 90153-KA3-730 Required per assembly: 1
Not Available
045

BOLT, FLANGE, (10X58)

Part #: 90153-KK0-000 Required per assembly: 1
$8.73
$7.56
-
+
Add to cart
046

NUT, AXLE, (10MM)

Part #: 90304-GA6-003 Required per assembly: 6
$3.91
$3.55
-
+
Add to cart
047

NUT, FLANGE, (12MM)

Part #: 90306-181-761 Required per assembly: 2
$7.31
$6.42
-
+
Add to cart
048

BEARING (14MM)

Part #: 91077-KN5-004 Required per assembly: 1
$24.73
$20.60
-
+
Add to cart
049

SEAL

Part #: 91262-KR8-750 Required per assembly: 2
Not Available
050

SEAL

Part #: 91262-KA3-712 Required per assembly: 4
$13.47
$11.24
-
+
Add to cart
