Carburetor replacement parts for 1985 Honda ALL TERRAIN CYCLE (ATC200X)

OEM Parts Honda 1985 Honda ALL TERRAIN CYCLE (ATC200X) Carburetor

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	GASKET SET Part #: 16010-HB5-305 Required per assembly: 1 $31.80 $26.51 - + Add to cart
002	NEEDLE, SET, JET Part #: 16012-965-004 Required per assembly: 1 Not Available
003	FLOAT SET Part #: 16013-439-921 Required per assembly: 1 $76.09 $73.79 - + Add to cart
004	TOP SET Part #: 16014-440-912 Required per assembly: 1 Not Available
006	SCREW SET A Part #: 16016-402-004 Required per assembly: 1 $24.12 $20.11 - + Add to cart
007	VALVE, SET, THROTTLE Part #: 16022-965-024 Required per assembly: 1 Not Available
008	SCREW SET B Part #: 16028-KB1-D11 Required per assembly: 1 $6.94 $6.31 - + Add to cart
009	CARBURETOR ASSEMBLY Part #: 16100-965-024 Required per assembly: 1 Not Available
010	CAP, CABLE, SEALING Part #: 16148-KB1-921 Required per assembly: 1 $19.12 $15.49 - + Add to cart
011	PLATE, STAY Part #: 16119-440-004 Required per assembly: 1 $10.65 $9.13 - + Add to cart
012	LEVER, CHOKE Part #: 16135-KA8-671 Required per assembly: 1 Not Available
013	VALVE, FLOAT Part #: 16155-413-751 Required per assembly: 1 $37.67 $31.41 - + Add to cart
015	HOLDER, JET Part #: 16168-382-014 Required per assembly: 1 $11.37 $8.45 - + Add to cart
016	TUBE Part #: 16199-KG4-405 Required per assembly: 2 $9.46 $9.40 - + Add to cart
016	TUBE Part #: 16199-KG4-405 Required per assembly: 1 $9.46 $9.40 - + Add to cart
017	TUBE, OVERFLOW Part #: 16199-435-771 Required per assembly: 1 $11.35 $11.01 - + Add to cart
018	SCREW-WASHER (4X16) Part #: 93892-04016-08 Required per assembly: 4 $1.79 $1.65 - + Add to cart
019	SCREW-WASHER (5X12) Part #: 93892-05012-08 Required per assembly: 2 $2.18 $2.02 - + Add to cart
020	NUT, FLANGE, (6MM) Part #: 94050-06080 Required per assembly: 7 Note: Sold in multiples of 5 only $1.73 $1.59 - + Add to cart
021	CLIP, TUBE, (B6.5) Part #: 95002-02650 Required per assembly: 1 $2.49 $2.31 - + Add to cart
022	JET, MAIN, (#110) Part #: 99113-GHB-1100 Required per assembly: 1 $10.80 $9.24 - + Add to cart
022	JET, MAIN, (#108) Part #: 99113-GHB-1080 $10.80 $9.24 - + Add to cart
023	JET, SLOW, (#40) Part #: 99103-GBF-0400 $13.13 $12.75 - + Add to cart
