Carburetor replacement parts for 1985 Honda ALL TERRAIN CYCLE (ATC350X)

OEM Parts Honda 1985 Honda ALL TERRAIN CYCLE (ATC350X) Carburetor

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	GASKET SET Part #: 16010-HA5-305 Required per assembly: 1 $49.42 $41.21 - + Add to cart
002	NEEDLE, SET, JET Part #: 16012-HA5-004 Required per assembly: 1 Not Available
003	FLOAT SET Part #: 16013-HN5-671 Required per assembly: 1 $49.94 $41.63 - + Add to cart
004	TOP SET Part #: 16014-HM3-L00 Required per assembly: 1 Not Available
005	CHAMBER, SET, FLOAT Part #: 16015-HA5-014 Required per assembly: 1 Not Available
006	SCREW SET Part #: 16016-KR3-721 Required per assembly: 1 Not Available
007	ARM, SET, LINK Part #: 16018-HA7-771 Required per assembly: 1 Not Available
008	SCREW SET Part #: 16028-HA5-004 Required per assembly: 1 Not Available
009	VALVE, SET, STARTER Part #: 16046-HA5-004 Required per assembly: 1 Not Available
010	CARBURETOR ASSEMBLY Part #: 16100-HA5-014 Required per assembly: 1 Not Available
011	VALVE, THROTTLE Part #: 16111-HA5-004 Required per assembly: 1 Not Available
012	TUBE, FUEL Part #: 16199-MN5-405 Required per assembly: 1 $13.75 $11.46 - + Add to cart
013	VALVE, FLOAT Part #: 16155-413-751 Required per assembly: 1 $37.67 $31.41 - + Add to cart
016	HOLDER, JET Part #: 16168-HC4-003 Required per assembly: 1 $14.19 $10.21 - + Add to cart
018	TUBE Part #: 16198-ML4-405 Required per assembly: 1 Not Available
019	TUBE, FUEL Part #: 16199-459-004 Required per assembly: 1 Not Available
020	SCREW, PAN, (3X6) Part #: 93500-03006-0H Required per assembly: 1 $1.87 $1.73 - + Add to cart
021	SCREW, PAN, (4X8) Part #: 93500-04008-0H Required per assembly: 4 $1.95 $1.80 - + Add to cart
022	SCREW, PAN, (4X14) Part #: 93500-04014-0H Required per assembly: 4 $1.87 $1.70 - + Add to cart
023	SCREW, PAN, (6X10) Part #: 93500-06010-0H Required per assembly: 1 $1.98 $1.83 - + Add to cart
024	SCREW-WASHER (5X14) Part #: 93892-05014-08 Required per assembly: 2 $2.13 $1.97 - + Add to cart
025	CLIP, TUBE, (B7) Part #: 95002-02070 Required per assembly: 2 $2.79 $2.60 - + Add to cart
026	CLIP, TUBE, (B8) Part #: 95002-02080 Required per assembly: 5 $2.79 $2.60 - + Add to cart
028	JET, MAIN, (#138) Part #: 99101-357-1380 Required per assembly: 1 $10.72 $9.19 - + Add to cart
029	JET, SLOW, (#40) Part #: 99103-MAZ-0400 Required per assembly: 1 $12.83 $10.70 - + Add to cart
